Chapter 1 Overview Introduction This chapter provides an overview of the 4100U-S1 operator interface and describes the normal appearance of the operator interface. In this Chapter Refer to the page number listed in this table for information on a specific topic. -
Page 12: Typical Panel Layout
Typical Panel Layout Overview The 4100U-S1 is supplied with an Operator Interface plus one Expansion Bay in a 21U sized cabinet. The Zone Isolate modules are fitted into the Expansion bays from left to right. The first zone is at the top of the leftmost module. -
Page 13: Basic System Description
Basic System Description Overview The Simplex 4100U-S1 Fire Alarm Control Panel (FIP) has three general functions. • It monitors fire alarm initiating points (smoke detectors, heat detectors etc.). • It activates fire alarm notification devices (bells, strobes, brigade call) when an initiating point activates. - Page 14 Basic System Description, Continued Overview, (continued) Table 1-1. Components of the Operator Interface (continued) LED/Key Description Refer To SYSTEM WARNINGS The System Warning LEDs – Isolation and Fault – indicate when Chapter 3 abnormal, non-fire conditions occur. When any zone is isolated, this LED turns on and the buzzer sounds until Isolate LED and Ack Key Chapter 3...
- Page 15 Basic System Description, Continued Overview, (continued) Table 1-1. Components of the Operator Interface (continued) LED/Key Description Refer To Displays text describing abnormal conditions for devices attached to the Alphanumeric Display panel (e.g., smoke detector in main lobby is in alarm). Also displays system prompts and messages.
-
Page 16: Control Keys & Indicators
Control Keys & Indicators Overview The control keys and indicator LEDs are located on the far left of the Operator Interface. A control key is pressed to perform the labelled function, and the associated LED turns on to show the function is active. Pressing the key again de-selects the function and turns off the LED. -
Page 17: Normal Appearance Of Operator Interface
Normal Appearance of Operator Interface Description The 4100U-S1 operator interface panel shows the following under normal conditions. • Green AC Power LED is ON – indicating the panel is receiving AC Power. • All other LEDs off. • Alphanumeric display reports that the system is normal and shows the current time and date, as shown below. -
Page 19: Introduction
An alarm condition occurs when an actuating device (such as a manual call point, smoke detector, etc.) activates. The 4100U-S1 indicates the presence of the alarm condition through messages it displays on the alphanumeric display, by illuminating the ALARM indicator LEDs, and by activating the building’s EWS and external bell. -
Page 20: Acknowledging Alarms
Acknowledging Alarms What the System When the first alarm condition is detected by the 4100U-S1, the panel does the following to Does When an indicate the presence of the alarm. Alarm Occurs • Red Fire Alarm and common Zone Alarm LED indicators flash •... -
Page 21: Procedure
Acknowledging Alarms, Continued Procedure Use the following procedure to acknowledge alarm(s). 1. Unlock and open the enclosure door. Read the alphanumeric display . It alternates between the display shown in fig 2.1 & the summary shown below. ***ALARM*** Press <FIRE ALARM ACK> to review. ALARMS = 1 ISOLATED = 0 FAULT = 0... -
Page 22: Isolating (Silencing) The Ews Or External Bell
In addition, the external bell sounds to indicate the location of the 4100U-S1 FIP. During maintenance or testing, these outputs can be prevented from activating by isolating them before an alarm occurs. In a real alarm situation, they should be left operating until Brigade personnel choose to turn them off. -
Page 23: Isolating Acf Outputs
Overview The Ancillary Control Facility (ACF) consists of relay outputs which can be used to control equipment which is not part of the 4100U-S1 fire alarm system, such as shutting down air conditioning or returning lifts to a certain floor. -
Page 24: Resetting Air Conditioning Control
When a zone alarm occurs, among the other alarm indications, the A/C AUTO indicator lights to show that the 4100U-S1 has taken control of the air conditioning system. This operation remains in effect even after all alarms have been cleared and the 4100U-S1 system has been reset and is back to normal. -
