FIRST TEAM SPORTS, INC

Uni-Sport Series Assembly Instructions

Bill of Materials

A (4) ½" Lock washer

B (1) Extension Arm

C (2) Backboard Brace

D (1) Clamp Bar

E (2) 3/8" Hex Nut

F (2) 4" U-Bolt

G (1) 2" U-Bolt

H (1) Backboard Frame Support

NOTE: Immediately unpack all components and cross check against bill of materials. Report

any shortages to First Team customer service at 1-888-884-6677

I (4) ½" Hex Nut

J (2) 3/8" Flat washer

K (2) 3/8" Lock washer

L (2) 5/16" x 1" Machine Screw

M (2) 5/16" Flat washer

N (2) 5/16" Lock washer

O (2) 5/16" Hex Nut

Need help?

Do you have a question about the Uni-Sport Series and is the answer not in the manual?

Page 1 FIRST TEAM SPORTS, INC Uni-Sport Series Assembly Instructions Bill of Materials A (4) ½" Lock washer I (4) ½" Hex Nut B (1) Extension Arm J (2) 3/8" Flat washer C (2) Backboard Brace K (2) 3/8" Lock washer D (1) Clamp Bar L (2) 5/16"...
Page 2 Trim gaskets if necessary. 4. Attach backboard braces to side holes in backboard frame using 5/16" hardware provided. Bend braces to fit as necessary. 5. Tighten all bolts. FIRST TEAM SPORTS, INC. 902 COREY ROAD HUTCHINSON, KS 67501 TOLL FREE: 888-884-6677...
