Silex technology MNS-300EM Command Manual

Hide thumbs Also See for MNS-300EM:
Table of Contents

Advertisement

Quick Links

Download this manual
MNS-300EM
Command Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MNS-300EM and is the answer not in the manual?

Questions and answers

Related Manuals for Silex technology MNS-300EM

Summary of Contents for Silex technology MNS-300EM

  • Page 1 MNS-300EM Command Manual...
  • Page 2 Copyright© 2019 silex technology, Inc. All rights reserved. WA105840XB...

  • Page 3: Table Of Contents

    Index 1. Introduction ............1 1-1. Introduction ..................2 MNS-300EM User's Manuals ............. 2 Disclaimers ....................2 Trademarks ..................... 3 1-2. Product Information and Customer Services ......4 Product Information ................4 Customer Support Center ..............4 2. How to Access Command Console ......5 3.
  • Page 4 4-1-2. SET NW RTS .................12 4-1-3. SET NW SSid ................13 4-1-4. SET NW STARTdelay ..............13 4-1-5. SH NW WLLIST ................14 4-1-6. SH NW PROFILE ................14 4-1-7. SET NW PROFCFG ..............15 4-1-8. SET NW PROFACT ..............15 4-2. Wireless LAN Security Commands ..........16 4-2-1.
  • Page 5 4-2-15. SET NW CLCERT ...............23 4-2-16. SET NW CLKEY ................23 4-2-17. SET NW SSCCITY ..............24 4-2-18. SET NW SSCCOMNAME ............24 4-2-19. SET NW SSCCOUNTRY ............25 4-2-20. SET NW SSCKEYSIZE ...............25 4-2-21. SET NW SSCORGNAME ............26 4-2-22. SET NW SSCORGUNIT ............26 4-2-23.
  • Page 6 4-5-1. SET NW SWSPINCODE .............33 4-5-2. SET NW SWSPBC ................33 4-5-3. SET NW SWSPBC NOWAIT ............33 4-5-4. SET NW SWSPIN .................34 4-6. TCP/IP Settings in Station Mode ..........35 4-6-1. SET IP MEthod ................35 4-6-2. SET IP ADdress ................35 4-6-3. SET IP SUbnet ................36 4-6-4.
  • Page 7 5-12. SET MEsh [profile_num] REFInterval ........44 5-13. SET MEsh [profile_num] POWer ..........44 5-14. SET MEsh [profile_num] IPMEthod ..........45 5-15. SET MEsh [profile_num] IPADdress .........45 5-16. SET MEsh [profile_num] IPSUbnet ...........45 5-17. SET MEsh [profile_num] IPROuter ...........46 5-18. SET MEsh [profile_num] DNSPRImary ........46 5-19.
  • Page 8 6-1-11. SET PORT S1 SPeed ..............55 6-1-12. SH PORT S1 STAtus ..............56 6-1-13. SET PORT S1 STOP ..............56 6-2. Ecable Port Command ..............57 6-2-1. SET PORT S1 ECABLE ..............57 6-2-2. SH PORT S1 ECABLE ..............57 6-2-3. SET PORT S1 ECADDR ..............58 6-2-4.
  • Page 9 7-7. SET SERVEr NAme ................67 7-8. SH SERVEr STAtistics ................67 7-9. SH SERVEr QUEue ................68 7-10. SH SNMP ...................68 7-11. SET SNMP CONtact ................69 7-12. SET SNMP GETCOMM ..............69 7-13. SET SNMP LOCation ..............69 7-14. SET SNMP SETCOMM2 ..............70 7-15. SH VErsion ..................70 8.
  • Page 10 8-13. SH SERVI PRI [service_num] ............78 8-14. SET SERVI <service name> QUEue ..........78 8-15. SET SERVI <service name> RECeive ........79 8-16. SET SERVI <service name> TCP ..........79 8-17. SH SERVI SUMmary [service_num] ..........80 9. String Commands ..........81 9-1. SET STRing ..................82 9-2.
  • Page 11 10-12. SET IP FTIme ..................91 10-13. SET IP REtry ..................91 10-14. SET IP STATus .................92 10-15. SET IP WIndow ................92 10-16. SET IP BAnner ................93 11. DNS Commands ..........95 11-1. SH DNS ....................96 11-2. SET DNS DOMain ................96 11-3. SET DNS PRImary ................97 11-4.
  • Page 12 13-8. SH GPIO SPECM ................107 13-9. SET GPIO DATA ................108 13-10. SH GPIO DATA ................109 14. Bluetooth Commands ........111 14-1. SH BT ....................112 14-2. SET BT ....................112 14-3. SET BT PASSkey ................113 15. Firmware Update Commands ......115 15-1. SET LOAd XModem ..............116 16.

  • Page 13: Introduction

    1. Introduction Introduction Thank you for purchasing the Intelligent Module MNS-300EM...

  • Page 14: Introduction

    MNS-300EM User's Manuals MNS-300EM has the following user's manuals: MNS-300EM Command Manual (this document) This document describes the console commands that can be used on MNS-300EM. MNS-300EM Setting Manual This document explains the functions and configuration methods of MNS-300EM. MNS-300EM Embedded Manual This document describes the specifications and procedures for embedding MNS-300EM into the customer's device (hereinafter "target device").

