Denlar DESIGNER Series Installation And User Manual

Hide thumbs Also See for DESIGNER Series:
Table of Contents

Advertisement

Quick Links

DESIGNER SERIES MODELS
INSTALLATION AND USER'S MANUAL
MODELS:
READ AND SAVE THESE
DS-30-F
INSTRUCTIONS
DS-30-D
DS-30-D-IF
https://www.denlarhoods.com/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESIGNER Series and is the answer not in the manual?

Questions and answers

Related Manuals for Denlar DESIGNER Series

Summary of Contents for Denlar DESIGNER Series

  • Page 1 DESIGNER SERIES MODELS INSTALLATION AND USER’S MANUAL MODELS: READ AND SAVE THESE DS-30-F INSTRUCTIONS DS-30-D DS-30-D-IF https://www.denlarhoods.com/...
  • Page 2 Use this unit in the manner intended by the Manufacturer. If you have questions or concerns, please contact Denlar Service at 860-526-9846 or service@denlarhoods.com. Before servicing the Hood, turn off power at the Main Breaker Panel. Ensure the Breaker is locked- out/tag-out in accordance with local codes.

  • Page 3: Table Of Contents

    DESIGNER SERIES SCHEMATIC DESIGNER SERIES DEVICE FLOW CHART For the Warranty Statement please visit https://www.denlarhoods.com/. For installation or service calls please contact Denlar Service at 860-526-9846 or at service@denlarhoods.com. For sales questions, please contact Denlar Sales at 860-526-9846 or at sales@denlarhoods.com.

  • Page 4: Hood Specifications

    HOOD SPECIFICATIONS LAB-110246 REV 20210312...

  • Page 5: Hood Layout

    HOOD LAYOUT LAB-110246 REV 20210312...

  • Page 6: Elevation Layout

    ELEVATION LAYOUT DS-30-F DS-30-D DS-30-D-IF LAB-110246 REV 20210312...

  • Page 7: Mounting Layout

    MOUNTING LAYOUT A. DENLAR Designer Series Hood(DS-30) B. Range (for reference purposes (Gas, Electric or Dual Element) C. Electric Power disconnect (shown) D. Gas Power Disconnect (not shown) E. The CLOCKBOX range element lockout system (CLBX option) The Touchscreen (E) is shown, the control module is not shown.
  • Page 8 MOUNTING LAYOUT The Hood has two options for mounting. There are four mounting holes in the top and rear of the unit. If a cabinet is installed above the Hood with top discharge or an inline fan, then a 7” hole is needed in the cabinet.

  • Page 9: Power Connections

    POWER CONNECTIONS Clock Box 120 VAC Input (not provided) CB1 / CB2 Control Box Touch Screen Electrical Disconnect 1. 120 VAC Input (not provided) a. 120 VAC / 15 Amp circuit (provided by installer) i. If a Clock Box is not used, connect the wire directly to the Hood, skip to Step 3. 2.
  • Page 10 POWER CONNECTIONS See Power Connections on Page 8 3. 120 VAC Input Power Cable (not provided) a. Remove the side cover of the Hood, there is a six-position connector in the compartment. The wire combination is Brown, White, Green, Green, White, and Blue. The mating connector is attached to the plug.
  • Page 11 POWER CONNECTIONS See Power Connections on Page 8 5. Cable (not provided) to provide 120 VAC from the Main Breaker Panel to the Clock Box (if applicable) a. Connect the 120 VAC Output Cable to the Installer Side of eight (8) position Power Plug in the Clock Box Control Box i.

  • Page 12: Operating The Designer Series Hood

    OPERATING THE DESIGNER SERIES HOOD The Designer Series Hood is equipped with two switches. The Switch on the right is for the two lights in the Hood. The switch on the left is for the fan motor. This switch is a three-position rocker switch.

  • Page 13: Manual Pull Station Installation (Mpk)

    MANUAL PULL STATION INSTALLATION (MPK) STEP 1: INSTALLING CONDUIT Mount the Pull Box in an appropriate location according to local building codes. The MPK is supplied with 25 Ft of wire rope cable and three Elbow Pulleys as our listing requires.

  • Page 14: Alarm Connections

    ALARM CONNECTIONS The Designer Series Hood offers a set of Normally Open (NO) or Normally Closed (NC) Contacts to connect to an alarm panel. To access the connection, remove the side cover, there are three red wires inserted into a Four-Position Connector, this mating connector is plugged into the four-position connector.

  • Page 15: Range Element Disconnect Installation

    RANGE ELEMENT DISCONNECT INSTALLATION DS-G Installation Gas Solenoid Disconnect 1. Secure the gas line input and output to the DS-G. The fittings are 3/8” NPT. Make note of the direction of the flow, there is an arrow on the bottom of the DS-G. 2.

  • Page 16: Range Element Schematic

    RANGE ELEMENT DISCONNECT SCHEMATIC DS-G DS-E-220 LAB-110246 REV 20210312...
  • Page 17 RANGE ELEMENT DISCONNECT SCHEMATIC DS-E-120 DS-DED-120/220 LAB-110246 REV 20210312...

  • Page 18: Handicap Accessible Control (Ada)

    HANDICAP ACCESSIBLE CONTROL (ADA) COMPONENTS • ADA Wire Harness Assembly o (2) Toggle Switches (white) o (1) Metal 2-Gang Enclosure o (15 ft) Plenum Cable Encased in 16mm ENT Flexible Conduit o (1) Eight-Position Male Connector (Plug-N-Play) o (1) 2-Gang White Switch Cover o (2) Mounting Brackets PREPARATION Turn OFF the supply line 110-120 VAC power (at the panel) to the Hood.
  • Page 19 HANDICAP ACCESSIBLE CONTROL (ADA) LAB-110246 REV 20210312...

  • Page 20: Tank Removal

    If a Manual Pull Station is installed, remove the swivel hook from the glass link. Using a 3/8” socket or Nut Driver, remove the two Tank Securing Nuts. The Designer Series Tank Assembly can be removed safely at this time. To reinstall the Designer Series Tank Assembly, reverse this process.

  • Page 21: Designer Series Testing

    DESIGNER SERIES TESTING Testing the Designer Series Hood Fan and Light 1. Turn the Light Switch ON and ensure both lights turn ON. 2. Turn the Light Switch OFF and ensure both lights turn OFF. 3. The Fan Switch is a Three-Position rocker switch.
  • Page 22 If a Manual Pull Station is installed, remove the swivel hook from the glass link. d. Using a 3/8” socket or Nut Driver, remove the two Tank Securing Nuts. The Designer Series Tank Assembly can be removed safely at this time.

  • Page 23: Designer Series Service

    DESIGNER SERVICE Before servicing the Designer Series Hood, install the Safety Pin for the tank to prevent an accidental discharge. Inspection: 1. Verify that all components are clean, non-damage, and have no corrosion. Corrosion could be a sign that there is an issue with the tank.

  • Page 24: Designer Series Schematic

    DESIGNER SERIES SCHEMATIC LAB-110246 REV 20210312...

  • Page 25: Designer Series Device Flow Chart

    DESIGNER SERIES DEVICE FLOW CHART LAB-110246 REV 20210312...

This manual is also suitable for:

Ds-30-fDs-30-dDs-30-d-if
