- Page 1 User's Manual LCD TV L19W461 Q41T2001673 3A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS …………………………….………………….. 1 FOR YOUR SAFETY …………………………………………………... 2 PRECAUT IONS AND REMINDERS ……………………………………3 IMPORTANT SAFETY INSTRUCTIONS …………………………….. 5 PREPARATION ………………………………………………………… 7 PERIPHERAL CONNECTION GUIDE ………………………………. 9 OPERATING INSTRUCTIONS ………………………………………. 10 TO USE THE FRONT PANEL CONTROL …………………….. 10 TO USE THE REMOTE CONTROL ……………………………. -
Page 3: For Your Safety
WARNING: To prevent fire or shock hazard, do not expose the TV to rain or moisture. Dangerously high voltages are present inside the TV. Do not open the cabinet. Refer servicing to qualified personnel only. -
Page 4: Precautions And Reminders
Don't place the TV in confined spaces or in a box when using it. Unplug immediately if other foreign materials are put inside TV box or if the TV fell down. Prohibit/Avoid opening TV cabinet... - Page 5 Avoid direct sunlight, dusty, high humidity and smoky areas. Call service personnel to clean the internal part of the TV once a year. Do not place the display near water, such as bathtub, washbasin, kitchen sink laundry tub, swimming pool or in a damp basement.
-
Page 6: Important Safety Instructions
13. The TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. - Page 7 Please, make sure to connect the power plug to the wall outlet socket after connecting the TV to the adapter! 22. Objects and Liquid Entry – Care should be taken so that objects do not fall...
-
Page 8: Preparation
TV to the power cord! lace the TV on a solid surface. Ensure that the TV is placed in a position to allow free flow of air. Do not cover the ventilation openings on the back cover. To prevent any unsafe situations, no naked flame sources, such as lighted candles, should be placed on or in the vicinity. -
Page 9: Power Key
Insert the power cord in the wall socket having an AC power supply. Then push the AC power switch to ON state. You can see the LED color is Blue, means the TV set is power on. If the LED color is Amber, which means this TV set is in stand 5. -
Page 10: Peripheral Connection Guide
PERIPHERAL CONNECTION GUIDE DVD/VCD/VCR/STB Once your equipment is connected, use the following procedure to view the input signal: Press the source button on the remote controller to select the relevant source to view. (ex: Press VIDEO button to select “Video1 Composite Rear” if you have connected a DVD player to Video1 Composite socket.) "HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC."... -
Page 11: Operating Instructions
VOL - : Press to decrease the sound volume level. ② - VOL + VOL +: Press to increase the sound volume level. Power key: Press to turn on / off (standby) the TV set. (Press to turn on TV after the Power-ON status LED had ③ changed to : Press to select the next lower Program number. -
Page 12: To Use The Remote Control
Normal, Wide1,Wide2, Zoom or Cinema mode. “SOURCE” Press repeatedly to choose the various input sources (Video 1 ~ 5). “CH- / CH +” Press + or - to browse through the TV channels. “Exit” Press to exit menu or OSD. “VIDEO ADJ”... -
Page 13: To Use The Menus
SETUP MENU The Setup menu in TV mode shows as below. In others source modes, the Setup menu only shows Menu Language and Aspect Ratio items. 1. Tuning Band: Select TV source signal from the Air (antenna) or Cable (CATV). -
Page 14: Video Menu
ATSC or NTSC TV channels and then edit (add/delete) the channel numbers. Channel Labels: Show the NTSC or ATSC TV channel label menu for user modifying channel labels specifically. 7. Menu Language: Select the menu display language. (English /Spanish / French) 8. -
Page 15: Audio Menu
5. Digital Audio Output: Digital audio output format selection, user can choose RAW (default) or PCM format. 6. TV Speaker: Choose to turn on / off the TV internal speaker. The digital audio output signals、earphone output signals and the composite L/R audio output signals will not be turn-off even though the TV speaker is off. -
Page 16: Feature Menu
Pacific、Alaska、Hawaii、Eastern、Central and Mountain. 【Time】item provides user to set the time clock. 2. Sleep Timer: Enable or disable the TV standby timer. User can set the TV standby timer as off / 5 min / 10 min / 15 min / 30 min / 45 min / 60 min / 90 min / 120 min / 180 min / 240 min. - Page 17 4. Password Set: Change the 4-numeral parental control password. Three steps are required for changing the password: Enter Old Password -> Enter New Password -> Confirm New Password. Note: This item is only available in TV, Composite and S-Video source modes. The default password is 『0 0 0 0』.
- Page 18 6. Digital Captions: Select the close caption options ( Service 1-6, Text 1-4 and CC 1-4) in digital TV mode. When select service 1 to service 6 you can modulate parameters in the Digital Close Caption. 7. Digital Closed Caption: Provide numerous options for setting the close caption style.
- Page 19 【Size】: Digital close caption font size, which can be set as Small、Normal or Large. 【Font】: Digital close caption font style, which can be chosen as Default or Font 1 ~ 7. 【Text Color】: Giving Red / Green / Blue / Yellow / Magenta / Cyan / Black / White Colors.
-
Page 20: Tips
Do not rub or strike the screen with anything hard as this may scratch, mar, or damage the screen permanently. Unplug the power cord before cleaning the screen. Dust the TV by wiping the screen and the cabinet with a soft, clean cloth. If the screen requires additional cleaning, use a clean, damp cloth. - Page 21 Canadian notice – This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Avis Canadian – Cat apparel numerous de la classed B respected toutes les exigencies du règlement sur le materiel brouilleur du Canada.
-
Page 22: Product Specification
Channel Coverage: VHF: 2 through 13 UHF: 14 through 69 Cable TV: Mild band (A - 8 through A - 1, A through I ) Super band (J through W) Hyper band (AA through ZZ, AAA, BBB) Ultra band (65 through 94, 100 through 125) -
Page 23: Before Calling Service
TV again. *Check antenna connection at the rear of the TV to see if it is properly connected to the TV. *Possible broadcast station trouble. Try another channel. *Adjust the contrast and brightness settings. -
Page 24: Glossary
(usually containing a second language translation for the displayed program). Sleep Timer You can set a time period for which the TV will automatically turn itself off. S-Video Input You can connect your TV set to a high-resolution video source (such as Super VHS video-cassette recorder, Laser Disc player and DVD Home Theater Set) in- order to provide maximum consumer viewing satisfaction. - Page 25 APPENDIX Use of Wall Mount Bracket Remove the M4 screws from the stand. Fasten M4 screws to secure the wall mount bracket.
- Page 26 Base Stand Installation Guide 1. Take out TV and base from carton. Place the TV on a solid surface. 2. Install the base onto TV stand. 3. Lock the 3 screws (provided in the accessory bag) at the bottom of the base.
