ELECTRIC BOWLING GREEN MOWER
P.O. Box 1673
Bedfordview
2008
PROTEA TURF EQUIPMENT
Manufacturers of Industrial Lawnmowers, Scarifiers & Sodcutters
PROTEA BG760
www.proteamachines.com
Reg. No. CK 1989/023716/23
Vat Reg. No. 4830119907
32 Shaft Rd
Knights, Germiston
Tel: +2711 828 9935
