Assembly- and Operating Manual
3-Jaws-Loading-Gripper Type UFG 26 / 32
Dear Customer,
Congratulations on choosing a SCHUNK product. By choosing SCHUNK, you have
opted for the highest
precision, top quality and best service.
You are going to increase the process reliability of your production and achieve
best machining results – to the customer's complete satisfaction.
SCHUNK products are inspiring.
Our detailed assembly and operation manual will
support you.
Do you have further questions? You may contact us at
any time – even after purchase. You can reach us directly at the below mentioned
addresses.
Kindest Regards,
Your SCHUNK GmbH & Co. KG
Precision Workholding Systems
SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106-134
74348 Lauffen/Neckar
Deutschland
Tel. +49-7133-103-0
Fax +49-7133-103-2189
automation@de.schunk.com
www.schunk.com
Reg. No. 003496 QM08
Reg. No. 003496 QM08
for
AUSTRIA: SCHUNK Intec GmbH
Tel. +43-7229-65770-0 · Fax +43-7229-65770-14
info@at.schunk.com · www.at.schunk.com
BELGIUM, LUXEMBOURG:
SCHUNK Intec N.V. / S. A.
Tel. +32-53-853504 · Fax +32-53-836351
info@be.schunk.com · www.be.schunk.com
CANADA: SCHUNK Intec Corp.
Tel. +1-905-712-2200 · Fax +1-905-712-2210
info@ca.schunk.com · www.ca.schunk.com
CHINA: SCHUNK Intec
Precision Machinery Trading (Shanghai) Co., Ltd.
Tel. +86-21-51760266 · Fax +86-21-51760267
info@cn.schunk.com · www.cn.schunk.com
CZECH REPUBLIC: SCHUNK Intec s.r.o.
Tel. +420-531-022066 · Fax +420-531-022065
info@cz.schunk.com · www.cz.schunk.com
DENMARK: SCHUNK Intec A/S
Tel. +45-43601339 · Fax +45-43601492
info@dk.schunk.com · www.dk.schunk.com
FINLAND: SCHUNK Intec Oy
Tel. +358-9-23-193861 · Fax +358-9-23-193862
info@fi.schunk.com · www.fi.schunk.com
FRANCE: SCHUNK Intec SARL
Tel. +33-1-64663824 · Fax +33-1-64663823
info@fr.schunk.com · www.fr.schunk.com
GREAT BRITAIN: SCHUNK Intec Ltd.
Tel. +44-1908-611127 · Fax +44-1908-615525
info@gb.schunk.com · www.gb.schunk.com
HUNGARY: SCHUNK Intec Kft.
Tel. +36-46-50900-7 · Fax +36-46-50900-6
info@hu.schunk.com · www.hu.schunk.com
INDIA: SCHUNK Intec India Private Ltd.
Tel. +91-80-40538999 · Fax +91-80-40538998
info@in.schunk.com · www.in.schunk.com
ITALY: SCHUNK Intec S.r.l.
Tel. +39-031-4951311 · Fax +39-031-4951301
info@it.schunk.com · www.it.schunk.com
JAPAN: SCHUNK Intec K.K.
Tel. +81-33-7743731 · Fax +81-33-7766500
naomi.masuko@jp.schunk.com · www.tbk-hand.co.jp
MEXICO, VENEZUELA:
SCHUNK Intec S.A. de C.V.
Tel. +52-442-211-7800 · Fax +52-442-211-7829
info@mx.schunk.com · www.mx.schunk.com
NETHERLANDS: SCHUNK Intec B.V.
Tel. +31-73-6441779 · Fax +31-73-6448025
info@nl.schunk.com · www.nl.schunk.com
NORWAY: SCHUNK Intec AS
Tel. +47-210-33106 · Fax +47-210-33107
info@no.schunk.com · www.no.schunk.com
POLAND: SCHUNK Intec Sp.z o.o.
Tel. +48-22-7262500 · Fax +48-22-7262525
info@pl.schunk.com · www.pl.schunk.com
RUSSIA: OOO SCHUNK Intec
Tel. +7-812-326 78 35 · Fax +7-812-326 78 38
info@ru.schunk.com · www.ru.schunk.com
SLOVAKIA: SCHUNK Intec s.r.o.
Tel. +421-37-3260610 · Fax +421-37-6421906
info@sk.schunk.com · www.sk.schunk.com
SOUTH KOREA: SCHUNK Intec Korea Ltd.
Tel. +82-31-7376141 · Fax +82-31-7376142
info@kr.schunk.com · www.kr.schunk.com
SPAIN, PORTUGAL: SCHUNK Intec S.L.U.
