- Page 1 IM10147 AUTO-DARKENING HELMET February 2013 OPERATORʼS MANUAL Copyright © Lincoln Global Inc. • World's Leader in Welding and Cutting Products • • Sales and Service through Subsidiaries and Distributors Worldwide • 2345 Murphy Blvd. Gainesville, GA 30504 TEL: 866-236-0044...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page SAFETY WARNINGS – READ BEFORE USING HELMET INFORMATION SPECIFICATIONS OPERATING INSTRUCTIONS CARTRIDGE OPERATIONS/FEATURES SHADE GUIDE SETTINGS HELMET CARE AND MAINTENANCE TROUBLE SHOOTING WARRANTY INFORMATION REPLACEMENT PARTS... -
Page 3: Safety Warnings - Read Before Using
SAFETY WARNINGS – READ BEFORE USING WARNING ARC Rays can injure eyes and burn skin • Before welding, always inspect helmet and filter lens to be sure they are fitted properly, in good condition and not damaged. • Check to see that the clear lens is clean and securely attached to the helmet. •... -
Page 4: Helmet Information
HELMET INFORMATION This Auto-Darkening Welding Helmet will automatically change from a light state (shade 3.5) to a dark state (Shade 9-13) when arc welding starts. The filter automatically returns to a light state when the arc stops. Shade control adjustments can be made while welding. Match your welding application to the shade indicated on the shade chart. -
Page 5: Specifications
SPECIFICATIONS LCD Viewing Area 97 x 44mm (3.82 x 1.73in) Cartridge size 110 x 90mm (4.33 x 3.54in) UV/IR Protection Up to Shade DIN 16 at all times Arc Sensors Light State Shade DIN 4 Variable Welding Shades DIN 9 to 13 and Grind Shade Control External knob - full adjustment Power Supply... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Headgear Adjustment TILT ADJUSTMENT CROWN ADJUSTMENT RATCHET KNOB PIN HOLES FOR ADJUSTMENT Head Size Adjustment: Headband tightness is adjusted by pushing in the ratchet knob and turning to adjust to desired comfort level. This knob is located at the back of the helmet. HEAD GEAR CROWN ADJUSTMENT is made by adjusting crown strap for vertical placement on the head and snap- ping the pin into the hole to lock securely in place. -
Page 7: Cartridge Operations/Features
CARTRIDGE OPERATION/FEATURES Variable Shade Control The shade can be adjusted from shade 9 to 13 based upon welding process or application (refer to Shade selection chart on page 6). The variable shade control knob is mounted on the exterior of the helmet shell. Grind mode can be selected by rotating the shade control knob counterclockwise till an audible click is heard. -
Page 8: Shade Guide Settings
ALWAYS TEST TO BE SURE THE ADF CARTRIDGE IS CHARGED BEFORE WELDING. The TEST button is for the user to verify the ADF car- tridgeis darkening properly. If cartridge is not darkening properly, replacebat- teries with fresh batteries and test again before use. While welding, thearc and solar cell will keep the ADF charged. -
Page 9: Helmet Care And Maintenance
HELMET CARE AND MAINTENANCE Replacing Front Cover Lens: Replace the front cover lens if it is damaged – cracked, soiled or pitted. Place your finger or thumb into recess (C) at the bottom edge of the cover lens and flex the lens upwards until it releases from the edges marked A and B. -
Page 10: Trouble Shooting
TROUBLE SHOOTING GUIDE Test your shade cartridge prior to welding by directing the front of the car- tridge toward a bright source of light, then using your fingers rapidly cover and uncover the sensors. The cartridge should darken momentarily as the sensor is exposed. -
Page 11: Warranty Information
WARRANTY INFORMATION WARRANTY INFORMATION: These helmets are warranted for a period of two years. Please contact us at 1 (866) 236-0044 for any service or warranty questions. SPATTER DAMAGE IS NOT COVERED BY WARRANTY: Do not use this product without the correct protective clear cover lenses installed properly on both sides of the Auto-Darkening Filter cartridge (ADF). - Page 12 • World's Leader in Welding and Cutting Products • • Sales and Service through Subsidiaries and Distributors Worldwide • 2345 Murphy Blvd. Gainesville, GA 30504 TEL: 866-236-0044...
