Model Specifications - Frigidaire Fas156N1A Product Information And Technical Manual

Model
Chassis Type
Capacity Features
BTU - Cooling
BTU - Heating
Moisture Removal
EER
Electrical Information
Voltage
Amps - Cooling
Amps - Heating
Watts - Cooling
Watts - Heating
Fuse/Breaker (Amps)
Receptacle Code
Wiring Diagram
Page #
Air Flow System
Capacitor-µ farads
Fan Motor Mfg.
Fan Motor Number
RPM/CMP (EVAP)
High
Medium
Low
Heat Only
Refrigeration System
Compressor Mfg.
Compressor Number
Compressor Type
Overload Protector
Capacitor-µ farads
Refrigerant Charge
Restrictor Tube
Thermostat Type
Installation Instructions
Kit Type
Part Number
Control Thermostat
Location Diagram
Condenser Fan and
Evaporator Blower
Location Diagram
FRIGIDAIRE MODEL SPECIFICATIONS
FAS156N1A FAS184N2A
Heavy Duty Heavy Duty
Top Control Top Control
15100 18000/17800
-
3.5
10.7
115 230/208
12.5 8.5/9.0
-
1415 1860/1840
-
15
A
309902101 309902101
17
10/370 6/440
Heshan Heshan
309630615 309630613
980/530 975/500
-
810/400 775/400
-
LG
QK191CAB QJ258KAB
Rotary Rotary
A363784 A363771
60/370 25/440
42 31.75
A112129 A112138
Electronic Electronic
A
309000906 309000906
Page 12 Page 12
Page 14 Page 14
FAS185N2A
Heavy Duty
Top Control
18500/18200
- -
5.3 5.5
9.7 10.7
230/208
7.8/8.5
- -
1730/1700
- -
15 15
C C
309902101
17 17
6/450
Heshan
309630613
1000/480
- -
800/380
- -
LG LG
QJ250KBA-6A
Rotary
A363789
35/450
36
A112115
Electronic
A A
309000906
Page 12
Page 14
4
FAS186N2A FAS226N2A
Heavy Duty Heavy Duty
Top Control Top Control
18500/18200 22000/21600
-
5.5 6.5
10.7 9.4
230/208 230/208
7.8/8.5 10.5/11.4
-
1730/1700 2340/2300
-
15 15
C C
309902101 309902101
17 17
6/450 7.5/450
Heshan Heshan
309630613 309630614
1000/480 1115/550
-
800/380 925/470
-
LG LG
QJ250KBA-6A QP306KBA
Rotary Rotary
A363789 Internal
35/450 40/450
36 38.5
A112115 A112114
Electronic Electronic
A A
309000906 309000906
Page 12 Page 12
Page 14 Page 14
-
-
-
-
-
