ES100 ELECTRONIC OVEN CONTROL
The ES100 electronic oven control is almost identical to the current control with a few exceptions.
Bake
Timer
Clock
Clear
Broil
On/Off
Set
Off
Note:
The ES100's are not field repairable.
Note:
Depending on model, the size and shape of touch pads may vary (for example round instead of elliptical).

NORMAL BAKE

During a normal bake mode, the control preheats the oven by alternate bake & broil elements. When the desired
temperature is reached, the control will cycle approximately between 5% of time in Broil and 92% of time in Bake.
Both elements use full power when they are on but they are never on at the same time.
FIRST RISE
It is normal to see a temperature overshoot in the
first rise of all modes when you monitor the temperature.

OVEN CALIBRATION

Set the electronic oven control for normal baking at 350°F/176°C. Obtain an average oven temperature after a minimum
of 5 cycles. Press Cancel to end bake mode.
T
°
t (sec)
2
First rise overshoot
set point
