- Page 1 Liso Glass Wall - Classroom Series ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 10/08/2019 1 of 13...
-
Page 2: Parts And Hardware
Tray Parts Parts and Hardware Left Tray End Glass Panel Right Tray End Blade Tray x1/2 x0/1 Roll Pin Top Trim x1/2 x2/ * P Nylon Tip Maprail x1/2 Adjuster with Cork Insert Maprail Pack Mounting Hardware M6-1x6mm #10 x1 1/4” Phillips Screw Phillips Screw 1/4”... -
Page 3: Warranty
WARNINGS AND DISCLAIMERS ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS Review full assembly instructions and Previo a comenzar el proceso de Avant de commencer l’ assamblage check that all parts are present before ensamblaje favor revisar veuillez consulter instructions beginning assembly. Heavy or large instrucciones y asegurarse que cuenta con complètes et vérifier si vous avez toutes furniture may require multiple persons in... - Page 4 STEP 1A Assembly for single piece tray. See STEP 1B for two piece tray assembly. Insert joiners (E1) into tray bottom channel. Slide in two joiners for every panel (i.e. 4 joiners for 2 panels). Move joiners along bottom channel until one hole on every joiner is lined up with a pre-drilled hole.
- Page 5 STEP 1B Assembly for two piece glass board tray. First splice two tray pieces together. Use one joiner (E1) on bottom channel and another on back channel with 2 set screws (E2) each. These joiners should not cover any pre-drilled holes in tray. A roll pin (C3) should also be added beneath the tray’s front lip.
- Page 6 STEP 2 Mounting glass board tray to wall. Place tray in desired location on wall. Mark anchor points using pre-drilled holes in back of tray piece. Install anchors at any mark not on a stud after pre- drilling a 1/4” hole in wall. Use drywall anchors (D2) or masonry anchors (D3) as needed and follow with screw (D1) through tray holes.
- Page 7 STEP 3 Mounting top trim to wall. If using two pieces of trim, splice with joiners (E1) before attaching to wall. Will need two joiners, one in top channel, one in back channel. Secure with set screws (E2) before proceeding. Insert wall mount clips (D4) along back edge of trim as shown.
- Page 8 STEP 4 For multiple panel installations only - Attach adhesive pads to wall. Remove backer off adhesive strips on one side of pads. Apply pad directly to wall being careful to center it along where vertical panel seam will be. Identify location of panel seams by marking halfway points between adjuster screw pairs above tray.
- Page 9 STEP 5 Attach adhesive pads to panel backs. Peel one side of backer off adhesive pads (B1) and apply to back of glass panels. See pictures below for pad placement. Each panel will receive at least ount two pads regardless of size. Do not peel backer on other side. 3X4 Horizontal Mount 3X4 Vertical Mount 3X4 Horizontal Mo...
- Page 10 STEP 6 Set panels into tray and trim. To set in first panel, slide entire length of top trim upward to make room for top of panels. Insert bottom of panel into tray at an angle then push top towards wall.
- Page 11 STEP 7 Adjust panel height at seams. Using adjusters previously inserted in tray, raise and lower panels to ensure flush seams across entire board. Use pictures below as guides in deciding where to make panel height adjustments. Situation 1: Gap at bottom of seam Situation 2: Gap at top of seam Raise Adjusters on one or both Lower Adjusters on one or both...
- Page 12 STEP 8 Remove adhesive and stick panels to wall. With all adjustments complete, adhesive backers on pads (B1) can be removed and panels stuck to wall. Start with one panel on either end of board. Lift up top trim enough to lower panel away from wall without removing from tray. Lower enough that backer on both adhesive pads on board and visible strips on wall can be peeled off.
- Page 13 STEP 9 Install maprail onto top trim. Hang maprail on top of trim as shown. For single piece of maprail, slide one joiner (E1) into upper trim top channel per every 4 ft of maprail. Add screw (A1) with washer (D4) to one hole in each joiner and use set screw (E2) in the other hole.
