- Page 1 FLEXIBLE SOLUTIONS IN MODERN TECHNOLOGY Remote controller Rojaflex HSR-1 | HSR-5 For all Rojaflex drives and radio receivers ORIGINAL OPERATING MANUAL V2.18-07.2020...
- Page 2 EU Declaration of Conformity specified in Article 10.9 Company Schoenberger Germany Enterprises GmbH & Co. KG, Hohenschäftlarn delares hereby that the radio device “Remote controller rojaflex HSR-1/HSR-5” conforms to Directive 2014/53/EU. The complete EU Declaration of Conformity is available at: https://www.rojaflex.com/konformitaetserklaerungen.html...
-
Page 3: Safety Guidelines
Observe instructions and safety driven device. guidelines concerning the controlled drive/receiver, as well as relevant instructions for driven sun protection devices! www.rojaflex.com... - Page 4 The use of defective devices may pose a hazard to people and cause damage in property. After unpacking, compare the device • type to relevant information in the nameplate. A device that is incomplete or not conforming to a specification cannot be started. www.rojaflex.com...
-
Page 5: Function Review
Programming button The remote controller 5 channel remote 1 channel remote back with a cover open controller HSR-1 controller HSR-5 Individual The “DIP switch” can be used to channels can be changed using choose between “SI” (single- K1 and K2 buttons directional communication) and “BI”... -
Page 6: Technical Data/Packaging Contents
Open space: ca. 150 m/closed rooms: ca. 30 m* Number of channels 1-channel/ 5 -channel Compatibility Rojaflex radio drivers and radio receivers Dimensions 130 x 44 x 18 mm (HxWxD) * Data on the range are approximations and depend on actual construction conditions. -
Page 7: Programming And Setup
1. Programming (learning) mode - a radio-controlled drive or an external radio receiver A radio receiver (a radio- controlled drive Rojaflex or an external radio receiver Rojaflex), to which a remote controller (transmitter) has to be assigned should be put into the programming mode as provided for in its programming mode instruction. - Page 8 When the drive moves in the opposite direction (the roller blind/drive moves down when the UP button is pressed), restart the process and press the DOWN, not the UP button after pressing the P2 button. This way the drive direction is changed. www.rojaflex.com...
- Page 9 P2 button of the already programmed remote controller is pressed only twice! This applies to MLSF/MLMMF drives – and external receivers REHK-1 and RUE-UP. An operating manual/drive of a given receiver/driver. Further information is available in relevant operating manuals of Rojaflex drives and radio receivers. www.rojaflex.com...
- Page 10 Notes www.rojaflex.com...
- Page 11 Notes www.rojaflex.com...
- Page 12 Should you have any questions about our product, please, contact us by a letter or by e-mail at the following address: rojaflex®™ is a registered trademark of Schoenberger Germany Enterprises Gmbh & Co. KG Zechstraße 1–7 82069 Hohenschäftlarn Germany Phone +49 (0) 8178 / 93 29 93 93 Any reproduction, including of parts of this document, requires the author’s consent.
