Marco FRIIA HC Quick Start Manual

FRIIA HOT/COLD
>
Sleek, stylish font
combining hot/
cold water needs
> 0.8 or 2.1 GAL
boiler option
CHILLER
PRODUCT INFO SIZE
NAME DIMENSIONS
ORDER CODE ( D X W X H inches )
Chiller
17.1 x 10.2 x 17.9
1000860US
PRODUCT INFO
NAME DIMENSIONS
ORDER CODE ( D X W X H inches )
MIX UC3 - 220v
1000880US
15.1 x 8.2 x 17.4
MIX UC3 - 110v
1001880US
MIX UC8 - 220v
15.1 x 8.2 x 24.2
1000887US
FRIIA HC FRIIA HC PLUS
DIMENSIONS
NAME
INC. DRIP TRAY
ORDER CODE
( D X W X H inches )
2b Font
6.6 x 4.7 x 11.2
1000868
For more information visit www.marcobeveragesystems.com
ORDER CODES
> FRIIA HC
> FRIIA HC Plus
BOILER
PERFORMANCE SPECS
CUPS
GAL/HR
/HR
7.9-11.8 GALS/hr based
175-235
on incoming water temp
(ΔT =
of 59°F and output water
18 °F)
temp of 41-44°F
SIZE PERFORMANCE SPECS
IMMEDIATE
DRAW OFF
0.8 GAL
2.1 GAL
FONT DIMS
DIMENSIONS
EXCL. DRIP TRAY
( D X W X H inches )
5.4 x 1.1 x 11.2
(Complete bundle)
1000864US/1001864US
(220/110v)
SYSTEM SET - UP
PLUMBING, ELECTRICAL AND TECHNICAL SPECS
POWER PLUMBING COMPRESSOR
@110V REQS
3/8"
Compression
180W
or 3/8" John
Guest
GAL/HR CUPS/HR
7.3 GAL
75
3.6 GAL
NAME
5.4"
Fonts (all)
Chiller
MIX UC3 -
220v/110v
MIX UC8 -
220v
TAP TO
PLEASE
COUNTER
NOTE
( inches )
9.7
1000866US
CHARGE REFRIGERANT
POWER
1/8hp 45g R290
PLUMBING & ELECTRICAL REQS
PLUMBING
POWER NEMA
REQS
2.8kW
L6-20P
@ 220v
3/8"
1.4kW Compression
5-15p
@ 110v or 3/8" John
Guest
2.8kW
L6-20P
@ 220v
PACKAGING
DIMENSIONS WEIGHT
(L x W x H inches)
11.4 x 22.4 x 8.4 4.4lbs
19.2 x 11.8 x 20.2 69.4lbs
17.7 x 11.4 x 21.2 25lbs
17.7 x 11.4 x 27.5 30.8lbs
FRIIA components (font, boiler
and chiller) are packed and
shipped in individual boxes.
