Zico Rol-Loc QM-ROLO-SA Series Parts And Instruction Manual

R -l M
®
ol oc echanical
M QM-Rolo-Sa-____
odel
P i
aRtS and nStRuction
Note: Not to be used in place
of a seat belt when used with
SCBA harness.
Note: Due to slight variations in cylinder length
between SCBAs of the same make and model,
Zico strongly recommends the purchase of the
Rol-Loc Adjustable Footplate Kit.
MODEL
QM-ROLO-SA
QM-ROLO-SA-LSPR Bracket, Stand Alone less Pull Release
QM-AF-R
B
Racket
M
anual
Self-locking - simply press the cylinder through the rolling top clamp.
The Rol-Loc features a unique self-locking, PVC-coated top clamp to
securely lock SCBA cylinders without the need for straps or levers.
To secure the cylinder, place the SCBA valve into the footplate, then press
the cylinder against the top clamp. The top clamp will roll up and out of the
way to accept the cylinder, and then lock closed behind it.
To release the SCBA, simply pull on the release cord.
NFPA compliant and third party tested to exceed the 9G standard.
Fits st SCBAs with only minor adjustments.
Easty to retrofit into new or old seats. Works with most center pull releases.
DESCRIPTION
Bracket, Stand Alone
Adjustable Footplate Kit
ZICO
1027PM1
Rev 11-7-13
WT./@ IN LBS.
18.3
17.9
0.6
®
