Table of Contents

Advertisement

Quick Links

See also: Quick Reference Manual
PATRIOT 2009 owner's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2009 Patriot and is the answer not in the manual?

Questions and answers

Related Manuals for Jeep 2009 Patriot

Summary of Contents for Jeep 2009 Patriot

  • Page 1 PATRIOT 2009 owner’s manual...

  • Page 2: Vehicles Sold In Canada

    VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name Chrysler LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution there- fore. DRIVING AND ALCOHOL Drunken driving is one of the most frequent causes of accidents.

  • Page 3: Introduction

    TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...

  • Page 5: Table Of Contents

    CONTENTS Introduction ......4 Rollover Warning ......4 How To Use This Manual .

  • Page 6: Introduction

    4 INTRODUCTION INTRODUCTION This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by a Warranty Information Booklet and various customer-oriented documents. You are urged to read these publications carefully.

  • Page 7: How To Use This Manual

    Rollover Warning Label Failure to use driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year and could reduce disabling injuries by two million annually.
  • Page 8 6 INTRODUCTION...

  • Page 9: Warnings And Cautions

    INTRODUCTION 7 WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.

  • Page 10: Vehicle Modifications/Alterations

    8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
  • Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Locking Doors With The Key .
  • Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Key Unlock, Driver Door/All First Press ......21 Illuminated Approach —...
  • Page 13 Enhanced Driver Seat Belt Reminder System (BeltAlert ) ......46 Seat Belt Extender ..... 47 Seat Belts And Pregnant Women .

  • Page 14: Things To Know Before Starting Your Vehicle

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The authorized dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys. Ask your authorized dealer for these numbers and keep them in a safe place.
  • Page 15 Ignition Switch Positions 1 — LOCK 3 — ON 2 — ACC (ACCESSORY) 4 — START NOTE: If you try to remove the key before you place the shift lever in PARK, the key may become trapped tem- porarily in the ignition switch cylinder. If this occurs, rotate the key to the right slightly, then remove the key as THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 described.
  • Page 16 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! An unlocked car is an invitation to thieves. Always remove the key from the ignition and lock all the doors when leaving the vehicle unattended. Manual Transmission 1. Turn the ignition switch to the ACC (Accessory) position.

  • Page 17: Locking Doors With The Key

    Locking Doors With The Key You can insert the key with either side up. To lock the door, turn the key to the right. To unlock the door, turn the key to the left. Refer to “Body Lubrication” under “Maintenance Procedures” in Section 7. Key-In-Ignition Reminder Opening the driver’s door when the key is in the ignition sounds a signal to remind you to remove the key.

  • Page 18: Sentry Key

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SENTRY KEY The Sentry Key Immobilizer System prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked.

  • Page 19: Replacement Keys

    Exxon/Mobil Speedpass™, additional Sentry Keys , or any other transponder-equipped components on the same key chain will not cause a key-related (transponder) fault unless the additional part is physi- cally held against the ignition key being used when starting the vehicle. Cell phones, pagers, or other Radio Frequency (RF) electronics will not cause inter- ference with this system.

  • Page 20: Customer Key Programming

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Customer Key Programming If you have two valid Sentry Keys , you can program new Sentry Keys to the system by performing the following procedure: 1. Cut the additional Sentry Key Transponder blank(s) to match the ignition switch lock cylinder key code.

  • Page 21: General Information

    NOTE: If a programmed key is lost, see your authorized dealer to have all remaining keys erased from the sys- tem’s memory. This will prevent the lost key from starting your vehicle. The remaining keys must then be reprogrammed. All vehicle keys must be taken to an authorized dealer at the time of service to be reprogrammed.

  • Page 22: To Disarm The System

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. The Vehicle Security Light in the instrument cluster will flash rapidly for approximately 16 seconds. This shows that the system is arming. During this period, if a door is opened, the ignition switch is turned ON, or the power door locks are unlocked in any manner, the Vehicle Security Alarm will automatically disarm.