Page 25: Displaying Event Time
Displaying Event time Procedure 1. Select the point by repeatedly pressing the <ALARM ACK> key (for a point in alarm), <FAULT ACK> (for a point in fault), or <ISOLATE ACK> (for an isolated point) until the desired point is displayed. 2. -
Page 26: Resetting Points
Resetting Points Overview The Alarm state and some Fault conditions latch within the panel so they can be acknowledged and viewed. When the latched states are no longer required they can be reset. The condition that caused each point to go into alarm must be cleared before the system can reset to the normal state, (e.g. -
Page 27: Chapter 3 Managing Fault And Isolate Conditions
Fault conditions are used to indicate something wrong, e.g. the presence of a field wiring problem (circuit break, short or ground), somewhere between the 4100U-S1 and one of its points. Faults are also used to indicate a problem with the 4100U-S1’s option cards, power supplies, network card, etc. -
Page 28: Acknowledging Fault Or Isolate Conditions
Acknowledging Fault or Isolate Conditions How the 4100U-S1 When a fault or isolate condition is detected by the 4100U-S1, the operator interface does the Indicates the following: Presence of a Fault • The yellow “FAULT” or “ISOLATE” indicators flash •... -
Page 29: Panel Operating Procedure - Fault Condition
Acknowledging Fault or Isolate Conditions, Continued Panel Operating 1. Unlock and open the panel door. The yellow Fault indicator (LED) will be flashing and Procedure – Fault the sounder (buzzer) sounding. The alphanumeric display shows a message similar to the Condition following. -
Page 30: Viewing Fault Or Isolate Conditions
Viewing Fault or Isolate Conditions Overview You can view the list of acknowledged fault or isolate conditions at any time by using the following procedure. 1. Press the <FAULT ACK> or <ISOLATE ACK> key to enter the fault or isolate list. The first fault or isolate condition in the list appears in the display. -
Page 31: Chapter 4 Testing And Controlling Points
Chapter 4 Testing and Controlling Points Introduction This chapter describes using the panel’s action keys (ALARM TEST, On, Off, etc.) to test and control system zones and points. In this Chapter Refer to the page number listed in this table for information on a specific topic. Topic See Page # Alarm and Fault Test for Zones... -
Page 32: Alarm And Fault Test For Zones
Alarm and Fault Test for Zones Alarm Test Alarm Test forces a zone into the alarm state. Once the zone is in alarm, you can check to see if the system reacts in the way that it has been programmed (i.e., do signals sound in the correct manner? do relays function correctly? etc.). -
Page 33: Isolating And De-Isolating Zones
Isolating and De-isolating Zones Overview This section describes isolating and de-isolating zones. Isolating a zone does not prevent any of the points within the zone from going into the alarm state, but does prevent the activation of any outputs that are programmed to operate when the zone is in alarm. Pressing the <ISOLATE>... -
Page 34: Disabling And Enabling Points
Disabling and Enabling Points Disabling and Enabling Points Overview Situations such as a malfunctioning detector causing false alarms, or an activated detector that prevents the system from being reset, can be temporarily overcome by disabling that particular point. Disabling a point allows the system to be reset while repairs are being made. It takes the point “offline”. -
Page 35: Turning A Point On Or Off
<AUTO> key and the <ENTER> key. Sounder (buzzer) A loud buzzer is used in the Australian 4100U-S1 to meet the requirements of AS4428 (70dB at 1m with the door closed). If doing testing or maintenance on the system with an operator at the panel, the buzzer may be inhibited by turning point P198 on. -
Page 37: Chapter 5 Selecting Points For Status Or Control
Chapter 5 Selecting Points for Status or Control Introduction Many of the operations that can be accomplished from the operator interface first require you to select the point on which you want to perform the operation. Points can be selected in one of three ways. -
Page 38: Selecting Points From The Menu
Selecting Points from the Menu Overview Every system point is part of the “Select a List of Points” list in the main menu. All points can be displayed sequentially by address order using this list option. To facilitate a search for a particular point, lists may be selected by point category (monitors, signals, auxiliary, input/output, pseudo points, etc.). -
