USER MANUAL
Ver. 1.0 08/31/20
In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time
to time. Please check our website for the latest user manuals and product materials.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SWAGTRON T6

Summary of Contents for SWAGTRON T6

  • Page 1 USER MANUAL Ver. 1.0 08/31/20 In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
  • Page 3 1/2-inch thick. + The helmet should be approved by the U.S. Consumer Product Safety Commission (CPSC), the Snell Memorial Foundation, or the American Society for Testing and Materials (ASTM). SWAGTRON T6 Off-Road Hoverboard English...

  • Page 4: Table Of Contents

    1.6 DISPOSAL AT END-OF-LIFE ....................... 11 II - PRODUCT FEATURES ..........................12 2.1 SWAGTRON® T6 DIAGRAM ....................... 12 2.2 SWAGTRON® SENTRYSHIELD® – PATENTED MULTILAYERED PROTECTION ........13 2.3 LEARNING MODE / STANDARD MODE / ADVANCED MODE ............14 2.4 MOVEMENT INDICATORS ........................14 2.5 USING Bluetooth®...
  • Page 5 5.4 SAFETY WARNINGS ..........................28 VI – MAINTENANCE ............................ 31 6.1 CLEANING ............................31 6.2 STORAGE ............................. 32 6.3 TRANSPORTATION ..........................32 VII – SWAGTRON T6 SPECIFICATIONS ...................... 33 90-DAY Limited Hardware Warranty ....................... 34 SWAGTRON T6 Off-Road Hoverboard English...

  • Page 6: I - General Information

    I - GENERAL INFORMATION This User Manual will guide you through the functions and usage of your SWAGTRON. Before operating this vehicle, read all the instructions for safe assembly, charging, and operation. Please inspect the SWAGTRON unit upon unpacking for any signs of physical damage or defects.

  • Page 7: What's In The Box

    1.2 WHAT’S IN THE BOX? + SWAGTRON T6 Off-Road Smart Board + Charging Adapter + User Manual 1.3 WHAT’S NEW? The SWAGTRON Off-Road Smart Board contains the latest technology from SWAGTRON, including all new features that make riding safer and more fun.

  • Page 8: Safety Notice

    Please read and be sure to follow all instructions and safety recommendations in this user manual prior to and when riding your SWAGTRON. Before each ride, especially if you may travel a long distance, inspect your SWAGTRON. First, check the tires for English...
  • Page 9 BUILT-IN STARTUP BALANCING The T6 has a built-in Startup Balancing feature which may be turned on or off via the SWAGTRON app. This feature enhances the unit’s self-balancing feature by further stabilizing the board and ensuring that the pedals always face up.

  • Page 10: Important Information

    English SWAGTRON T6 Off-Road Hoverboard...

  • Page 11: Disposal At End-Of-Life

    The substances contained inside the battery present chemical risks to the environment. The recommended disposal for any Swagtron at its end-of-life is to dispose of the entire unit at or through an e-waste recycling center, program, or facility. Local regulations and laws pertaining to the recycling and disposal of lithium ion batteries and/or products containing them will vary according to country, state, and local governments.

  • Page 12: Product Features

    II - PRODUCT FEATURES 2.1 SWAGTRON® T6 DIAGRAM Reinforced Body Upgraded Motor and Stabilizers with Aluminum & Durable Shell System Status Indicators Battery Level Indicators Wider, Anti-slip Wider, Anti-slip Foot Pedals Foot Pedals Power Button Charging Port LED Movement Indicators...

  • Page 13: Swagtron® Sentryshield® - Patented Multilayered Protection

    Built-in Bluetooth® Speaker 2.2 SWAGTRON® SENTRYSHIELD® – PATENTED MULTILAYERED PROTECTION Your safety is our top priority. That’s why all SWAGTRON devices use a premium quality lithium-ion battery pack that is specifically designed with your well-being in mind. The battery housing used in SWAGTRON SentryShield® technology is made of aluminum, which provides an airtight seal enclosing the battery.

  • Page 14: Learning Mode / Standard Mode / Advanced Mode

    For more information on the battery specifications, see SECTION V. 2.3 LEARNING MODE / STANDARD MODE / ADVANCED MODE The SWAGTRON T6 includes three riding modes in order to provide all types of riders with the best experience possible. Easily switch between Learning and Standard Mode directly on your smart board.
  • Page 15 ACCELERATION – Blue lights on the front of the board indicate forward Blue motion. TURNING – Flashing green lights on the front of the board indicate Green turning direction. NOTE: For your safety, the Indicators cannot be turned off. SWAGTRON T6 Off-Road Hoverboard English...

  • Page 16: Using Bluetooth

    ® & “Swagtron music” should appear. Select “Swagtron music” to begin connecting if you would like to play music on your T6. Connect to “Swagtron” through your SWAGTRON app and enter the default password (000000) if prompted. The app can be used to switch modes and monitor your SWAGTRON T6 battery status. The SWAGTRON will make a sound to indicate that the devices have been successfully connected and/or paired.
  • Page 17 3.) Connection terminated + Powering on the SWAGTRON will automatically enable Bluetooth® i.e. Bluetooth® will become enabled and stay enabled as long as the SWAGTRON is powered on. + Some mobile devices immediately become “discoverable” once Bluetooth® is activated. Please check the instructions of your Bluetooth®-enabled device for any trouble with this feature.