  • Page 23: To Unlock The Doors And Liftgate

    Three Button RKE Transmitter NOTE: The line of transmission must not be blocked with metal objects. To Unlock The Doors And Liftgate Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door, or twice within five seconds to unlock all doors and liftgate.

  • Page 24: Illuminated Approach - If Equipped

    22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Release both buttons at the same time. 3. Test the feature while outside of the vehicle by press- ing the LOCK/UNLOCK buttons on the RKE transmitter with the ignition switch in the LOCK position and the key removed.

  • Page 25: Flash Lights With Remote Key Lock/Unlock

    For vehicles not equipped with the EVIC, perform the following steps: 1. Press the LOCK button on a programmed RKE trans- mitter for at least 4 seconds, but no longer than 10 sec- onds. Then, press the PANIC button while still holding the LOCK button.

  • Page 26: Using The Panic Alarm

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Test the feature while outside of the vehicle by press- ing the LOCK/UNLOCK buttons on the RKE transmitter with the ignition switch in the LOCK position and the key removed. 4. Repeat these steps if you want to return this feature to its previous setting.

  • Page 27: Rke Transmitter Battery Replacement

    2. This device must accept any interference that may be received including interference that may cause undesired operation. NOTE: Changes or modifications not expressly ap- proved by the party responsible for compliance could void the user’s authority to operate the equipment. If your RKE transmitter fails to operate from a normal distance, check for these two conditions: 1.

  • Page 28: Door Locks

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Remove and replace the batteries. Avoid touching the new batteries with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3. To reassemble the RKE transmitter case, snap the two halves together.

  • Page 29: Power Door Locks

    WARNING! (Continued) When leaving the vehicle, always remove the key from the ignition lock and lock your vehicle. Do not leave unattended children in the vehicle or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause severe per- sonal injuries and death.
  • Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Door Locks — If Equipped The doors will lock automatically on vehicles with power door locks if all of the following conditions are met: 1. The Auto Lock feature is enabled. 2.
  • Page 31 5. Repeat these steps if you want to return this feature to its previous setting. NOTE: If you do not hear the chime it means that the system did not enter the programming mode and you will need to repeat the procedure. Use the Automatic Unlock Doors On Exit feature in accordance with local laws.
  • Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If you do not hear the chime it means that the system did not enter the programming mode and you will need to repeat the procedure. Use the Automatic Unlock Doors On Exit feature in accordance with local laws.

  • Page 33: Child-Protection Door Lock System (Rear Doors) - If Equipped

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 Child-Protection Door Lock System (Rear Doors) — If Equipped Insert the tip of the ignition key into the lock and rotate to the LOCK or UNLOCK position. Child-Protection Door Lock Function Child-Protection Door Lock Location...

  • Page 34: Power Windows - If Equipped

    32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged. NOTE: For emergency exit with the system engaged, move the lock plunger up (unlocked position), roll down the window and open the door with the outside door handle.

  • Page 35: Auto Down

    controls on each passenger door trim panel, which oper- ate the passenger door windows. The window controls will operate when the ignition switch is in the ON or ACC position. NOTE: For vehicles not equipped with the Electronic Vehicle Information Center (EVIC), the power window switches will remain active for 45 seconds after the ignition switch is turned to the LOCK position.

  • Page 36: Window Lockout Switch

    34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window Lockout Switch The window lockout switch on the driver’s door allows you to disable the window control on the other doors. To disable the window controls on the other doors, press the window LOCKOUT switch.
  • Page 37 Opening The Liftgate NOTE: In the event of a power malfunction, or the RKE transmitter is inoperative, insert the key into the liftgate lock cylinder and turn to the right (manual lock models only). Using the liftgate handle, pull the liftgate open with one fluid motion.

  • Page 38: Occupant Restraints

    36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Gas props support the liftgate in the open position. However, because the gas pressure drops with tempera- ture, it may be necessary to assist the props when opening the liftgate in cold weather. OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems.