Page 39: Selecting Points With The Entry Keypad
Selecting Points with the Entry Keypad Overview The Entry Keypad, shown below, allows you to quickly select points. For example, pressing the ZONE key on the upper left side of the keypad selects the monitor zone category. After selecting a category, messages on the display prompt you for the specific point in the category. After a point has been displayed, you can scroll through all the points in the system from that point, or select another point directly by entering another identifier using the keypad. -
Page 40: Selecting Points
Selecting Points with the Entry Keypad, Continued Selecting Points, (continued) Press this Key on Keypad Data to Enter <AUX>, followed by <ENTER>, where AUX AUX – allows you to select an represents an auxiliary relay and is a number from x Auxiliary Relay to y. -
Page 41: Chapter 6 Displaying And Modifying Detailed Point Attributes
Chapter 6 Displaying and Modifying Detailed Point Attributes Introduction This chapter describes displaying and modifying the attributes of a point. In this Chapter Refer to the page number listed in this table for information on a specific topic. Topic See Page # Display-Only Attributes Modifiable Point Attributes... -
Page 42: Display-Only Attributes
Display-Only Attributes Select a Point Points can be selected in one of three ways: through the alarm, fault, or isolate list, using the MENU keys, or with the ENTRY keypad. Refer to Chapter 5 for information on selecting a point. See the Attributes 1. -
Page 43: Summary Of Display-Only Attributes
Display-Only Attributes, Continued Summary of Display- Only Attributes, (continued) Table 6-2. Display-Only Attributes (continued) Category Attribute Description Present sensitivity selected Displays the current sensitivity of the device. Average value Displays the average value recorded by the sensor. TrueAlarm Alarm value Displays the value required to trigger an alarm. -
Page 44: Modifiable Point Attributes
Modifiable Point Attributes Overview This section describes using the <MORE INFO> key to modify the attributes of a point. Select a Point Points can be selected in one of three ways — through the alarm, fault, or isolate list, using the MENU keys, or with the ENTRY keypad. - Page 45 Modifiable Point Attributes, Continued Summary of Modifiable Table 6-4. Modifiable Attributes (continued) Attributes, (continued) Attribute Description TrueAlarm Peak Analog Allows you to clear the peak value of a TrueAlarm Values sensor. Allows you to set the value at which the device goes into alarm.
-
Page 47: Chapter 7 Setting Access Levels And Logging In
Chapter 7 Setting Access Levels and Logging In Introduction This chapter describes setting the time and date on the system, logging in and out, and setting access levels for use by system operators. In this Chapter Refer to the page number listed in this table for information on a specific topic. Topic See Page # Operator Access Levels... -
Page 48: Operator Access Levels
2 through 4. Routine actions are assigned to low access levels while access level 4 is reserved for special, highly sensitive operations (normally reserved for Simplex personnel). Entering a level 4 passcode enables you to access all the functions of the system. -
Page 49: Logging In And Out Of The System
Logging In and Out of the System Introduction The 4100U-S1 system uses four access levels, referred to by the numbers one through four, to control what system operators can do with the system. The system typically operates at access level one, which allows an operator to accomplish basic tasks without logging in to the system. -
Page 50: Log Out Procedure
Logging In and Out of the System, Continued Log In Procedure, If the passcode entered in Step 5 is correct, the following message is shown. (continued) <ENTER> a Passcode followed by <ENTER> ACCESS GRANTED After a brief pause, the system displays the granted access level, such as the level 2 message shown below. - Page 51 Logging In and Out of the System, Continued Log Out Procedure, 3. Press the <2> key. After a brief pause, the display shows a message similar to the one (continued) below. 1 = Login 2 = Logout CURRENT ACCESS REDUCED TO LEVEL 1 4.
