Using Timer - Mitsubishi Electric MJ-E130AL-H Instruction Manual

Using Timer

2
1
Switch the power ON.
2
Select operation mode.
Select the desired operation mode.
3
Change the louvre swing
direction.
Select the desired louvre swing direction.
4
Set the operation
time.
Press once to display " " "
Each press will change the display in
the sequence of 1 to 9 hours.
(Holding the switch will cause the display to
change continuously.)
Blip Blip
No display
(continuous
operation)
The OFF TIMER is set.
Example of setting OFF TIMER to 2 hours
with AUTO mode (setting: 60%), louvre swing
setting "Wide"
The remaining time will decrease one
hour after each hour elapses.
When the set time is reached, the unit stops
automatically and the louvre closes automatically.
DRYING INSIDE (auto) operation will start if it has been activated.
20
3 4 1
12
12–17
18
Blip
".
. .. .
Blip
Blip
Blip
The OFF TIMER can be set
between 1 to 9 hours. Set the timer
when the power is switched on.
Cancellation
<When you want to stop
operation>
Press POWER switch
Press
<When you want to disable the
OFF TIMER mode and continue
operation>
Press and hold the ON/OFF TIMER switch
until the remaining time disappears from the
display.
Empty the water tank before operating. During
operation, if the tank becomes full, the FULL lamp
lights and the unit stops.
The OFF TIMER and ON TIMER cannot be set at the
same time.
If the OFF TIMER mode is used with the INTELLIGENT
LAUNDRY, NIGHT LAUNDRY or MILDEW GUARD,
the unit may stop before the laundry or the bathroom
is dry.
The OFF TIMER cannot be set during DRYING INSIDE
operation.
19
OFF
Blip
Press
Press POWER switch
OFF
Blip
Press
The OFF TIMER is
cancelled.
