Summary of Contents for Crane Coca-Cola BevMAX Refresh

  • Page 2: Table Of Contents

    Table of Contents CAUTIONS & WARNINGS…………………………………………………………………………………………….2 PROGRAMMING ......................... 3 General........................3 Normal Mode………………………………………………………………………………………………………………3 Service Mode……………………………………………………………………………………………………………...3 External Display Items ....................3 Quick Reference Menu Items ............... 4, 5, and 6 Programming Menu ....................7 Dixie-Narco Factory Setup Menu/BevMax Setup ............23 Cautions &...

  • Page 3: Programming

    COCA-COLA PROGRAMMING GENERAL INFORMATION In order to fully utilize the many features of your Vender it is important that you first understand the options available and procedures for programming the VMC (Vending Machine Controller). All programming, testing, and service functions are accomplished by using the Keypad in an easy to follow, Display prompted format.
  • Page 4 Coca-Cola BevMax 4 Programming Method Quick Reference Prompts Select Button 1: Abort/Cancel (will return to previous menu prompt or to normal door open mode). Select Button 2: Scroll Up (forward in menu). Select Button 3: Scroll down (backward in menu). Select Button 4: Enter/Save/Clear (allows you to enter a specific prompt, save what you have programmed, or clear the error).
  • Page 5 Coca-Cola BevMax 4 Programming Method Quick Reference Prompts Continued Select Button 1: Abort/Cancel (will return to previous menu prompt or to normal door open mode). Select Button 2: Scroll Up (forward in menu). Select Button 3: Scroll down (backward in menu). Select Button 4: Enter/Save/Clear (allows you to enter a specific prompt, save what you have programmed, or clear the error).

  • Page 6: Quick Reference Menu Items

    Coca-Cola BevMax 4 (xxx.xx Software) BevMax Setup Programming Method Quick Reference Menu Prompts BevMax Setup Coke Factory Setup Coke Factory Setup $ Enable Set Model Number Coke Factory Setup Product Recovery Coke Factory Setup Factory Testing Only Coke Factory Setup Set Prc/Tmpr 4 Test Light Timer Coke Factory Setup...

  • Page 7: Programming Menu

    PROGRAMMING MENU “Error Codes” - ERROR ROUTINE This function allows you to enter the error readout routine. “Error Codes” will appear when you press the service button on the control board. Press key number 4, if there have been no Error Codes since the last reset, the display will read “No Errors”.
  • Page 8 “Cab Control” – Cabinet Controller Summary Error Codes Press key number 4 and the display will show one of the following: - C Test – Cup Board factory test not completed. - E Test – Environmental Board factory test not completed - P Test –...
  • Page 9 “Card Reader” - Card Reader Summary Error Codes Press key number 4 and the display will show one of the following: - “Card Reader Comm”, indicating no card reader communication for 5 seconds. - “Card Reader #”, indicating the most recent “non-transient error” from the card reader (failed card reader). Press key number 1 will return to “Card Reader”...
  • Page 10 If all refrigeration summary Error Codes have been cleared the next error code will be displayed, or “No Error Codes” if there are no Error Codes. Press key number 1 will return to “Error Codes”. Press key number 2 will scroll to the next routine.
  • Page 11 Press key number 2 to scroll to “Password Entry”. * “Password Entry” - PASSWORD ROUTINE This function allows you to enter the following routines which are not accessible until the operator enters a password, which is set as 4-2-3-1. To enter the password, press key number 4 until the display goes blank. Then press key number 2, then 3, then 1, and then 4, and “Cash Counters”...
  • Page 12 “StS Programming” – SPACE TO SALES ROUTINE This function allows you to change the space to sale settings. Press key number 4 and “Option #” or “Custom StS” will show on the display, which indicates the current space to sales option. For the 7 options available, see list below. Press key number 2 to scroll through the options.
  • Page 13 Config 3 - Configuration Switch 3 - POS Message This code is used to disable the point of sale message. Config 3 0 = enabled, Config 3 1 = disabled. Press key number 4 and “Config 3 #” will be displayed, with the “#” flashing. Press key numbers 2 or 3 to scroll between “Config 3 0”...
  • Page 14 Press key number 4 with the display flashing the setting you wish to use. Press key number 1 to return to “Config 1 0”. Press key number 2 to scroll to the next configuration code. Press key number 1 to return to “Config Switches”.
  • Page 15 *”Language Select” - LANGUAGE ROUTINE This function is used to set the language that will be used for display messages. Note: This does not change the menu prompts. Press key number 4 and the display will show the language currently set in the controller. Press key number 2 or 3 to scroll through the languages available.
  • Page 16 *”Lighting Control” - LIGHTING CONSERVATION CONTROL ROUTINE (Config 2 Must Be Enabled – Config 2 1) This function is used to turn the lights off and on during certain periods of the day. Press key number 4 will enter “Enable #”. “Enable #”...
  • Page 17 “Start Time” - Start Energy Conservation This function is used to set the days and time to start Energy Conservation when “Enable 1” is selected. Press key number 4 and “Start Day” will show on the display. “Start Day” - Day to Start Setting This function is used to set the days of the week to start Energy Conservation.
  • Page 18 *”Select Block 1" - BLOCK SELECTION BANK 1 ROUTINE (Config 2 must be enabled – Config 2 1) This function is used to set selections which will be blocked during certain periods of the day. Press key number 4 will enter “Enable X”.
  • Page 19 “Lighting #” - Lighting / P.O.S. Display Control This function is used to turn the lights (if supported) and P.O.S. Display Message off during selection blocking period 1. 0 = disable or on; 1 = enable or off. Press key number 4 and the “#” will start flashing. Press key number 2 or 3 to scroll between “Lighting 0”...
  • Page 20 “Stop Time” - Stop Discount Pricing This function is used to set the day(s) and times to stop discount prices. Press key number 4 and “Stop Day” will show on the display. “Stop Day” - Day to Stop Setting Set this feature using instructions for “Select Block 1”, “Stop Time”, “Stop Day”. “Hour”...
  • Page 21 “Selection” – Selection(s) To Be Affected By Health Protection This function is used to set selection(s) which will be protected by the Health Protection constraints. Press key number 4 and “All Selections” will be displayed. Press key number 2 to scroll through “All Selections, A, B, C, D, and E”.
  • Page 22 “Remote Vend Mech” - REMOTE VEND MECHANISM ROUTINE This function is used to activate the Universal Satellite Device Control routine. Press key number 4 to enter routine. If the controller detects a device responding to the remote vend mechanism address (USD address #3,50H), the vend request commands for this device will be controlled by the following parameters.

