Black Multi-Purpose Mobile Podium
Instruction Manual
SKU: CART-V03E
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/cart-v03e
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo CART-V03E
Summary of Contents for Vivo CART-V03E
- Page 1 Black Multi-Purpose Mobile Podium Instruction Manual SKU: CART-V03E Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cart-v03e GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 44 lbs 22 lbs Failure to do so may result in serious injury. (20 kg) (10kg) TOP SHELF BOTTOM SHELF Phillips Screwdriver ASSEMBLY STEPS STEP 1 Attach Casters (3) to the Short and Long Square Tubes (1, 2) using the provided Wrench (24). - Page 4 STEP 4 After making sure the poles are at the same height, insert Plastic Knobs (10) into the back of the Pole Set (7) to set the height of the Inner Poles. STEP 5 Slide the Connector Cover (5) over the Pole Set (7). Attach the Pole Set (7) to the Tube Connector (4) using M6x10 Screws (20) in the back and M5x6 Set Screws (22) in the sides.
- Page 5 STEP 7 Attach the Shelf Supports (11) to the Pole Set (7) using M6x10 Screws (20). Tighten using the provided Allen Wrench (24). STEP 8 Attach the Shelf (12) to the Shelf Supports (11) using M4x6 Screws (21). Tighten with a Phillips screwdriver.
- Page 6 STEP 10 Place the assembled Top Plate (13) onto the Pole Set (7), and secure with M6x10 Screws (20). STEP 11 Insert Levers (17) with M6 Washers (23) through the slots in the Connecting Plates (14,15) and screw into Pole Set (7). STEP 12 Attach Soft Pads (18) to the top front edge of the Top Plate (13).
- Page 7 STEP 13 Loosen the Levers (17) to adjust the tilt angle, then tighten in the desired position. Adjust the height by loosening the Plastic Knobs (10), then tighten at the desired height. tilt 40˚ STEP 14...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
