Summary of Contents for Lexmoto LX06
- Page 1 USER’S MANUAL LX06 （EEC L1e-B）...
-
Page 2: Riding Guide
Make sure to check the following items before riding a electric scooter, which will guarantee your safety on the road. Welcome to the family of LX06 owners! We will guide you to know each function for the right and safe use of electric scooters. -
Page 3: Safety Instructions
DESCRIPTION OF COMPONENTS AND PARTS SAFETY INSTRUCTIONS Installation of Mirrors To ensure the safety of you and others, please make sure to observe the following matters: Do not ride after you take medications, drink alcohol, or when you are unwell, which may affect your riding ability. Observe traffic regulations and traffc signs and confirm the surrounding road conditions and scooter conditions at any time to avoid danger. - Page 4 DESCRIPTION OF COMPONENTS AND PARTS DIAGRAM OF INSTRUMENT PANEL Rearview mirror Rear registration plate lamp Temperature Speedometer Rear combination lamp Headlamp High beam Handle Stop lamp/rear position lamp Front position lamp Speed Rear direction indicator USB charger lower beam Controller Converter Battery capacity Horn...
-
Page 5: Switch Function
OPERATION GUIDE SWITCH FUNCTION Details Of Instrument Panel Left Start Button Right Start Button Lamp Function Lamp Function READY Power on Low voltage need recharge the battery Turn signal on High beam on Motor error, erase the error and run the Meter working temperature motor for 4 minutes, the error indicator will disappear automatically. - Page 6 OPERATION GUIDE SWITCH FUNCTION Guide of ignition key Item Switch position Functions Start power supply Turn the key to postion and power on the scooter. Press the button to adjust the speed level, ATTENTION: Speed levels level information will be synchronous shown in meter 1.
- Page 7 BATTERY INSTALLATION AND DISMOUNT OPERATION GUIDE How To Operate The Smart Remote Contol Install the cable Open the small cap on the top of battery case With the advanced Smart Remote Controller, you can easily lock or unlock your Align the power cord with the white arrow on the socket. Insert slowly and press firmly until electric scooter by simply pressing the button within 50 meters.
- Page 8 USB & SIDE STAND GUIDE OF THE BREAKER Guide of the USB 1. Open the dust cover of the USB charging port; 2. Connect the cable When the master switch is ON, the vehicle's main power source is connected. Guide for side stand power off fuction When the master switch is OFF, the vehicle's main power source is disconnected.
-
Page 9: How To Charge The Battery
BATTERY USE INSTRUCTIONS BATTERY USE INSTRUCTIONS How to Charge the Battery TIPS: TIPS: Insert the main charger plug into the charging port of the scooter. Short circuit of the cathode and the anode at the battery's input. Do not expose the battery to water, and prevent it from being Insert the chargers AC power plug into the home power socket, and the battery starts charging when the charger indicator turns red. -
Page 10: Routine Cleaning And Maintenance
BATTERY USE INSTRUCTIONS MAINTENANCE Routine Cleaning and Maintenance Cleaning： Please use clean water and neutral detergent to clean it, and use soft cloths and sponges to clean the surface; It is prohibited to use metal brushes, sandpaper or the like to clean it, in order not to scratch the parts surface. After cleaning, dry it with soft cloths. Storage, Maintenance and Transportation TIPS: Please disconnect the air switch before cleaning. -
Page 11: Troubleshooting And Faq
TROUBLE-SHOOTING & FAQ ELECTRICAL SCHEMATIC Fuse converter 250V/ １ 0A The power lock Max output power120W battery pack1 Regular maintenance can improve the service life and driving safety of the electric scooters. １２０Ｗ Air switch1 The headlight switch Please refer to the fol-lowing suggestions and take care of your scooter. flasher Failure Causes...
Need help?
Do you have a question about the LX06 and is the answer not in the manual?
Questions and answers
Won't turn on but battery is fully charged
If a Lexmoto LX06 won't turn on despite a fully charged battery, possible reasons include:
1. The master switch is OFF, disconnecting the main power.
2. The side stand is not retracted.
3. The brake handle is not in the correct position.
4. The air switch is not turned on.
5. The parking key is not closed.
6. Steering handlebar failure.
7. Loose controller plug.
8. Controller failure.
