- Page 1 User’s FC800D Manual Non-reagent Type Free Available Chlorine Sensor Unit Start-up and Safety Precautions IM 12F05B10-01EN IM 12F05B10-01EN 2nd Edition...
- Page 2 Thank you for purchasing FC800D Non-reagent type Free Available Chlorine Sensor Unit. This User’s Manual contains all essential information for the user to make full use of FC800D. Please read the following respective documents before installing and using the instrument.
-
Page 3: Trademark Acknowledgements
• No part of the user’s manuals may be transferred or reproduced without prior written consent from YOKOGAWA. • YOKOGAWA reserves the right to make improvements in the user’s manuals and product at any time, without notice or obligation. • If you have any questions, or you find mistakes or omissions in the user’s manuals, please contact our sales representative or your local distributor. - Page 4 Control of Pollution Caused by the Product This is an explanation for the product based on “Control of Pollution caused by Electronic Information Products” in the People’s Republic of China. 产品中有害物质的名称及含量 有害物质 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr (VI))
-
Page 5: Safety Precautions
Safety Precautions WARNING Installation and wiring The FC800D should only be used with equipment that meets the relevant IEC, American or Canadian standards. Yokogawa accepts no responsibility for the misuse of this unit. Don’t install “general purpose type” instruments in the hazardous area. -
Page 6: Warning And Disclaimer
The product is provided on an “as is” basis. YOKOGAWA shall have neither liability nor responsibility to any person or entity with respect to any direct or indirect loss or damage arising from using the product or any defect of the product that YOKOGAWA can not predict in advance. IM 12F05B10-01EN... -
Page 7: Compliant Standards
Compliant Standards Safety: EN 61010-1, EN 61010-2-030 UL 61010-1, UL 61010-2-030 CSA-C22.2 No.61010-1 CSA-C22.2 No.61010-2-030 GB30439 Installation altitude: 2000 m or less Overvoltage Category based on IEC 61010: II (*) Pollution level: IEC 61010: 2 (**) Installation category, called over-voltage category, specifies impulse withstand voltage. Equipment with Category II is energy-consuming equipment to be supplied from the fixed installation. -
Page 8: Instrument Check
If damage is found, retain the original packing materials (including the outer box) and then immediately notify the carrier and the relevant Yokogawa sales office. Make sure the model and suffix code on the nameplate match your order and the necessary accessories are included. -
Page 9: Wiring And Installation
● allows for drainage. For information on FLXA402T, read the user’s manual. Install the FC800D’s converter and sensor unit in pipes, racks or walls using their special mounting brackets, respectively. Note that these mounting brackets are supplied only when specified. Refer to General Specifications (GS 12F05B10-01EN) for details. - Page 10 <Start-up and Safety Precautions> 67.5 210.5 Unit: mm Maintenance space Maintenance space 2B pipe (Ø60.5) Needle valve Flow cell Sample intle Drain outlet (Tube size Ø15 ID hose coupling) (Rc1/4) IM 12F05B10-01EN 2nd Edition : June 01, 2021-00...
- Page 11 Use the plate with Terminal Box to provide wiring. When wiring FC800D, first remove the cover of the smart box, then attach the cable gland. After the wiring completes, install the shield cover securely. Refer to user’s manual IM 12F05B10- 02EN for details.
- Page 12 See GS 12F05B10-01EN ● Solenoid valve (SV1). CAUTION Turn off power supply to FC800D before wiring. Power rating must comply with FC800D specifications. Power voltage must match with the one indicated on the name plate. IM 12F05B10-01EN...
- Page 13 ● The external power supply switch or a circuit breaker must comply with a current rating of 5Aor IEC60947-1 or IEC60947-3 ● Yokogawa recommend installing the external power supply switch, circuit breaker and FC800D all in the same location. ● Install the external power supply switch or circuit breaker to the place where operators access easily.
-
Page 14: Wiring The Power Supply
B: Power FLXA402T – Smart unit L(201) C: Power intput N(202) (002)G Wiring of FC800D (/TB) Terminal Box for connecting solenoid valve Refer to IM 12F05B10-02EN. Wiring of FLXA402T Refer to FLXA402T Installation and Wiring IM 12A01G01-02EN. Wiring the power supply The cable size of terminals is 0.13 to 2.5 mm... -
Page 15: Operation
CAUTION Never use harsh chemicals or solvents. If the instrument does become heavily stained or scratched, you may need to replace some parts. Consult Yokogawa. Fuse There is a circuit board mounted fuse protecting the instrument. If a fuse blows soon after the change, contact Yokogawa. -
Page 16: Revision Record
June 2021/2nd Edition Revised compliant standards (p.4, 7) Added a code to Model and Suffix Codes (p.8) Mar. 2021/1st Edition Newly released. Yokogawa Electric Corporation 2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, JAPAN http://www.yokogawa.com/ IM 12F05B10-01EN 2nd Edition : June 01, 2021-00...
