- Page 1 Super Surge Brake Trailer Safety, Operation, Maintenance & Parts Manual STRB-S LT70HD-R Sawmills Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. January 2003 Form #1116...
- Page 2 Printed in the United States of America. All rights reserved. No part of this manual may be reproduced in any form by any photographic, electronic, mechanical or other means or used in any information storage and retrieval system without written permission from Wood-Mizer 8180 West 10th Street Indianapolis, Indiana 46214...
-
Page 3: Table Of Contents
Table of Contents Section-Page SECTION 1 SURGE BRAKE HITCH Operation ........................1-1 Maintenance ......................2-1 SECTION 2 PARTS LISTS Trailer Axle Assembly, Surge Brake................. 3-3 Outriggers ........................3-5 Outrigger Assembly, Long (LT70HD & Remote) ............ 3-6 Outrigger Assembly, Front..................3-7 Outrigger Assembly, Front.................. - Page 4 SB70-R03doc091317 Table of Contents...
-
Page 5: Surge Brake Hitch
Surge Brake Hitch Operation SECTION 1 SURGE BRAKE HITCH Operation IMPORTANT! Your vehicle should be equipped with a Class hitch with a solid 2 5/16” ball (not two-piece) and rated for at least 6000 pounds (2722 kg). The hitch should be correctly mounted to the towing vehicle so that it will be able to pull this type of load. - Page 6 Surge Brake Hitch Operation place. Use the hitch only with the specified ball size. Fail- ure to do so may result in serious personal injury and/or severe machine damage. 3. Cross the safety chains underneath the hitch and hook to the vehicle. The chains should be connected so that there is still slack in the chains when the vehicle is turned sharply in either direction.
- Page 7 Surge Brake Hitch Operation WARNING! Always check trailer tires for proper inflation before towing sawmill. Failure to do so may lead to tire fail- ure resulting in property damage and/or serious injury or death. Surge Brake Hitch SB70-R03doc091317...
-
Page 8: Maintenance
Maintenance Maintenance 1. Clean and repack the trailer axle wheel bearings with lithium grease every 12 months or 12,000 miles (19,308 km), whichever comes first. 2. Make sure that the trailer tires are correctly inflated to the pressure shown on the tire. CAUTION! Always check trailer tires for proper inflation before towing sawmill. - Page 9 Maintenance 5. Replace the adjusting hole cover and lower the wheel to the ground. 6. Repeat the above procedure on all brakes. For best results, the brakes should all be set at the same clearance. The wheel nut torque should be 90lbs.-ft. Tighten in 3 stages. See Table 1-1.
- Page 10 Maintenance If applicable, grease the Fine Adjust Outriggers (FAOs) every 200 hours of operation or once a month, whichever comes first. Use one squeeze of a NLGI No. 2 grade lithium grease from a grease gun to lubricate the outrigger and remove any sawdust. See Figure 1-3.
-
Page 11: Parts Lists
Parts Lists Trailer Hitch Assembly, Surge Brake SECTION 2 PARTS LISTS Trailer Hitch Assembly, Surge Brake SM0184C DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. HITCH WELDMENT, SURGE BRAKE (LT70-R) Chain, Safety w/Hook A07563 Actuator, Dico Surge Brake Hitch P09840 Bolt, Surge Brake Latch P10119... - Page 12 Parts Lists Trailer Hitch Assembly, Surge Brake Bolt, 1/2-13 X 4 1/2" Hex Head Grade 5 F05008-35 Nut, 1/2-13 Hex Nylon Lock F05010-8 BOLT, 58-11 X 6" HEX HEAD GRADE 5 F05009-22 WASHER, 5/8” SAE FLAT F05011-5 NUT, 5/8-11 NYLON LOCK F05010-34 WASHER, 5/8”...
-
Page 13: Trailer Axle Assembly, Surge Brake
Parts Lists Trailer Axle Assembly, Surge Brake Trailer Axle Assembly, Surge Brake SM0275B DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. PLUMBING KIT, LT40/70 LENGTH SURGE BRAKE K10049 AXLE ASSEMBLY, 5200 LB SURGE BRAKE (LT70-R) Mount Bracket, Trailer Fender (requires welding) W09784 Parts Lists SB70-R03doc091317... - Page 14 Parts Lists Trailer Axle Assembly, Surge Brake Shoe/Lining Kit, 10” x 2 1/4” Brake 010180 Plate, Trailer Axle Shackle M07528 Bolt, 9/16-8 X 3" Shackle P04644 Nut, 9/16-8 Shackle P04643 Nut, 1/2-20 Wheel Lug P04646 BOLT, 1/2-13 X 4” HEX HEAD F05008-26 WASHER, 1/2”...
-
Page 15: Outriggers
Parts List Outriggers Outriggers LT70HD Rev. A1.00+ 600288 DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. OUTRIGGER ASSEMBLY, LONG (See Section 2.4) 012997 OUTRIGGER ASSEMBLY, LONG (See Section 2.4) 012997 OUTRIGGER ASSEMBLY, SHORT (See Section 2.7) A04278 OUTRIGGER ASSEMBLY, SHORT W/JACK HOLDER (See Section 2.9) -
Page 16: Outrigger Assembly, Long (Lt70Hd & Remote)
Parts List Outrigger Assembly, Long (LT70HD & Remote) Outrigger Assembly, Long (LT70HD & Remote) LT70HD Rev. A1.00+ 3H0807B DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. OUTRIGGER ASSEMBLY, LONG 012997 Guide, Long Outrigger Guide 012996 Leg, Outrigger 016401 Cap, Outrigger Leg P09926... -
Page 17: Outrigger Assembly, Front
Parts List Outrigger Assembly, Front Outrigger Assembly, Front LT70HD Rev. A1.00+ LT70HD Remote Rev. A9.00+ SM0336-1C DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. OUTRIGGER ASSEMBLY, FRONT ADJUSTABLE 003944 Parts List SB70-R03doc091317... - Page 18 Parts List Outrigger Assembly, Front Mount Weldment, Front Adjustable Outrigger 003943 Seal, Outrigger Acme Screw 039641 Bearing Assembly, Adjustable Outrigger Thrust 039639 Bearing, Needle-Roller Thrust 039637 Washer, Thrust Bearing 039638 Sleeve, Outrigger Acme Screw 039645 Screw, 1-5 Adjustable Outrigger Long Acme 039642 Washer, 3/4"...
