Klein Tools 56063 Instructions

ENGLISH
The 56063 red Safety Lamp provides supplemental visual alert
in busy, noisy, dark, and bright environments. It is designed
to attach to Klein Tools' hard hat/safety helmet front or back
accessory mounts. The Safety Lamp can also be attached to
magnetic surfaces to serve as a stationary alert beacon. The
Safety Lamp has four user-selectable modes and is rechargeable.
• 56063 Safety Lamp
• 15" (381 mm) USB-A to USB-C Cable
• Instruction Sheet
• LED Color: Red
• Visibility: Up to 1/4 mile (0.4 km) in low light and clear weather
• Dimensions: 2.53" × 1.87" × 1.27" (64.3 × 47.5 × 32.3 mm)
• Weight (Safety Lamp only): 2.34 oz. (66 g)
• Battery Type: Internal, Lithium-Ion, 3.7V / 1200mAh
• Battery Life: Low ON: 22 hrs Low PULSE: 52 hrs
• Lumens: Low SOLID ON / Low PULSE: 4
• Charging Requirements: Maximum 5V DC, Minimum 0.5A
• Certifications: NRCan, CEC-BC, UL1642 (Battery)
• Operating/Charging Temperature: 32°F to 113°F (0°C to 45°C)
• Storage Temperature: 14°F to 131°F (-10°C to 55°C)
• Drop Protection: 10 ft. (3.05 m)
• Ingress Protection (IP) Rating: IP64
Specifications subject to change.
Read, understand, and follow these instructions to ensure safe
operation. Check with your safety supervisor prior to using this
product. Follow local safety codes.
• This safety lamp is NOT a headlamp. Its primary purpose is to
serve as visual alert to the immediate surroundings. DO NOT use
this as the primary light source.
• Visibility can be impacted by environmental conditions (fog,
flashing/bright lights, barriers, moving objects), mode selected,
viewing angles, and viewer's visual acuity.
• No user-serviceable parts. DO NOT open enclosure or attempt to
repair this safety lamp or charging cable. REPLACE SAFETY LAMP
OR CABLE with new, if damaged or not functioning properly.
• This safety lamp is NOT intended to be a replacement for any
personal protective equipment, high visibility apparel, reflective
markers/signs, lockout-tagout devices, construction warning
lights or other safety devices.
• This product is NOT designed to be charged or used in
environments where volatile gases, fumes and fine dust are present.
• Never place this safety lamp on other electrical/electronic
equipment that is sensitive to magnets.
• DO NOT expose to open flame, vibration, corrosive fumes or
extreme temperature.
• NEVER immerse in water or other liquids. Avoid spilling liquids or
falling foreign objects into openings on the safety lamp enclosure.
• Water-resistant cover must be properly sealed to achieve
specified water & foreign object ingress protection. Keep seal
free of dirt, oil, sand, or other material that interferes with proper
sealing. Failure to do so can result in risk of fire or electric shock.
• DO NOT open water-resistant cover if wet or in a wet environment.
Dry the Safety lamp thoroughly and the seal around water-resistant
cover completely before opening water-resistant cover.
• Use safety-rated power supply. Never use power supply or
charging cable that does not meet the specified charging voltage
and current listed in the specifications here or on the Safety Lamp.
1.800.561.8187

CONTENTS

GENERAL SPECIFICATIONS

High ON: 5 hrs High PULSE: 10 hrs
High SOLID ON / High PULSE: 22

WARNINGS

www.
Safety Lamp – Instructions
FIG. A
FRONT
8
6
9
BACK
3
1
information@itm.com
.com
56063
7
4
5
10
2