  • Page 39: Lap/Shoulder Belts

    ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times. Lap/Shoulder Belts All the seats in your vehicle are equipped with Lap/ Shoulder Belts. The belt webbing retractor is designed to lock during very sudden stops or collisions.
  • Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your pas- sengers safe, too.
  • Page 41 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Inserting Latch Plate Into Buckle THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 WARNING! A belt that is buckled into the wrong buckle will not protect you properly.
  • Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) A belt that is worn under your arm is very danger- ous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries.
  • Page 43 WARNING! A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap belt as low as possible and keep it snug.

  • Page 44: Adjustable Upper Shoulder Belt Anchorage

    42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Adjustable Upper Shoulder Belt Anchorage In the front seat, the shoulder belt can be adjusted upward or downward to position the belt away from your neck. Push the anchorage button to release the anchorage, and move it up or down to the position that fits you best.
  • Page 45 Mini-Latch Stowage 2. Grasp the mini-latch plate and pull the belt over the seat. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 3. Route the shoulder belt to the inside of the right head restraint. Routing The Rear Center Shoulder Belt...
  • Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Routing The Rear Center Shoulder Belt 4. When the belt is long enough to fit, insert the mini- latch plate into the mini-buckle until you hear a “click.” 5. Sit back in the seat. Slide the regular latch plate up the webbing as far as necessary to allow the belt to go around your lap.
  • Page 47 on the shoulder belt. To loosen the lap belt if it is too tight, pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision. Rear Center Seat Belt Buckled 8. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck.

  • Page 48: Seat Belt Pretensioners

    46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE slide the latch plate down the webbing to allow the belt to retract fully. Insert the mini-latch plate into the slot provided in the trim panel. Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to automatically remove any slack from the seat belts in the event of a collision.

  • Page 49: Seat Belt Extender

    BeltAlert can be enabled or disabled by your authorized dealer or by following these steps: NOTE: The following steps must occur within the first 60 seconds of the ignition switch being turned to the ON or START position. Chrysler LLC does not recommend deactivating the Enhanced Warning System (BeltAlert ).

  • Page 50: Seat Belts And Pregnant Women

    48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the seat belt is not long enough when it is worn low and snug, and in the recommended seating positions.
  • Page 51 Front Airbags and Knee Bolsters 1 — Driver and Passenger Airbag 2 — Knee Boltser NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment. The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity.
  • Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Airbag covers may not be obvious in the interior trim; but they will open to allow airbag deployment. WARNING! Do not put anything on or around the front airbag covers or attempt to manually open them. You may damage the airbags and you could be injured because the airbags are no longer functional.
  • Page 53 Along with the seat belts, front airbags work with the instrument panel knee impact bolsters to provide im- proved protection for the driver and front passenger. Side curtain airbags also work with seat belts to improve occupant protection. The seat belts are designed to protect you in many types of collisions.
  • Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. If a child from 1 to 12 years old must ride in the front passenger seat because the vehicle is crowded, move the seat as far back as possible, and use the proper child restraint (refer to information on Child Restraint in this section).
  • Page 55 Airbag System Components The airbag system consists of the following: Occupant Restraint Controller (ORC) Side Remote Acceleration Sensors (if equipped) Airbag Warning Light Driver Airbag Front Passenger Airbag Supplemental Side Curtain Airbags above side win- dows (if equipped) Steering Wheel and Column Instrument Panel Interconnecting Wiring Seat Belt Reminder Light...
  • Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The ORC also turns on the Airbag Warning Light in the instrument panel for six to eight seconds as a self-check when the ignition is first turned on. After the self-check, the Airbag Warning Light will turn off.
  • Page 57 The Side Impact SRS Side Curtain Airbag is designed to activate only in certain side collisions. When the ORC (with side impact option) detects a collision requiring the side curtain airbag to inflate, it signals the inflators on the crash side of the vehicle. A quantity of nontoxic gas is generated to inflate the side curtain airbag.
  • Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE However, if you haven’t healed significantly within a few days, or if you have any blistering, see your doctor immediately. As the airbags deflate, you may see some smoke-like particles. The particles are a normal by-product of the process that generates the nontoxic gas used for airbag inflation.
  • Page 59 Maintaining Your Airbag System WARNING! Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper passenger side of the instrument panel.