  • Page 15: Trademarks

    1. Introduction Trademarks • Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. • Wi-Fi, Wi-Fi Protected Access (WPA), WPA2 are either registered trademarks or trademarks of Wi-Fi Alliance. • Other brand or product names are registered trademarks or trademarks of their respective owners.

  • Page 16: Product Information And Customer Services

    If you cannot find the relevant problem in this manual or on our website, or if the corrective procedure does not resolve the problem, please contact Silex Technology Customer Support. Contact Information +1-657-218-5199 support@silexamerica.com Europe +49-2154-88967-0 support@silexeurope.com • Refer to the Silex Technology website ( https://www.silextechnology.com/ ) for the latest FAQ and product information. Note...

  • Page 17: How To Access Command Console

    • Configuration console port • Linux console port In addition to the above, the Web console function can be used from MNS-300EM's Web page. Whichever method is used to access the command console, the setting method is the same unless otherwise noted.
  • Page 18 MNS-300EM Command Manual (Blank page)

  • Page 19: Network Commands

    3. Network Commands Network Commands This chapter describes the network parameter commands.

  • Page 20: Set Nw Wired

    MNS-300EM Command Manual 3-1. SET NW WIRED Sets the wired LAN link mode. SET NW WIRED <mode> Choose one of the followings for <mode>. AUTO : Auto mode FD100BASE : 100Base FULL 100BASE : 100Base Half FD10BASE : 10Base FULL...

  • Page 21: Set Nw Mode

    3. Network Commands 3-3. SET NW MOde Sets the wireless LAN mode. SET NW MOde [STation | MEsh | AUto] Choose one of the followings for the wireless LAN mode: STation : Operates in Station (wireless client) mode. MEsh : Operates in Mesh Point mode. : Operates in either Station mode or Mesh Point mode depending on the wireless AUto environment.

  • Page 22: Sh Nw Sq

    MNS-300EM Command Manual 3-5. SH NW SQ Shows the radio quality of the wireless LAN link. SH NW SQ Signal Quality is a number (0-100) to show the relative quality of the wireless link. Signal Strength shows RSSI value [dBm] calculated for the current connection.

  • Page 23: Station Commands

    4. Station Commands Station Commands This chapter describes the commands to use for the Station mode settings.

  • Page 24: Wireless Lan Commands

    MNS-300EM Command Manual 4-1. Wireless LAN Commands The following describes the general wireless configuration commands for Station mode. 4-1-1. SET NW RADio Changes the wireless standard. SET NW RADio [802.11A-N-ac | 802.11B-G-N | 802.11A-B-G-N-ac] Choose one of the followings for the wireless standard: 802.11A-N-ac...

  • Page 25: Set Nw Ssid

    4. Station Commands 4-1-3. SET NW SSid Sets the SSID of the wireless LAN. SET NW SSid <name> Enter the SSID (1-32 characters) for <name>. For the SSID, alphanumeric character, hyphen (-) and underscore (_) can be used. The factory default value is serserv. Sample output: Local>...

  • Page 26: Sh Nw Wllist

    MNS-300EM Command Manual 4-1-5. SH NW WLLIST Shows the wireless LAN networks nearby. This displays only the Access Points which broadcast their SSIDs. When a stealth function is enabled on the Access Point, such Access Point will not be detected.

  • Page 27: Set Nw Profcfg

    For <n>, enter the number of wireless profile (1-4) to save the setting into. When an unused wireless profile is chosen, the previous wireless settings will be inherited. Since this setting is not saved, a value set by PROFACT will be applied after MNS-300EM restarts.

  • Page 28: Wireless Lan Security Commands

    MNS-300EM Command Manual 4-2. Wireless LAN Security Commands The following describes the commands that change the wireless LAN security. 4-2-1. SET NW AUTHtype Changes the wireless LAN authentication method. SET NW AUTHtype [OPEN | TLS | TTLS | LEAP | PEAP | EAP-FAST | PSK] Choose one of the followings for the wireless LAN authentication method.

  • Page 29: Del Nw Certs

    DEL NW CERTS This command deletes host certificates, client certificates, and private key information of the profiles stored in MNS-300EM as well as PAC files dynamically provided by EAP-FAST authentication server. The actual deletion process is performed when settings are saved.

  • Page 30: Set Nw Key

    MNS-300EM Command Manual 4-2-4. SET NW KEY# Chooses the key index of WEP key for the wireless LAN. SET NW KEY# <n> For <n>, specify the key index number of WEP key to use (1 to 4). The factory default value is 1.

  • Page 31: Set Nw Wpapsk

    4. Station Commands 4-2-7. SET NW WPAPSK Sets the Pre-Shared Key of WPA. SET NW WPAPSK <key> For <key>, enter a passphrase with 8-63 characters, or 64 hexadecimal digits (256-bit PSK value). The value is used when the wireless LAN authentication method is PSK. The factory default value is Device Server.