  • Page 23: Dixie-Narco Factory Setup Menu/Bevmax Setup

    Dixie-Narco Factory Setup Menus - BevMax Setup/Test Modes The below diagnostic features are used for aligning the XY assembly and providing pertinent information that is unique to the Coca-Cola BevMax 4 Vender and is not found in the standard programming of the vender. These include menus for “BevMax Setup”, Test Modes”.
  • Page 24 “” key to save and display will show “#### Offset recorded. Then press “CLR to go back to “Shelf Offset”. Go to Position Test and check the plunger is contacting the targets correctly. Coke Factory Setup Position Test –Test Delivery Cup to column selected: This sub menu will be used to test the vend mechanism alignment to specific columns confirming the proper X belt tension.
  • Page 25 Coke Factory Setup Cup Test – Turns Delivery Cup Sensor On & Off: This sub menu will be used to test the operation of the Delivery (Picker) Cup Assy and Sensor. Press key 4 and the display will show “Cup Test”. Press key 4 and the display will show “On:0 In:0 Out:0 Hm:1”. Note: The left door switch must be pulled to the out position to perform this test.
  • Page 26 Coke Factory Setup Port Test – Test the operation of the Port : This sub menu will be used to test the operation of the Port Cup Assy and Port Sensor. Press the number 4 key and the display will show four numbers “####”. The 1 # is Port Open switch and 0 = Port not open or 1 = Port opened.
  • Page 27 Please see table below for programming options effected by MASTER RESET. NOTE: A power out error message will be generated when a master reset is performed. The table outlines the results of using MASTER RESET. ITEM RESET TO Tube Fill Cleared Cash Counters each select $0.00...
  • Page 28 This sub menu will be used to show the current software build number being used in the VMC and all peripheral boards. Press key 4 and the display will show “Build Number ####”. Where #### is the software build number significant to Crane engineering. Press the “1” Key to return to “BevMax Setup”. Coke Factory Setup Port Sensor Enable Pres Key 4 to enter menu, Use Port Sensor: “ON”...
  • Page 29 Coke Factory Setup Find Hook Swipe This function enables the machine to run the vend mechanism to automatically find the hook swipe position. Press button 4 and the vend mechanism will run to the delivery port to set the hook offset. Coke Factory Setup Mixed Credit This function can be used to enable the consumer to use a combination of cash and card to make a purchase.
