Page 3
ADDAC703Assembly Guide STEP 1: Grab the pcb and the capacitors, proceed to solder them, notice the orientation below. Tip: soldering these caps is easy, just place a dab of solder on the pad on your right (left pad if youʼre left handed) and then, with the help of a tweezer, put the capacitor in place and reflow the previously tinned pad to reflow the solder while pushing the capacitor down.
Page 4
ADDAC703Assembly Guide STEP 2: Next place the transistors and power regulator like shown below. 2N3392 2N3392 L79L05 2N3702 2N3702 ADDACSYSTEM page 4...
Page 5
ADDAC703Assembly Guide STEP 3: Next place the boxed power header. Notice the orientation marked on the pcb. ADDACSYSTEM page 5...
Page 6
ADDAC703Assembly Guide STEP 4: Next weʼll need to prepare some parts before adding them to the front panel. Locate the jacks and cut the smallest legs like shown below. ADDACSYSTEM page 6...
Page 7
ADDAC703Assembly Guide STEP 5: Place all parts on the pcb, notice the values, orientation and jack types like shown below. 50k =503 50k =503 50k =503 50k =503 1k =102 50k =503 100k =104 Non-threaded Jacks Threaded Jacks Non-threaded Threaded Jacks Jacks ADDACSYSTEM page 7...
Page 8
ADDAC703Assembly Guide STEP 6: Place the frontpanel and tighten all nuts. ADDACSYSTEM page 8...
Page 9
ADDAC703Assembly Guide STEP 7: Adjust the height of the pcb keeping it parallel to the front panel. ADDACSYSTEM page 9...