  • Page 32: Set Nw Pw

    MNS-300EM Command Manual 4-2-9. SET NW PW Sets the password to be used for 802.1x EAP authentication. SET NW PW <password> For <password>, enter a string with 1-32 alphanumeric characters. The factory default value is anonymous. Example: Local> SET NW PW eappassword 4-2-10.

  • Page 33: Set Nw Peapmschap

    4. Station Commands 4-2-11. SET NW PEAPMSchap This is a test command to force MSCHAP to be used on phase 2 of the PEAP authentication handshake. SET NW PEAPMSchap [ENable | DISable] Enable/Disable mandatory use of MSCHAP. ENable : Enables mandatory use of MSCHAP. DISable : Disables mandatory use of MSCHAP.

  • Page 34: Set Nw Peapv0

    The factory default value is DISable. SH NW PEAPV0 can show the current setting 4-2-13. SET NW PKPASS Changes the password of private key file to be registered to MNS-300EM. SET NW PKPASS <passphrase> For <passphrase>, enter a string with 8-63 alphanumeric characters.

  • Page 35: Set Nw Cacert

    4. Station Commands 4-2-14. SET NW CACERT Starts updating the CA certificate file by using XModem protocol. When this command is executed, the mode is changed to XMODEM mode. SET NW CACERT 4-2-15. SET NW CLCERT Starts updating the client certificate file by using XModem protocol. When this command is executed, the mode is changed to XMODEM mode.

  • Page 36: Set Nw Ssccity

    The factory default value is Orange County. Example: Local> SET NW SSCCITY "Kyoto City" • The value will be deleted when MNS-300EM restarts. 4-2-18. SET NW SSCCOMNAME Changes the common name of the self-signed certificate to be issued. SET NW SSCCOMNAME <"common name string">...

  • Page 37: Set Nw Ssccountry

    The factory default value is US. Example: Local> SET NW SSCCOUNTRY JP • The value will be deleted when MNS-300EM restarts. 4-2-20. SET NW SSCKEYSIZE Changes the key size (bit) of the self-signed certificate to be issued. SET NW SSCKEYSIZE [1024 | 2048] Choose one of the following values for the key size.

  • Page 38: Set Nw Sscorgname

    The factory default value is silex technology america. Example: Local> SET NW SSCORGNAME "silex technology japan" • The value will be deleted when MNS-300EM restarts. 4-2-22. SET NW SSCORGUNIT Changes the organization unit name of the self-signed certificate to be issued.

  • Page 39: Set Nw Sscstate

    The factory default value is CA. Example: Local> SET NW SSCSTATE "Kyoto" • The value will be deleted when MNS-300EM restarts. 4-2-24. SET NW SSCGEN Issues the self-signed certificate configured with the commands starting with SET NW SSC. SET NW SSCGEN The private key associated with the certificate will be saved as a client key or certificate of MNS-300EM.

  • Page 40: Wireless Lan Roaming Control

    MNS-300EM Command Manual 4-3. Wireless LAN Roaming Control The following describes the commands that change the roaming function settings. 4-3-1. SET NW BGSCAN Changes the interval of wireless background scans. SET NW BGSCAN <seconds> For <seconds>, enter the number of seconds (1-60) to specify the interval for scans.

  • Page 41: Set Rm Scan Norm

    4. Station Commands 4-3-3. SET RM SCAN NORM Changes the interval of normal wireless background scans. SET RM SCAN NORM <seconds> For <seconds>, enter the number of seconds (1-60) to specify the interval of background scans to run when the reception quality exceeds the roaming scan threshold value which represents the wireless link quality.

  • Page 42: Wireless/Wired Bridge Setting

    MNS-300EM Command Manual 4-4. Wireless/Wired Bridge Setting The following describes the commands that configure the wireless/wired LAN bridge setting. 4-4-1. SET NW BRIDGE Enables/Disables the wireless/wired bridge mode. SET NW BRIDGE [ ENable | DISable] ENable : Enables the bridge mode.

  • Page 43: Set Nw Braccess

    SET NW BRACC [ ENable | DISable ] ENable : Accepts an access to the configuration function. A client device connected to the wired LAN port of MNS-300EM can access the configuration function including the Web interface. DISable : Denies an access to the configuration function.

  • Page 44: Set Nw Brstatic

    BRCLADDR. DISable : Disables the static MAC address mode. MNS-300EM waits a packet on the wired LAN interface and uses the source address of that packet as the MAC address of wireless LAN interface. The factory default value is ENable.

  • Page 45: Smart Wireless Setup

    Executes the smart wireless setup using the PBC method. SET NW SWSPBC 4-5-3. SET NW SWSPBC NOWAIT Executes the smart wireless setup using the PBC method. SET NW SWSPBC NOWAIT When this command is executed, MNS-300EM does not wait for completion of the smart wireless setup.

  • Page 46: Set Nw Swspin

    MNS-300EM Command Manual 4-5-4. SET NW SWSPIN Executes the smart wireless setup using the PIN method. SET NW SWSPIN...

  • Page 47: Tcp/Ip Settings In Station Mode

    The factory default value is AUTO. 4-6-2. SET IP ADdress Specifies the IP address to use for Station mode. To assign a static IP address to MNS-300EM, use this command to specify the IP address. SET IP ADdress <aa.bb.cc.dd> Enter the IP address for <aa.bb.cc.dd>.