-
Page 53: Chapter 8 Viewing And Clearing Historical Logs
Chapter 8 Viewing and Clearing Historical Logs Introduction When an abnormal condition occurs, a record of the event is placed in one of two logs generated by the system, depending on the nature of the condition. These logs are: • Historical Alarm Log •... -
Page 54: Viewing And Clearing The Historical Alarm And Fault Logs
Viewing and Clearing the Historical Alarm and Fault Logs Viewing Logs The Historical Alarm and Fault Logs can be viewed from the 4100U-S1 Operator Interface. Press the <MENU> key. Using the <NEXT> and <PREVIOUS> keys, scroll through the Main Menu items until the "Display Historical Alarm Log?"... -
Page 55: Chapter 9 Service-Related Operations
Chapter 9 Service-Related Operations Introduction This chapter describes service-related status and control procedures. In this Chapter Refer to the page number listed in this table for information on a specific topic. Topic See Page # Setting Time and Date Displaying Software Revision Viewing Card Status Information Displaying Network Node Information Lamp Test... -
Page 56: Setting Time And Date
Setting Time and Date Procedure Follow these steps to set the time and date on the panel. Press the <MENU> key. Press the <NEXT> or <PREVIOUS> key until the display shows the option for setting the time and date. Press <NEXT> or <PREVIOUS> to Scroll Set Time and Date? Press the <ENTER>... -
Page 57: Displaying Software Revision
Displaying Software Revision Overview Follow these steps to display software revision information. 1. Press the MENU key. 2. Press the <NEXT> or <PREVIOUS> keys until the prompt reads, “Display Software Revision Level?” 3. Press <ENTER>. A display similar to the following appears. SYS REV: 11.02.08 CFIG FORMAT: 112 JOB: JOB1... -
Page 58: Viewing Card Status Information
Viewing Card Status Information Overview Every card, including the Master Controller and all option cards, has a series of Card Status Points associated with it. For the SPS (System Power Supply) these points include System Voltage, System Current, Battery Voltage, etc. Procedure 1. -
Page 59: Displaying Network Node Information
Displaying Network Node Information Overview Network systems consist of multiple panels linked via a 4120 network. Each panel includes a programmer-defined node number, used to identify the panel on the network. The following section describes how to determine a panel’s node number. The node number is required when selecting a network point. -
Page 60: Lamp Test
The “LAMP TEST” push-button on the Operator Interface is used to determine local lamp (LED) failures within the system. LEDs on the 4100U-S1 Operator Interface and Switch/LED Display Modules illuminate. All segments on the LCD also change to squares. Perform the following procedures to determine LED or LCD failures. -
Page 61: Displaying Idnet & Mapnet Device Status
IDNet device address, press the <MORE INFO> key on the operator interface panel to display additional device information. IDNet Point Each IDNet device must have a point address in order to communicate with the 4100U-S1 Addressing FIP. These point addresses along with their custom labels are located in the Programmers Report. -
Page 62: Truealarm Sensor Display Values
Displaying IDNet & Mapnet Device Status, Continued TrueAlarm Sensor Press the <MORE INFO> key to obtain the next display: Display Values, (continued) Device Address: 3-1 IDNet Device: M1-1 Press the <NEXT> key to obtain the next display: 1-Force on card LED Type: IDNet IDNet CARD Pressing key <1>... - Page 63 4100U-S1 system printer. Printing of peak values is done at the time the peak value is received at the FIP. This peak value is helpful in determining if a sensor should...
-
Page 65: Chapter 10 System Test Procedures
Chapter 10 System Test Procedures Introduction The following test features can be used when commissioning after the system is installed, and during periodic testing as required by code. Refer to Chapter 12, Maintenance Procedures for detail on these. In this Chapter Refer to the page number listed in this table for information on a specific topic. -
Page 66: Walk Test
Walk Test™ mode and return to normal. WalkTest™ by The 4100U-S1 will support up to eight Walk Test™ groups. This allows the building to be Group divided into small portions for the Walk Test™, and allows the rest of the building to be protected by the fire alarm panel. -
Page 67: Silent Walk Test
Walk Test™, Continued Zone Coding Option, (continued) = Zone 3 (three long pulses) = Zone 12 (one long, pause, two long pulses) = Zone 20 (two long and two short pulses) = Zone 102 (one long, two short, and two long pulses) NOTE: Zero Code = 2 short pulses. -
Page 68: Walk Test Operation
The second line of the LCD shows device status. Walk Test Operation When the 4100U-S1 system is placed in Walk Test™ mode, any zone in the active Walk Test™ group(s) can be tested in any order. If zone coding is enabled, there is an advantage in testing all devices within one zone before going on to the next zone. -
Page 69: Walk Test™ Features
