- Page 1 Application Note 80507NT11470A, Rev. 02 – 2016-05-26...
- Page 2 BlueEva+SR NFC Add-on Package Stollmann is a Telit brand. BlueEva+SR NFC Add-on Package Release r02 Page 2 of 10...
-
Page 3: Table Of Contents
3.1 Package Contents ..................5 3.2 Hardware ...................... 5 3.3 Solder the pin strip ..................6 3.4 Connect the NFC tag to the BlueEva+SR hardware ........6 BlueEva+SR Firmware Update (optional) ............7 Usage of NFC Handover ................... 7 History ....................... 8... -
Page 4: Introduction
This documentation describes the upgrade of the Bluetooth evaluation board BlueEva+SR with NFC Handover. 2 Requirements The BlueEva+SR NFC Add-on package is intended for customers who have bought a BlueEva+SR hardware without NFC Handover feature in the past. Figure 1: BlueEva+SR hardware without X3 connector (24 pin strip) -
Page 5: Package Contents
BlueEva+SR NFC Add-on Package Stollmann is a Telit brand. 3.1 Package Contents The NFC Handover Add-on package contains the following components: 1 x Pin strip (24 pins) 1 x NFC board “NTAGI2CEvalv1.0” including corresponding flat ribbon cable 3.2 Hardware... -
Page 6: Solder The Pin Strip
3.3 Solder the pin strip Please solder the pin strip carefully on top of the BlueEva+SR hardware and avoid solder straps. Otherwise the NFC tag will not work correctly! The place where the pin strip shall be soldered is labeled with “X3”. The pin strip has no alignment so it is not possible to solder it in a wrong direction. -
Page 7: Blueeva+Sr Firmware Update (Optional)
Please refer to the BlueEva+SR User Guide regarding firmware update. http://www.telit.com/support/technical-support/ 5 Usage of NFC Handover Please refer to the BlueEva+SR User Guide regarding the usage of the NFC Handover feature. http://www.telit.com/support/technical-support/ Page 7 of 10... -
Page 8: History
BlueEva+SR NFC Add-on Package Stollmann is a Telit brand. 6 History Version Release Date Change description 27.02.2015 NH First release 26.05.2016 BG Telit cover page added Page 8 of 10... - Page 9 BlueEva+SR NFC Add-on Package Stollmann is a Telit brand. Telit Wireless Solutions GmbH Phone: +49 (0)40 890 88-0 Mendelssohnstraße 15 D Fax: +49 (0)40 890 88-444 22761 Hamburg E-mail: ts-srd@telit.com Germany www.telit.com Page 9 of 10...