-
Page 19: Outrigger Assembly, Front
Parts List Outrigger Assembly, Front Outrigger Assembly, Front LT70HD Rev. A1.00+ LT70HD Remote Rev. A1.00 - A8.02 3H0805C DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. OUTRIGGER ASSEMBLY, FRONT 015143 Guide, Front Outrigger ‘97 Super 015144 Leg, Outrigger W07537 Cap, Outrigger Leg P09926... - Page 20 Parts List Outrigger Assembly, Front Pin, 3/4” Outrigger Pull 016147 Pin, 5/16" X 2 1/2" Roll F05012-47 Plate, Outrigger Pin Lock 064001 Pin, 3/16" X 1 1/2" Roll F05012-17 BOLT, 3/8-16 X 5” CARRIAGE HEAD F05007-113 WASHER, 3/8” SAE FLAT F05011-3 NUT, 3/8-16 HEX NYLON LOCK F05010-10...
-
Page 21: Outrigger Assembly, Short Front (Lt70Hd & Remote)
Parts List Outrigger Assembly, Short Front (LT70HD & Remote) Outrigger Assembly, Short Front (LT70HD & Remote) LT70HD Rev. A1.00+ SM0260B DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. OUTRIGGER ASSEMBLY, SHORT FRONT A04278 Guide, Short Front Outrigger Guide W09012 Leg, Outrigger W07537... - Page 22 Parts List Outrigger Assembly, Short Front (LT70HD & Remote) BOLT, 3/8-16 X 1 1/4” HEX HEAD F05007-2 WASHER, 3/8” FLAT F05011-3 NUT, 3/8-16 HEX NYLON LOCK F05010-10 3-12 SB70-R03doc091317 Parts List...
-
Page 23: Outrigger Assembly, Rear (Lt70Hd & Remote)
Parts List Outrigger Assembly, Rear (LT70HD & Remote) Outrigger Assembly, Rear (LT70HD & Remote) LT70HD Rev. A1.00+ 3H0808D DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. OUTRIGGER ASSEMBLY, LT40 REAR A12083 Guide, Short Rear Outrigger Guide W12082 Leg, Outrigger W07537 Cap, Outrigger Leg... - Page 24 Parts List Outrigger Assembly, Rear (LT70HD & Remote) BOLT, 3/8-16 X 1 1/4” CARRIAGE HEAD F05007-11 WASHER, 3/8” FLAT F05011-3 NUT, 3/8-16 HEX NYLON LOCK F05010-10 REFLECTOR, 2” DIAMETER RED P07452 REFLECTOR, 2” DIAMETER AMBER P07453 Pin Assembly 007736 with Lock Plate 064001 replaces Pin Kit 016148 on Front and Rear outrigger assemblies to prevent pin from vibrating loose (12/09) .
-
Page 25: Outrigger Assembly, Short Rear (Lt70Hd & Remote)
Parts List Outrigger Assembly, Short Rear (LT70HD & Remote) Outrigger Assembly, Short Rear (LT70HD & Remote) LT70HD Rev. A1.00+ SM0261B DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. OUTRIGGER ASSEMBLY, SHORT REAR A09475 Guide, Short Rear Outrigger Guide W09474 Leg, Outrigger W07537... - Page 26 Parts List Outrigger Assembly, Short Rear (LT70HD & Remote) Pin, 5/16" X 2 1/2" Roll F05012-47 Pin, 3/16" X 1 3/4" Roll F05012-103 SCREW, 3/8-16 X 1 1/4” HEX HEX CAP F05007-2 WASHER, 3/8” FLAT F05011-3 NUT, 3/8-16 HEX NYLON LOCK F05010-10 HANDLE, OUTRIGGER LIFT S04827...
-
Page 27: Trailer Lights
Parts List Trailer Lights 2.10 Trailer Lights LT70HD Rev. B1.00+ LT70HD Super Rev. A1.00+ SM0354-2B DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. PLUG, TRAILER LIGHT MALE P04159 PLUG, TRAILER LIGHT FEMALE P04983 LIGHT ASSEMBLY, TRAILER TAIL LED 006391 GROMMET, 6 1/2”... -
Page 28: Trailer Lights
Parts List Trailer Lights 2.11 Trailer Lights LT70HD Rev. A1.00 - A9.00 SM0089C 9 10 DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. PLUG, TRAILER LIGHT MALE P04159 PLUG, TRAILER LIGHT FEMALE P04983 LIGHT ASSEMBLY, TRAILER TAIL P04294 Lens, Grote Tail Light #90012 P12509... -
Page 29: Wrench Bracket Assembly
Parts List Wrench Bracket Assembly 2.12 Wrench Bracket Assembly SM0382 DESCRIPTION ( INDICATES PARTS AVAILABLE IN ASSEMBLIES ONLY) PART # QTY. BRACKET ASSEMBLY, FAO WRENCH 075717 Strap, Rubber 6 016542 Bracket, FAO Wrench Mount 075710 Bolt, 1/4-20 x 1 1/4” Hex Head Full Thread Cap F05005-3 Nut, 1/4-20 Nylon Lock F05010-69...
