Tally Dascom DL-200
Power switch
Component Name
Power socket
Power switch
USB interface
Optional interface
(Serial/ Parallel/ Ethernet/ Wi-Fi)
Connection cable must comply with the following requirements:
Connection Type
USB
Serial
Parallel
Ethernet

2.7.1 Connecting USB interface

Power socket
USB interface
Function
Connect power cord to the printer
For switching on/off printer
Connect USB interface cable from host
Connect optional interface cable from host
(interface type is on request)
Optional Interface
(Serial/ Parallel/ Ethernet/
Wi-Fi/ Bluetooth）
Specifications
USB 1.1/2.0 compatible
RS232
IEEE 1284.4
10 Base-T/100 Base-TX compatible
21
User Guide V1.3