  • Page 48: Set Ip Subnet

    IP address for the number of times specified in <n>. When the IP address cannot be obtained for <n> times, MNS-300EM will operate with the static IP address configured by SET IP ADdress. The factory default value is 3.

  • Page 49: Mesh Commands

    5. Mesh Commands Mesh Commands This chapter describes the commands that change Mesh parameters. MNS-300EM can configure and save up to 5 Mesh profiles.

  • Page 50: Sh Mesh Profile [Profile_Num]

    MNS-300EM Command Manual 5-1. SH MEsh PROFILE [profile_num] Shows the Mesh profile settings of the specified number [profile_num]. SH MEsh PROFILE [profile_num] Sample output: Local> SH MEsh PROFILE 1 Mesh configuration list 　 Mesh profile: Enabled 　 Wlan mode: 11NG 　...

  • Page 51: Set Mesh Profselect [Profile_Num]

    5. Mesh Commands 5-2. SET MEsh PROFSELect [profile_num] Changes the Mesh profile number to use when the Mesh mode is on. SET MEsh PROFSELect [profile_num] The factory default value is 1. SH MEsh PROFSELect can show the current setting. 5-3. SET MEsh [profile_num] PROFile Enables/Disables the Mesh profile of the specified number [profile_num] when Auto mode is on.

  • Page 52: Set Mesh [Profile_Num] Mode

    MNS-300EM Command Manual 5-4. SET MEsh [profile_num] MOde Sets the wireless LAN mode to Mesh profile of the specified number [profile_num]. SET MEsh [profile_num] MOde [11G | 11NG | 11A | 11NA | 11AC] Choose one of the following wireless LAN modes.

  • Page 53: Set Mesh [Profile_Num] Channel

    5. Mesh Commands 5-6. SET MEsh [profile_num] CHannel Sets the communication channel to Mesh profile of the specified number [profile_num]. SET MEsh [profile_num] CHannel <n> Specify the communication channel for <n>. The factory default value is 11. SH MEsh [profile_num] CHannel can show the current value. 5-7.

  • Page 54: Set Mesh [Profile_Num] Key

    Sets the Mesh encryption key to Mesh profile of the specified number [profile_num]. SET MEsh [profile_num] KEY <key> Specify the Mesh encryption key for <key>. The factory default value is silex technology, Inc. SH MEsh [profile_num] KEY can show the current value. Example: Local>...

  • Page 55: Set Mesh [Profile_Num] Refresh

    Sets the route refresh method for Mesh profile of the specified number [profile_num]. SET MEsh [profile_num] REFMethod [LIGHT | FULL] LIGHT : Rebuilds the route only to MNS-300EM. FULL : Rebuilds the route to and from MNS-300EM. The factory default value is LIGHT. SH MEsh [profile_num] REFMethod can show the current value.

  • Page 56: Set Mesh [Profile_Num] Refinterval

    MNS-300EM Command Manual 5-12. SET MEsh [profile_num] REFInterval Specifies the route refresh interval in seconds for Mesh profile of the specified number [profile_num]. SET MEsh [profile_num] REFInterval <n> For <n>, enter the number of seconds to specify the route refresh interval (1-86400).

  • Page 57: Set Mesh [Profile_Num] Ipmethod

    Sets the IP address to Mesh profile of the specified number [profile_num]. SET MEsh [profile_num] IPADdress <aa.bb.cc.dd> Enter the IP address for <aa.bb.cc.dd>. To assign a static IP address to MNS-300EM, use this command to specify the IP address. The factory default value is 0.0.0.0. 5-16. SET MEsh [profile_num] IPSUbnet Sets the subnet mask to Mesh profile of the specified number [profile_num].

  • Page 58: Set Mesh [Profile_Num] Iprouter

    MNS-300EM Command Manual 5-17. SET MEsh [profile_num] IPROuter Sets the default gateway to Mesh profile of the specified number [profile_num]. SET MEsh [profile_num] IPROuter <aa.bb.cc.dd> Enter the default gateway for <aa.bb.cc.dd>. The factory default value is 0.0.0.0. 5-18. SET MEsh [profile_num] DNSPRImary Sets the primary DNS server's address to Mesh profile of the specified number [profile_ num].

  • Page 59: Set Mesh [Profile_Num] Rtmode

    5. Mesh Commands 5-20. SET MEsh [profile_num] RTMOde Sets the route switching mode to Mesh profile of the specified number [profile_num]. SET MEsh [profile_num] RTMOde [ RESponsive | STAble ] RESponsive : Set the responsive type for the route switching mode. STAble : Set the stable type for the route switching mode.
  • Page 60 MNS-300EM Command Manual...

  • Page 61: Port Commands

    6. Port Commands Port Commands This chapter describes the commands for serial port settings and Ecable mode.

  • Page 62: Serial Port Commands

    MNS-300EM Command Manual 6-1. Serial Port Commands The following examples of command execution use S1 as a serial port. When S2 is enabled as a data port, S2 can be used instead. When there are the commands which cannot be used for that port, such note is described.

