CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when it is not in use.
Dust regularly with small brush or vacuum. Spills should be taken
care of immediately before they harden or stain with a slightly
dampened sponge.
Please make sure that you have all parts indicated before you
begin assembly of this item.
Part List and Hardware List
PIECE
DESCRIPTION
A
Back
B
Seat
C
Left side
D
Right side
E
Table top
F
Table leg
Support bar
G
QUANTITY
PIECE
DESCRIPTION
Allen nut
H1
2x
H2
Allen screw
2x
2x
H3
Screw
H4
Allen screw L
2x
H5
1x
Allen screw S
2x
H6
Extra bolt
H7
Allen key
1x
MODEL# PAT6749
Product Dimension:
Bench : 52.36"W x 24.02"D x 29.53"H
Table : 23.62"W x 23.62"D x 21.65"H
Weight capacity bench : 600 lbs , Table : 40 lbs.
Warning : Do not stand on the bench or table
Warning : Do not torque bolts / screws
QUANTITY
8x
M6x90
8x
M6x60
4x
M4x15
4x
M6x90
2x
M6x40
1x
M6x50
1x