Walk Test™ FEATURES Introduction The Walk Test™ function has the following features: • Abort Audible and Delay on Reactivation • Active/Not Active • Auto Abort on Alarm • Auto Abort on Time-out • Control Lists • Delay Before Reset • Log/No Log (Logging Option) •... -
Page 70: Delay Before Reset
Walk Test™ FEATURES, Continued Delay Before Reset The programmer has the ability to set a Reset Time Delay. The delay time period starts after a zone alarm is detected and runs until the detector is reset. The length of the delay may be from 15 to 60 seconds, and may be adjusted depending on the method used to simulate an alarm. -
Page 71: Fault Audible
Walk Test™ FEATURES, Continued Fault Audible When a zone fault is detected, the Walk Test™ signals sound continuously for four seconds. Zone Code/Zero The <3> key is used to enable/disable Zone Coding. By default, Zone Coding is enabled. Code 10-7... -
Page 72: Walk Test™ Procedures
Walk Test™ PROCEDURES Walk Test™ PROCEDURES, Continued How to Enter Walk Once the passcode has been entered, you may enter the Walk Test™ mode by performing the Test Mode following procedures. 1. Press the <MENU> key. The LCD shows the following message. Press <NEXT>... -
Page 73: How To Enter Walk Test Mode
7. Press <2> to log out. 8. If Access Level 4 was entered, a fault will continue to exist in the system. Access Level 4 is normally used by Simplex personnel and additional steps must be performed. Call Simplex to restore the system. -
Page 74: How To Turn A Point Off
Walk Test™ PROCEDURES, Continued How to Turn a Point The <OFF> key press will turn a control point off and prevent the automatic override, thus causing it to remain OFF. This action will result in a system fault. The normal state of all control points is AUTO. -
Page 75: How To Turn A Point On
Walk Test™ PROCEDURES, Continued How to Turn a Point To turn a point ON, perform the following procedures. On, (continued) 1. Ensure the point to be turned ON is shown on the alphanumeric display. A typical point (SIG2) is shown below. MASTER SIGNAL POINT 2, SIG2 SIGNAL CIRCUIT 2. -
Page 76: How To Enable A Disabled Point
Walk Test™ PROCEDURES, Continued How to Return a Press the <AUTO> key. A typical display is shown below. Point to Auto, (continued) Press <ENTER> for AUTOmatic control SIGNAL CIRCUIT: SIG2 Press the <ENTER> key. A typical display is shown below. MASTER SIGNAL POINT 2, SIG2 SIGNAL CIRCUIT 4. -
Page 77: What To Do In Case Of System Malfunction
5. Press the <C/EXIT> key to exit. This will allow the panel to show the Time and Date. What to do in Case CALL YOUR LOCAL SIMPLEX BRANCH OFFICE, WHICH IS LISTED IN THE of System YELLOW PAGES, FOR ALL MALFUNCTIONS, OR IF YOU WOULD LIKE A... -
Page 79: Chapter 11 Printing Reports
Chapter 11 Printing Reports Introduction This chapter describes printer options and how to print a report. In this Chapter Refer to the page number listed in this table for information on a specific topic. Topic See Page # Setting Printer Options 11-2 Printing a Report 11-3... -
Page 80: Setting Printer Options
Setting Printer Options Available Options The 4100U-S1 includes two printer options: Select Report Printer and Terminate Current Report. Follow these steps to set these options. 1. Press the <MENU> key. 2. Press the <NEXT> and <PREVIOUS> keys until the prompt reads, “Printer Options?”... -
Page 81: Printing A Report
Printing a Report Overview The system can generate any of the following reports. Report Description Report includes all information contained in the alarm Alarm History Log Report history log – device custom label, time and date device entered alarm. Report includes all information contained in the fault Fault History Log Report history log –... - Page 82 11-4...
-
Page 83: Chapter 12 Maintenance Procedures
Chapter 12 Maintenance Procedures Introduction It is a requirement of AS1851 - Part 8, Maintenance of Fire Protection Equipment, that tests be carried out to ensure the system is fully functional. The owner or tenant of the premises usually carries out the weekly test described. The maintenance company, under a Service Agreement, typically carries out the monthly and annual tests. -
Page 84: Weekly Tests
Weekly Tests Procedure Weekly tests should be conducted and should include the following: Carry out a fire alarm call by simulating an alarm on detector zones as follows; 1. Isolate any system outputs you wish not to respond to the testing of the system, such as the external bell (using the <EXT BELL ISOLATE>... -
Page 85: Monthly Tests
Monthly Tests Procedure In addition to the weekly test specified previously, the following inspection and testing procedures should be carried out each month: Check all battery terminals and electrolyte levels, where appropriate. Maintain all batteries in a serviceable condition. b. Check condition of battery enclosure for corrosion and ensure the batteries are stored in a safe and secure condition. -
Page 86: Annual Tests
Annual Tests Procedure The annual tests consist of all the inspection and testing procedures specified in the previous clause and the following: Visually inspect all detectors and sampling points for any condition which is likely to adversely affect their operation, such as excessive deposition of dust or coating with paint. b.
