C Plus
DeltaSol
®
1.2.3 Terminal allocation Arr 2
ARR 2
S1
R1
1.2.4 Terminal allocation Arr 3
ARR 3
S1
R1
S4 / TRF
6
|
S3
store 1
S2
R2
S3
R2
S2
Solar system and heat exchange to existant store
with 2 stores, 4 sensors and 2 pumps.
store 2
Symbol
S1
S4
S2
S3
S4
R1
R2
Solar system and after-heating with 1 store, 3 sensors
and after-heating. Sensor S4 / TRF can optionnally be used
for heat quantity measurement.
Symbol
S1
S2
S3
S4 / TRF
R1
R2
Description
collector sensor
store base sensor
store top sensor
store sensor 2
solar pump
pump for
heat exchange
Description
collector sensor
store sensor base
store sensor top
Sensor for heat quantity
measurement (optional)
solar pump
charging pump
after-heating
