2. ADJUSTING SHOE ANGLE
The angle of the shoe can be adjusted to allow for bevel cuts
between 0 and 45°.
1 Loosen the 2 screws at the
bottom of the jigsaw using
the hex key.
2 Slide the shoe
backwards to allow
the shoe to rotate.
3 Tilt the shoe to the
desired angle using the
measurements.
4 Once the angle is
correct, slide the
shoe forward for the
pin to make contact.
5 Secure in place tightening
the 2 screws at the bottom
of the jigsaw.
2
1
3
0
2
1
3
0
2
1
3
0
2
1
3
0
2
1
3
0

3. ATTACHING THE ACCESSORIES

Attaching the Parallel Guide
The parallel guide assists in cutting in a line parallel to an edge.
1 Unscrew the 2 guide
locking screws at the
front of the jigsaw.
2 Slide the parallel guide into
the slots under the locking
screws.
3 Tighten the guide
locking screws to
secure position.
2
1
3
0
2
1
3
0
2
1
3
0
