Page 1: Power Supply
Variable Regulated Power Supply Instruction Manual Model XP-85 Elenco Electronics, Inc. 150 W. Carpenter Avenue Wheeling, IL 60090 (847) 541-3800 http://www.elenco.com e-mail: elenco@elenco.com Copyright © 1992 Elenco Electronics, Inc. Revised 2002 REV-B 753285... -
Page 2: Specifications
INTRODUCTION The Model XP-85 is a solid-state DC power supply, continuously variable from 5-15VDC. The unit is precisely held to the desired output voltage by a special regulating circuit. Current capability is up to 2.5A. The unit features a fail-safe automatic overload protection circuit. Maximum output current is externally adjustable from .1 to 2.5A.