  • Page 18: How To Ride

    III – HOW TO RIDE Get ready to ride with swag! The below instructions will ensure that you have a comfortable and safe riding experience with your SWAGTRON unit. Please read it carefully as this information is very important. Power Button 3.1 OPERATING STEPS...
  • Page 19 The SWAGTRON has 4 sensors below the pedals. When the rider steps on a pedal, the SWAGTRON will adjust itself to balance automatically. If the SWAGTRON does not enter self-balancing mode when triggering the sensors, the System Indicator will light up to indicate the error.

  • Page 20: Diagram Of Operation

    When you lean forward, the SWAGTRON will sense your actions and accelerate. When you need to turn, slow down and gently shift the weight on your left or right foot to turn towards the opposite direction.

  • Page 21: Calibration

    + If the T6 flips over or rotates more than 180º, motor and riding capability will be disabled. To restore normal functions, power off the unit then power the unit back on. After this, continue to ride as normal.
  • Page 22 IV – SAFE RIDING TECHNIQUES We sincerely hope every operator can ride the SWAGTRON safely. Think back to when you first learned to ride a bike, drive a car, or skateboard. Although the SWAGTRON is designed with gyroscopic balancing technology in order to maintain maximum stability, it is still possible to “override”...

  • Page 23: Safe Riding Techniques

    + Do not use the SWAGTRON on rough or loose terrain or off-road until you are familiar with all of the unit’s features and have practiced riding. Practice in open spaces and flat areas, avoid steeps slopes or high traffic areas until you’re completely comfortable riding.
  • Page 24 + Remember, only ride the SWAGTRON where it is permitted, you MUST comply with local laws and give way to pedestrians. WARNING: Devices are not intended for use at elevations greater than 2000 m above sea level. Prolonged exposure to UV rays, rain and the elements may damage the enclosure materials, store indoors when not in use.

  • Page 25: Battery Information

    Plug the charger into a grounded wall outlet (100V-240V; 50-60Hz). Verify that the green light is on, then plug the other end of the charging unit into the SWAGTRON. If charging while the smart board is on, all five lights of the battery indicator will turn blue when charging is complete.
  • Page 26 + Please keep your charging environment clean and dry. + If the charging port is damp or has any liquid on it, DO NOT charge your SWAGTRON. + In order for the battery to operate at maximum efficiency, avoid charging your SWAGTRON in extremely hot or extremely cold environments.

  • Page 27: Battery Level Indicator

    5.2 BATTERY LEVEL INDICATOR The SWAGTRON includes LED Indicators so you never have to guess how much power is left in your ride. There are 5 levels of power that you can monitor right at your feet. Indicator light Status...

  • Page 28: Range Per Charge

    5.3 RANGE PER CHARGE The average distance for which you can ride your SWAGTRON on a full charge is between 7 to 12 miles. However, many factors need to be considered when determining the actual range per charge. Factor Comment Speed and Riding Style Keep a moderate, consistent speed.
  • Page 29 (4) In the event that the battery leaks and the fluid gets into one’s eye, do not rub the eye. Rinse well with water and immediately seek medical care. If left untreated, the battery fluid could cause damage to the eye. SWAGTRON T6 Off-Road Hoverboard English...
  • Page 30 The temperature range within which the battery can be discharged is 32°F ~ 104°F (0°C to CAUTION 40°C). Use of the battery outside of this temperature range may damage the performance of the battery or reduce its life expectancy. English SWAGTRON T6 Off-Road Hoverboard...

  • Page 31: Maintenance

    VI – MAINTENANCE Your SWAGTRON must be maintained in order to provide the best riding experience. Follow the below tips and reminders to keep your SWAGTRON running in top condition. NOTE: + Always ensure the POWER is OFF and the unit is not being charged during maintenance.

  • Page 32: Storage

    + If storing the SWAGTRON for more than one month, discharge and recharge the battery at least once a month. + Store your SWAGTRON indoors in a location with stable temperate. Do not store in an unheated garage or shed. Do not store in a dusty environment as this may cause damage over time.

  • Page 33: Swagtron T6 Specifications

    VII – SWAGTRON T6 SPECIFICATIONS Item Parameters Net Weight 30.55 lbs Dimensions 25.7 x 10 x 10.5 in. Chassis Height 2.7 in. Pedal Height 6.6 in. Chassis Material Aluminum & Durable shell with UL approved material Tire Material Tubeless Nylon Tires / Aluminum Rims Maximum Speed 8 mph / 12.8 km/h...

  • Page 34: 90-Day Limited Hardware Warranty

    This Warranty is not assignable or transferable. The original purchaser may call SWAGTRON’s toll-free number at 1-844-299-0625 for service request. When a product or part is exchanged, any replacement item becomes your property and the replaced item becomes SWAGTRON ’s property.
  • Page 35 (including but not limited to wearables and other consumable parts such as tires); or (h) external causes such as accidents, abuse, or other actions or events beyond our reasonable control. Important: Do not disassemble the Product. Disassembling the Product will void this Warranty. Only SWAGTRON or a party ®...
  • Page 36 COPYRIGHT © 2020 SWAGTRON. ALL RIGHTS RESERVED.