  • Page 63: Set Port S2 Console

    In the console mode, the MNS-300EM's settings can be configured from the serial port. When no string is defined, this function is disabled and the configuration cannot be changed via the serial port.

  • Page 64: Sh Port S1 Constr

    Sets the console mode string to two successive escape characters. 6-1-5. SH PORT S1 CONSTR Shows the console mode string of MNS-300EM. SH PORT S1 CONSTR When non-printable characters are contained in the string, \x is added at the beginning of the string and each byte is displayed in 2-digit hexadecimal.

  • Page 65: Set Port S1 Dtr

    6. Port Commands 6-1-6. SET PORT S1 DTR Sets the DTR mode for a serial port 1. SET PORT S1 DTR [CONN | HI | LOW] When GPIO2 is set for a special function, the serial port 1 processes DTR signals. This command can change the pin operation.

  • Page 66: Clear Port S1 Job

    MNS-300EM Command Manual 6-1-8. CLEAR PORT S1 JOB Stops the ongoing job of the specified port. CL PORT S1 JOB When a remote host is connected and the data is sent after the command is executed, such data will be deleted.

  • Page 67: Set Port S1 Parity

    6. Port Commands 6-1-10. SET PORT S1 PArity Sets the parity of the serial port. SET PORT S1 PArity <parity> Choose one of the followings for <parity>. NOne, EVen, ODd The factory default value is NOne. 6-1-11. SET PORT S1 SPeed Sets the baud rate of the serial port.
  • Page 68 MNS-300EM Command Manual 6-1-12. SH PORT S1 STAtus Shows the serial port status. SH PORT S1 STAtus Sample output: Local> SH PORT S1 STAtus Port S1 status = On-line Serial Device 3 bytes transmitted, 0 bytes received 0 framing errors, 0 parity errors, 0 overrun errors, 0 buffer overruns, 0 breaks 6-1-13.
  • Page 69 6. Port Commands 6-2. Ecable Port Command The following describes the commands for communication of Silex Technology's E-Cable application. 6-2-1. SET PORT S1 ECABLE Enables/Disables E-Cable. SET PORT S1 ECABLE [ENable | DISable] ENable : Enables E-Cable DISable : Disables E-Cable The factory default value is DISable.
  • Page 70 MNS-300EM Command Manual 6-2-3. SET PORT S1 ECADDR Sets the primary destination address for E-Cable connection. SET PORT S1 ECADDR <dest-addr> For <dest-addr>, enter the primary address (IP address) of the host device to which the I/O port data is sent. When DNS is enabled only for the TCP mode, a host name can be used to enter the command.
  • Page 71 6. Port Commands 6-2-5. SET PORT S1 ECLPORT Specifies the UDP port number for the remote host to use MNS-300EM's I/O port. This setting is enabled for UDP mode only. SET PORT S1 ECLPORT <port> Specify the UDP port number for <port>.
  • Page 72 MNS-300EM Command Manual 6-2-7. SET PORT S1 ECPORT Specifies the port number for remote connection to use when E-Cable is enabled. SET PORT S1 ECPORT <port> Specify the port number for <port>. When 0 is given, no data will be sent.
  • Page 73 6. Port Commands 6-2-9. SET PORT S1 ECRPORT Specifies the UDP port number for the primary/secondary E-Cable destination. This setting is enabled for UDP mode only. SET PORT S1 ECRPORT <index> <port> index : When the index value is set to 0, the primary port is set. When not 0, the valid range is 1 to (n-1), where "n"...
  • Page 74 MNS-300EM Command Manual 6-2-11. SET PORT S1 ECUDP Enables/Disables the UDP mode. SET PORT S1 ECUDP [ENable | DISable] ENable : Enables the UDP mode. DISable : Disables the UDP mode. The factory default value is DISable.
  • Page 75 7. Server Commands Server Commands This chapter describes the commands for the server information of MNS-300EM.
  • Page 76 MNS-300EM Command Manual 7.1. SH SERIAL Shows the serial number of MNS-300EM. SH SERIAL Sample output: Local> SH SERIAL Serial number is 9047595 7-2. SH SERVEr Shows the server information. SH SERVEr Sample output: Local> SH SERVEr Silex MNS-300EM Serial # 2000560...
  • Page 77 N/A User Buffer Unavailable: Frames Sent, Deferred: N/A System Buffer Unavailable: Unsupported parameters show N/A. 7-4. SET SERVEr DEScription Sets the server description string. SET SERVEr DEScription <description-string> Enter the description for <description-string>. The factory default value is Silex MNS-300EM.
  • Page 78 MNS-300EM Command Manual 7-5. SH SERVEr FWVER Shows the MNS-300EM's firmware version. SH SERVEr FWVER Sample output: Local> SH SERVEr FWVER 1.00 (20xx.xx.xx) This command only shows the firmware version string that does not include the information shown by SH VERsion.

