Ecco EW2030 Installation And Operation Instructions Manual

IMPORTANT!
Read all instructions before installing and using. Installer: This manual must be
delivered to the end user.
!
WARNING!
Failure to install or use this product according to manufacturer's recommendations may result in property
damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the safety
information contained in this manual.
1. Proper installation combined with operator training in the installation, use, care and maintenance of vehicle equipment accessories is
essential to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation are vital to the performance of this worklamp. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that s/he can
operate the system without losing eye contact with the work area.
5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use, the
vehicle operator should ensure the projection of the beam is not blocked by vehicle components (i.e., open trunks
or compartment doors), people, vehicles, or other obstructions.
6. The manufacturer assumes no liability for any loss resulting from the use of this device.
SAA
NOTE: Black die cast aluminum housing gets very hot to the touch after operating constantly for several hours.
Overall Dimensions: 2.6" x 3.0" x 2.7"
6.6 cm x 7.6 cm x 6.1 cm
Weight: 0.55 lbs.
0.25 kg
Input Voltage: 12-80 VDC
Current Draw: 1.0 A max.
Temp Range: -22° to 122°F
-30° to 50°C
Recommended Angle for Custom Preference
Installation:
Rating for In-Line Fuse
Needed:
Installation and Operation Instructions
SPECIFICATIONS
EW2015R
2.6" x 5.1" x 2.4"
6.6 cm x 13.0 cm x 6.1 cm
1.06 lbs.
0.50 kg
12-80 VDC
1.5 A max.
-22° to 122°F
-30° to 50°C
Custom Preference
5A
MATERIAL HANDLING LED
BOUNDARY WORKLAMP
EW2025R
2.5" x 3.75" x 1.87"
6.35 cm x 9.53 cm x 4.75 cm
0.56 lbs.
0.25 kg
12-80 VDC
1.1 A max.
-22° to 122°F
-30° to 50°C
5A
EW2030
90°
5A
Page 1 of 3
