- Page 1 830VS Milling Machine Operation Manual Chester UK Ltd Clwyd Close Hawarden Industrial Park Hawarden Chester CH5 3PZ Tel: 01244 531631 sales@chestermachinetools.com www.chestermachinetools.com Safety Rules...
- Page 2 Warning: Failure to follow these rules may result in serious injury. 1. For your own safety, carefully read this instruction manual before operating the machine, learn the machines application and limitations as well as the specific hazards associated with this type of machine. 2.
-
Page 3: Grounding Instructions
22. Make sure that the machine is disconnected from the power supply while the motor is mounted, connected or disconnected. Grounding Instructions In the event of a malfunction or a breakdown, grounding provides a path of least resistance for the electrical current to reduce the risk of electric shock. This machine has been equipped with an electric cable with an equipment-grounding conductor and a grounding plug. -
Page 4: Specifications
Specifications Spindle Taper Spindle Travel 88.9mm Spindle Speed 200-2250rpm Distance Spindle to Table Surface 57-510mm Size of Worktable 205x760mm Size of T-Slots 14mm Number of T-Slots Maximum Longitudinal Travel of Table 470mm Maximum Cross Travel of Table 200mm Vertical Travel of Table 455mm Leadscrew for Drill Chuck 3mm Pitch... -
Page 5: Installation
Installation Install this machine on a solid, level foundation, ensure that space is provided around the machine to allow for the movement of the head in the horizontal axis and to allow for maintenance to the electrical system. Cleaning and Lubricating the Machine Once the machine is in position, thoroughly clean the machine with kerosene or other non-flammable cleaning solutions. - Page 6 The table clamping levers are located in front of the saddle and should always be clamped when longitudinal movement is required. The knee clamping lever is located on the left side of the knee, leave the knee clamped at all times unless the knee is in operation. Motor Mounting and Shifting Belts for Speed The motor is mounted on a plate that is secured on the pulley housing.
- Page 8 Part Description Part Description Lock Knob Shaft Washer Lock Block (L) **** Spring Spline Shaft Lock Blocks (S) Bearing Cover Screw Bearing 6209ZZ Lock Nut S-Ring 45 Height Nut C-Ring 85 Block Head Casting M5-15 Pan Head Screw 1/2" Nut Handwheel 1/2"...
- Page 10 Part Description Part Description 5x5x40 Key **** **** **** M6-8 Set Screw **** **** **** M8x-20 Cap Screw Lower Belt Cover M8 Washer M6-35 Screw Motor M6 Washer M16-75 Screw Latch M16 Nut M3-8 Pan Head Screw Bracket M5-8 Pan Head Screw 1/2"...
- Page 12 Part Description Part Description Handle M5-30 Pan Head Screw 5/8" Nut Adjsuting Screw M6-8 Set Screw Handle Bar Handle Table Locking Screw Dial M6-16 Cap Screw Dial Positioning Screw M5 Nut M6-25 Cap Screw M5-10 Ppan Head Screw Spacer Rubber Sheet S-Ring 20 Bearing 6004ZZ M5-25 Cap Screw...
- Page 14 Part Description Part Description **** Bearing Housing **** Cross Leadscrew Column Bearing 6204zz Lamp Assembly Leadscrew M6-8 Cap Screw Pedestal Cover Lock Screw Holder Oil Joint Machine Base Knee Cover Knee Cover Limit Block M3-6 Pan Head Screw Limit Track Handle Bar M10-30 Screw Oil Pump...
- Page 16 Part Description Part Description Set Nut M5-15 Pan Head Screw Dial Nozzle Hose M6-25 Cap Screw Pipe Union Power Feed Hose 3x3x30 Key Splash pan Stop W/Plunger Assembly M6-8 Pan Head Screw Auto Stop Switch M6-15 Pan Head Screw M6-16 Pan Head Screw M6 Washer M6 Washer Pump Motor...