  • Page 79: Set Server Name

    7. Server Commands 7-7. SET SERVEr NAme Specifies the server node name. SET SERVEr NAme <name> The factory default value is SDSxxxxxx. xxxxxxx is the last 6 digits of the MAC address. 7-8. SH SERVEr STAtistics Shows information of the received print job. SH SERVEr STAtistics Sample output: Local>...

  • Page 80: Sh Server Queue

    MNS-300EM Command Manual 7-9. SH SERVEr QUEue Shows the I/O job queue for each serial port. SH SERVEr QUEue Sample output: Local> SH SERVEr QUE Port S1 status = On-line # Type Source The queue is empty 7-10. SH SNMP Shows the SNMP protocol setting (enabled/disabled).

  • Page 81: Set Snmp Contact

    7. Server Commands 7-11. SET SNMP CONtact Specifies the sysContact string for SNMP. SET SNMP CONtact <string> Enter the character string of the contact for <string>. The factory default value is a NULL string. 7-12. SET SNMP GETCOMM Specifies the community name for GET command processing of SNMP. SET SNMP GETCOMM <string>...

  • Page 82: Set Snmp Setcomm2

    Specifies the community name for SET command processing of SNMP. SET SNMP SETCOMM2 <string> Enter the community name for <string>. The factory default value is public. 7-15. SH VErsion Shows the MNS-300EM's firmware version. SH VErsion Sample output: Local> SH VER Silex MNS-300EM Firmware Ver.

  • Page 83: Service Commands

    8. Service Commands Service Commands MNS-300EM's serial port is associated with the logical I/O service. This chapter describes commands for the I/O service.

  • Page 84: Sh Servi

    MNS-300EM Command Manual 8-1. SH SERVI Shows the service settings. SH SERVI Sample output: Local> SH SERVI # Service Port FIL BOT EOT DEL OPT PROT * 1 SDS1E86B0_S1_A S1 0 1 1 0 B IP 2 SDS1E86B0_S1_B S1 0 1 1 0 B IP "...

  • Page 85: Set Servi Eot

    8. Service Commands 8-3. SET SERVI <service name> EOT Sets the index number of the end of transmission (EOT) string for the specified service. SET SERVI <service name> EOT <n> service name : Specifies the service name. : Specifies the index number. The string of the index number will be the EOT string.

  • Page 86: Set Servi Filter

    : Specifies the service name. : Specifies the index number. The filter of the index number will be set. SH FILter can show available filters of MNS-300EM. 8-6. SH SERVI FILters Shows a list of the service filter settings.

  • Page 87: Set Servi Fms

    8. Service Commands 8-7. SET SERVI <service name> FMS Specifies the index number of match string for Filter 1 (string replacement filter). SET SERVI <service name> FMS <n> service name : Specifies the service name. : Specifies the index number. When the string of the specified index is found in output, it will be replaced with the replacement string configured by SET SERVI <service name>...

  • Page 88: Set Servi Ip

    MNS-300EM Command Manual 8-9. SET SERVI <service name> IP Enables/Disables the IP-distributed jobs (LPD, Raw TCP, etc.). SET SERVI <service name> IP [ ENable | DISable] service name : Specifies the service name. ENable : Enables jobs distributed via IP.

  • Page 89: Set Servi Port

    8. Service Commands 8-11. SET SERVI <service name> POrt Sets the association between the service and output port. SET SERVI <service name> POrt <portname> service name : Specifies the service name. portname : Specifies the output port name to be associated. The factory default value is S1.

  • Page 90: Sh Servi Pri [Service_Num]

    MNS-300EM Command Manual 8-13. SH SERVI PRI [service_num] Shows the priority for the specified services. SH SERVI PRI [service_num] For [service_num], enter the number of the service to show the priority. When no value is given, priority for all services will be shown.

  • Page 91: Set Servi Receive

    8. Service Commands 8-15. SET SERVI <service name> RECeive Enables the receive-only mode for the specified service. This command is used only when the host application does not operate properly when data is received from the serial device and is sent to the host application. SET SERVI <service name>...

  • Page 92: Sh Servi Summary [Service_Num]

    MNS-300EM Command Manual 8-17. SH SERVI SUMmary [service_num] Shows the setting of the specified service. SH SERVI SUMmary [service_num] For [service_num], enter the number of the service to show the setting. When no number is provided, settings of all services will be shown.

  • Page 93: String Commands

    9. String Commands String Commands This chapter describes the commands that can set the strings to use for services and service filters.

  • Page 94: Set String

    MNS-300EM Command Manual 9-1. SET STRing Registers the string to use for services. SET STRing <string_num> <"value"> string_num : Specifies the number where the string is registered. value : Specifies the string to register. The string has to be double-quoted.

  • Page 95: Sh String

    9. String Commands 9-3. SH STRing Shows the BOT and EOT string definitions to use for services. SH STRing <string_num> The output will be changed depending on the existence of <string_num>. W h e n < s t r i n g _ n u m > i s : Shows the string of <string_num>...

  • Page 96: Sh Filters

    MNS-300EM Command Manual 9-4. SH FILters Shows the filter that can be used to modify the job stream. SH FILters Sample output: Local> SH FIL Filter 0 No Filter 1 Text Substitution 3 Text to PostScript 4 PostScript Tagged Binary...