Tel. +34-937 556 020 · Fax +34-937 908 692
info@es.schunk.com · www.es.schunk.com
SWEDEN: SCHUNK Intec AB
Tel. +46-8-554-42100 · Fax +46-8-554-42101
info@se.schunk.com · www.se.schunk.com
SWITZERLAND, LIECHTENSTEIN:
SCHUNK Intec AG
Tel. +41-523543131 · Fax +41-523543130
info@ch.schunk.com · www.ch.schunk.com
TURKEY: SCHUNK Intec
Tel. +90-2163662111 · Fax +90-2163662277
info@tr.schunk.com · www.tr.schunk.com
USA: SCHUNK Intec Inc.
Tel. +1-919-572-2705 · Fax +1-919-572-2818
info@us.schunk.com · www.us.schunk.com
Advertisement
Table of Contents
Related Manuals for SCHUNK UFG 26
Summary of Contents for SCHUNK UFG 26
- Page 1 Assembly- and Operating Manual 3-Jaws-Loading-Gripper Type UFG 26 / 32 Dear Customer, Congratulations on choosing a SCHUNK product. By choosing SCHUNK, you have opted for the highest precision, top quality and best service. You are going to increase the process reliability of your production and achieve best machining results –...
-
Page 2: Table Of Contents
Page -2- TABLE OF CONTENTS Page 1. Unpacking and Control 2. Brief description and technical data 3. Assembly and connection 5 – 6 3.1 Assembly 3.2 Connection 4. Proximity Switches 7 – 8 4.1 Notes on proximity switches 4.2 Assembly and adjustment of proximity switches 5. -
Page 3: Unpacking And Control
- UFG (without top jaws and pressure piece) - 2 O-Rings Ø 6 x 2 mm - 3 screws M 8 x 35 DIN EN ISO 4762 (UFG 26) - 3 screws M 8 x 40 DIN EN ISO 4762 (UFG 32) -
Page 4: Brief Description And Technical Data
– stroke control can be continiuously adjusted – I.D. and O.D. clamping possible – centrically gripping Accessories: – proximity switch – pressure piece – top jaws (custom-made solutions available from SCHUNK) Technical Data: UFG 26 UFG 32 Actuation: hydraulically hydraulically Range of operating temperature: 6...60 bars... -
Page 5: Assembly And Connection
The gripper must be aligned during assembly since it is not equipped with fixing bores. 3 Fastening bores for M8 DIN EN ISO 4762 3 fastening threads in the plastic bag UFG 26 M 8 x 17 UFG 32 M 8 x 20... -
Page 6: Connection
Page -6- Assembly and Connection 3.2 CONNECTION NOTE: For assembly without hoses, please use two O-rings out of the little plastic bag to seal the oil feeding. Close the oil feedings which you won’t use with a suitable blind plug (M 6, R1/4”). 2 x R1/4”... -
Page 7: Proximity Switches
Page -7- Proximity Switches 4.1 NOTES ON PROXIMITY SWITCHES M 8 x 1 2 pieces Technical Data: – Supply voltage: 10 - 30 V DC Type Output Id.-No. – Operation voltage: max. 15 % INW 80/S Closer 301 508 – Max. load current: 200 mA Sensing distance 1.5 mm –... - Page 8 Turn the cyl. screw anti-clockwise: The positions on the switch are freely chooseable. – The control cam is moving away from the screw head. If SCHUNK proximity switches with plug-connectors Jamming piece Counter nut Control cam (max. 100 Ncm) (secured cyl.
-
Page 9: Maintenance
The jaws do not move: For exchange of components please return the – The hydraulic supply is interrupted. complete gripper with a repair order to SCHUNK. – Break of screws at the connection between the piston bar and the base jaw. -
Page 10: Optional: With Pneumatic Actuation
Page -10- Optional: with pneumatic actuation Pneumatic actuation for UFG 26 = Type UFG-P 26 Gripper side is identical pneumatic air with hydraulic version feeding side UFG 26 Note: If requested, we can supply a spare-and wear-part list. - Page 11 Page -11- Optional: with pneumatic actuation Pneumatic actuation for UFG 32 = Type UFG-P 32 Gripper side is identical pneumatic air with hydraulic version feeding side UFG 32 Note: If requested, we can supply a spare-and wear-part list.
- Page 12 Translation of original EC declaration of incorporation EC declaration of incorporation In terms of the EC Machinery Directive 2006/42/EC, annex II, Part B Manufacturer/ SCHUNK GmbH & Co. KG. distributor Spann- und Greiftechnik Bahnhofstr. 106 – 134 D-74348 Lauffen/Neckar We hereby declare that the following product:...
