Predator Installation Manual V10_1_29_00
•
Custom A- Current Preset -Used to show the stored preset text when the camera is at the preset
position. Text will be shown on top line of video.
Custom B - Current Preset -Used to show the stored preset text when the camera is at the preset
position. Text will be shown on second from top line of the video.
RTSPURL
•
Copy -Use this option to copy the RTSP URL
Overlay Options
•
Date Position - Choose date text to bottom right or left of the image.
•
lime Position - Choose time text to bottom right or left of the image.
Show Sub-stream - shows second sub-stream if enabled ..
RTSP authentication - Choose to enable or disable authentication on the RTSP stream D1 16:9
aspect ratio - Choose to output a 16:9 aspect ratio or the default which is 4:3
Choice of analogue or digital/IP video output.
Camera will perform an automatic reboot when this option is changed.
19 Video Advanced
•
,;·
360VirionTMhnologyLimhd
)(
©
Multicast
Tick the box to enable 'multicast'. If the box is not ticked then 'unicast' is
selected.
Multicast Stream 1 - Set IP address and port for stream 1.
•
Multicast Stream 2 - Set IP address and port for stream 2.
(See Video - Stream Type page 36).
-
Concurrent Uni/Multicast - Enable to allow concurrent unicast / multicast streams.
RTSP protocols allow 'multicast' or 'unicast' transmission. In addition to the multi cast feature being
available on the Predator, the 'multicast' feature must also be available on the receiving device.
OK to program the new settings into the Predator.
Cancel to abandon the changes to the video settings.
192.168.1.157flagon.hlml#
© 360 Vision Technology Ltd