  • Page 97: Tcp/Ip Commands

    10. TCP/IP Commands TCP/IP Commands This chapter describes the commands for TCP/IP function settings.

  • Page 98: Sh Ip

    MNS-300EM Command Manual 10-1. SH IP Shows the current TCP/IP settings. SH IP Sample output: Local> SH IP IP is enabled Boot method DHCP IP address 192.168.5.40 (192.168.5.235) Subnet Mask 255.255.255.0 (255.255.255.0) IP gateway 192.168.5.1 (0.0.0.0) Boot tries 3 Timeout...

  • Page 99: Set Ip Access

    Allows/Denies access from the specified IP address range. SET IP ACcess [ENable | DISable | ALL] <aa.bb.cc.dd> <ee.ff.gg.hh> This command updates the list of IP addresses that can access MNS-300EM. ENable : Adds an IP address range to the IP address list. Only the hosts with the registered IP address are allowed to access MNS-300EM.

  • Page 100: Set Ip Http

    MNS-300EM Command Manual 10-4. SET IP HTTP Enables/Disables the HTTP protocol. SET IP HTTP [ENable | DISable] ENable : Enables the HTTP protocol. DISable : Disables the HTTP protocol. The factory default value is ENable. 10-5. SET IP TFTP Enables/Disables the TFTP protocol.

  • Page 101: Set Ip Tcp

    Disables the LPD protocol. DISable The factory default value is ENable. 10-9. SET IP SX_INTERN Enables/Disables the Silex Technology's proprietary protocol. SET IP SX_INTERN [ ENable | DISable] Enables the Silex Technology's proprietary protocol. ENable Disables the Silex Technology's proprietary protocol.

  • Page 102: Set Ip Probe

    MNS-300EM Command Manual 10-10. SET IP PRObe Enables/Disables the TCP connection check (TCP Keepalive packet transmission). SET IP PRObe [ENable | DISable] Enables transmission of the TCP Keepalive packet. ENable Disables transmission of the TCP Keepalive packet. DISable The factory default value is DISable.

  • Page 103: Set Ip Ftime

    10. TCP/IP Commands 10-12. SET IP FTIme Specifies the unit of IP timeout. SET IP FTIme [ENable | DISable ] ENable : The IP timeout is measured in seconds. DISable : The IP timeout is measured in minutes. The factory default value is DISable. 10-13.

  • Page 104: Set Ip Status

    SH IP STATus can show the current status string. Example: Local> SET IP STATUS lpd-status • This value will be deleted when MNS-300EM restarts. 10-15. SET IP WIndow Specifies the maximum TCP window size in bytes. SET IP WIndow <n>...

  • Page 105: Set Ip Banner

    10. TCP/IP Commands 10-16. SET IP BAnner Enables/Disables the banner printing on LPD. SET IP BAnner [ENable | DISable] ENable : Enables the banner printing. DISable : Disables the banner printing. The factory default value is DISable.
  • Page 106 MNS-300EM Command Manual (Blank page)

  • Page 107: Dns Commands

    11. DNS Commands DNS Commands This chapter describes the commands for DNS function settings.

  • Page 108: Sh Dns

    MNS-300EM Command Manual 11-1. SH DNS Shows the current DNS settings. SH DNS Sample output: Local> SH DNS DNS is Enabled Domain name: Primary DNS server: 0.0.0.0 Secondary DNS server: 0.0.0.0 11-2. SET DNS DOMain Specifies the domain name required by the DNS function.

  • Page 109: Set Dns Primary

    11. DNS Commands 11-3. SET DNS PRImary Specifies the IP address of primary DNS server. SET DNS PRImary <aa.bb.cc.dd> Enter the IP address of primary DNS server for <aa.bb.cc.dd>. The factory default value is 0.0.0.0. 11-4. SET DNS SECondary Specifies the IP address of secondary DNS server. SET DNS SECondary <aa.bb.cc.dd>...
  • Page 110 MNS-300EM Command Manual (Blank page)

  • Page 111: Ntp Commands

    12. NTP Commands NTP Commands This chapter describes the commands for NTP settings.

  • Page 112: Set Ntp Server

    MNS-300EM Command Manual 12-1. SET NTP SERVER Specifies the NTP server to retrieve the time information from. SET NTP SERVER <server> For <server>, enter an alphanumeric string (up to 48 characters). When no value is given to <server>, the factory default value is used.

  • Page 113: Gpio Control Commands

    13. GPIO Control Commands GPIO Control Commands This chapter describes the commands for GPIO signal settings. MNS-300EM has 11 GPIO signals, and number 0-10 is assigned for each. For details on the GPIO signal definitions and functions, refer to MNS-300EM Setting Manual.

  • Page 114: Set Gpio Dir

    MNS-300EM Command Manual 13-1. SET GPIO DIR Specifies the GPIO signal direction (IN or OUT). SET GPIO DIR [IN | OUT] <gpio-number> : Sets the direction to input. : Sets the direction to output. gpio-number : Specifies the number of GPIO signal to set (0-10) .

