- Page 1 Original instructions ..7 ..10 ..13 ..16 ..20 ..28 ..36 ..24 ..32 ..40 ..44...
- Page 2 The introduction pages consist mainly of pictures. For translation of the English texts used, see the respective language pages. Introduktionssidorna består huvudsakligen av bilder. För översättning av de engelska texter som används, se respektive språksidor. Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de engelske tekstene, se de respektive språksidene.
-
Page 3: Installation Height
Dimensions 500/676 46,5 ø8 Wallbracket Positioning Installation height 1,8–2,5 m 2,3–3,5 m Fig.1: The heaters should heat from at least two directions for even heating... - Page 4 Minimum mounting distance ceiling bracket min 30° 1000 Flammable 1800 material Replacing the lamp...
- Page 5 Accessories 11884 IHUB* 18050 16975 IHXH* 16976 IHXL* 11887 IHT* IHUB IHXH IHXL 16974 IHTW* 16970 IHP* 92865 KLS1KS 93272 IHAF 220646 IHL1000 220647 IHL1500 IHT+IHTW 206496 IHL2000 *) See separate manual. KLS1KS IHAF IHP+IHT Controls 92867 IHBD3* 10740 *) See separate manual. IHBD3...
-
Page 6: Technical Specifications
IHF10 1000 230V~ 2200 11882 IHF15 1500 230V~ 2200 11883 IHF20 2000 230V~ 2200 Wiring diagrams Timer control 1 2 3 Max load 3500W IH/IHC IH/IHC IH/IHC 230V~ Timer control with contactor 1 2 3 230V~ 400V3~ IH/IHC IH/IHC IH/IHC... - Page 7 4. Lock in position with the screws. Protection class: IP44. Connection Positioning IH is equipped with a 0.9 metre cord with The heaters must be placed so that they plug for connection to an earthed outlet cover the area to be heated, see fig. 1. The socket.
-
Page 8: Maintenance
Replacing the lamp Residual current circuit breaker The heat lamp is of the highest quality and When the installation is protected by means unless it is subjected to mechanical strains in of a residual current circuit breaker, which the form of vibrations and impact it will last trips when the appliance is connected, for a long time. - Page 9 Safety • For all installations of electrically heated products should a residual current circuit breaker 300 mA for fire protection be used. • The unit must not be fully or partially covered as overheating can result in a fire risk! •...
- Page 10 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net.
