Assembly Instruction - Launch TWC-401NIC Operation Manual

Electric Requirements
Max. Wheel Diameter
Max. Wheel Width
Outside Clamping—Rim sizes
Inside Clamping—Rim sizes
Max Inflation Pressure
Bead Breaker Force
Max Rotating Torque (Turntable)
Noise Level
Overall Dimensions (L x W x H)
Shipping Weight
Voltage
Frequency
Ambient Temperature
Operation Humidity
Installation altitude NOT exceed
Transport / Storage temperature
Fig.1
2-1 Transport
When transporting the machine it must be handle with a forklift truck with the forks
Positioned as show as in the Fig.1.
2-2 Unpacking
When unpacking, check to make sure all parts shown on the spare parts List/Assembly. Diagrams are included. If any parts are missing or broken,
please call the manufacturer or the dealer as soon as possible.
1. Technical Data
Model A
39"
13"
10" ~ 18"
12" ~ 20"
38.2" x30.3" x37.4"
(97x77x95cm)
220kg

2.ASSEMBLY INSTRUCTION

B
See the manufacturer's serial plate
42"
14"
11" ~ 21"
13"~ 23"
116PSI (8 Bar)
5500Lbs (2500kgs)
795 ft.lbs (1078N.m)
<70db
38.2" x30.3" x37.4"
(97x77x100cm)
230kg
0.9 ~ 1.1 of nominal voltage
0.98~1.02 of nominal frequency
5~40° C
30~95%
1000m
-25~55° C