  • Page 115: Sh Gpio Dir

    13. GPIO Control Commands 13-2. SH GPIO DIR Shows the GPIO signal direction settings. SH GPIO DIR Sample output: Local> SH GPIO DIR GPIO Direction -------------- 0 [SPCL] 1 [SPCL] 2 [OUT] 3 [OUT] 4 [OUT] 5 [OUT] 6 [OUT] 7 [OUT] 8 [OUT] 9 [OUT]...

  • Page 116: Set Gpio Dirm

    MNS-300EM Command Manual 13-3. SET GPIO DIRM Sets the direction (in/out) for all 11 GPIO signals with a bitmask value. SET GPIO DIRM <bit-mask> <bit-mask> is an 11 bit mask expressed as 3 hex digits. The value range must be 000-7FF.

  • Page 117: Set Gpio Special

    This command enables or disables the special function defined for individual GPIO signal. For details on the special function assigned for each GPIO signal, refer to 8-1. GPIO Special Functions in MNS-300EM Setting Manual. • This setting will remain even after the configuration is initialized.

  • Page 118: Sh Gpio Special

    MNS-300EM Command Manual 13-6. SH GPIO SPECial Shows the current setting of special function for GPIO signals. SH GPIO SPECial Sample output: Local> SH GPIO SPECIAL GPIO Special Functions ----------------------- GPIO #0 is special GPIO #1 is special GPIO #2 is normal...

  • Page 119: Set Gpio Specm

    13. GPIO Control Commands 13-7. SET GPIO SPECM Sets the special function for all 11 GPIO signals with a bitmask value. SET GPIO SPECM <bit-mask> <bit-mask> is an 11 bit mask expressed as 3 hex digits. The value range must be 000-7FF. The following table shows the definition of each bit for <bit-mask>.

  • Page 120: Set Gpio Data

    For example, when 080 (hex) is entered for <bit-mask>, 1 (high) is set for GPIO7, and 0 (low) is set for all other GPIO signals except for the ones whose special function is enabled. • For all GPIO signals whose direction is an output, 0 (Low) is applied when MNS-300EM is powered on or restarts.

  • Page 121: Sh Gpio Data

    13. GPIO Control Commands 13-10. SH GPIO DATA Shows the current input/output values of GPIO signals. SH GPIO DATA Sample output: Local> sh gpio data GPIO Data In -------------- GPIO #0 [1] GPIO #1 [0] GPIO Data Out -------------- GPIO #2 [0] GPIO #3 [0] GPIO #4 [0] GPIO #5 [0]...
  • Page 122 MNS-300EM Command Manual (Blank page)

  • Page 123: Bluetooth Commands

    14. Bluetooth commands Bluetooth Commands This chapter describes the commands for Bluetooth functions.

  • Page 124: Sh Bt

    MNS-300EM Command Manual 14-1. SH BT Shows the current Bluetooth function settings. SH BT Sample output: Local> SH BT BT configuration list Bluetooth: Enabled Passkey: 000000 14-2. SET BT Enables/Disables the Bluetooth function. SET BT [ ENable | DISable] ENable : Enables the Bluetooth function.

  • Page 125: Set Bt Passkey

    14. Bluetooth commands 14-3. SET BT PASSkey Specifies the pass key used for Bluetooth pairing. SET BT PASSkey <n> n = 0-999999 (default = 0) Enter the following value in <n>: 0 - 999999 : Specifies the pass key for Bluetooth pairing. The factory default value is 0.
  • Page 126 MNS-300EM Command Manual (Blank page)

  • Page 127: Firmware Update Commands

    15. Firmware Update Commands Firmware Update Commands This chapter describes the command for firmware update.

  • Page 128: Set Load Xmodem

    Local> SET LOAd XModem You may begin your XModem transfer now. The firmware update file (MNS-300EM.bin) is sent to MNS-300EM after the above message is shown. When the file is received, MNS-300EM starts a firmware update process and restarts itself automatically.

  • Page 129: Power Management Commands

    16. Power Management Commands Power Management Commands This chapter describes the commands for the wireless module's power operation.

  • Page 130: Set Nw Wlif

    : Disables the wireless LAN network interface and stops emitting radio waves. The factory default value is UP. 16-2. SET POWER LEVEL Changes the power level of MNS-300EM. SET POWER LEVEL <n> Enter one of the following values for <port>.

  • Page 131: Other Commands

    17. Other Commands Other Commands This chapter describes other commands.

  • Page 132: Set Default

    MNS-300EM Command Manual 17-1. SET DEFAULT Restores MNS-300EM to the factory default settings. SET DEFAULT 17-2. EXIT Terminates the configuration console session. EXIT 17-3. HElp <command> Shows the help information of the console command. Enter only "HElp" or enter a command after "HElp" to see the information.

  • Page 133: Init

    Starts a soft reset when the EXIT command is executed. INIT 17-5. SET PAssword Changes the password to access MNS-300EM. SET PAssword <password> Enter 1-8 alphanumeric characters for <password>. By default, no password is configured to MNS-300EM. 17-6. SAVE Saves the current settings to the non-volatile memory. SAVE...
  • Page 134 MNS-300EM Command Manual (Blank page)

Table of Contents