  • Page 60: Event Data Recorder (Edr)

    58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Event Data Recorder (EDR) In the event of an accident, your vehicle is designed to record up to five seconds of specific vehicle data param- eters (see list below) in an event data recorder prior to the moment of airbag deployment, or near-deployment, and up to a quarter second of high-speed deceleration data during and/or after airbag deployment or near-...
  • Page 61 upon request. General data that does not identify par- ticular vehicles or crashes may be released for incorpo- ration in aggregate crash databases, such as those main- tained by the U.S. government and various states. Data of a potentially sensitive nature, such as would identify a particular driver, vehicle, or crash, will be treated confi- dentially.

  • Page 62: Child Restraint

    60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Cruise control status Traction/stability control status Tire pressure monitoring system status Child Restraint Everyone in your vehicle needs to be buckled up at all times — babies and children, too. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
  • Page 63 Infants And Small Children There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat owner’s manual to ensure you have the correct seat for your child.
  • Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The belt-positioning booster seat is for children weigh- ing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s cushion while the child’s back is against the seatback;...
  • Page 65 Here are some tips on getting the most out of your child restraint: Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards. We also recommend that you make sure that you can install the child restraint in the vehicle where you will use it, before you buy it.
  • Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Buckle the child into the seat according to the child restraint manufacturer’s directions. When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it from the vehicle. Don’t leave it loose in the vehicle.
  • Page 67 the vehicle’s seat belt for the outboard position, but you must use the vehicle’s seat belt at the center position. If your child restraints are not LATCH-compatible, you can only install the child restraints using the vehicle’s seat belts. Please refer to Installing the Child Restraint System for typical installation instructions.
  • Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: When using the LATCH attaching system to install a child restraint, please ensure that all seat belts not being used for occupant restraints are stowed and out of reach of children. It is recommended that before installing the child restraint, buckle the seat belt so the seat belt is tucked behind the child restraint and out of reach.
  • Page 69 Rear Seat Tether Anchors Not all child restraint systems will be installed as we have described here. Again, carefully follow the instruc- tions that come with the child restraint system. NOTE: If your child restraint seat is not LATCH com- patible, install the restraint using the vehicle seat belts.

  • Page 70: Engine Break-In Recommendations

    68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the shoulder belt contacts the face or neck, move the child closer to the center of the vehicle. Never allow a child to put the shoulder belt under an arm or behind their back.

  • Page 71: Safety Checks You Should Make Inside The Vehicle

    SAFETY TIPS Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing CO, fol- low these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area.

  • Page 72: Periodic Safety Checks You Should Make Outside The Vehicle

    70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light The light should come on and remain on for six to eight seconds as a bulb check when the ignition switch is first turned ON. If the LED is not lit during starting, have it checked.

  • Page 73: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......75 Inside Day/Night Mirror ....75 Automatic Dimming Inside Mirror —...
  • Page 74 72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Recognition System (VR) — If Equipped......109 Voice Recognition System (VR) Operation .
  • Page 75 Map/Reading Lights ....129 Windshield Wipers And Washers ..130 Windshield Wiper Operation ... . 130 Intermittent Wiper System .
  • Page 76 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Closing The Sunroof ....144 Pinch Protect Feature ....144 Pinch Protect Override .

  • Page 77: Mirrors

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of vehicle).

  • Page 78: Automatic Dimming Inside Mirror

    76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Inside Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.

  • Page 79: Outside Mirror - Driver's Side

    Outside Mirror — Driver’s Side Adjust the flat (drivers side) outside mirror to center on the adjacent lane of traffic with a slight overlap of the view obtained on the inside mirror. Drivers Side Mirror Directions UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77 Outside Mirror —...

  • Page 80: Folding Outside Mirrors - If Equipped

    78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side mirror could cause you to collide with another vehicle or other object.

  • Page 81: Power Mirrors - If Equipped

    Power Mirrors — If Equipped The power mirror controls are located on the drivers door trim panel. Power Mirror Control UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 To adjust a mirror, turn the control wand toward the left or right mirror positions indicated. Tilt the control wand in the direction you want the mirror to move.

  • Page 82: Vanity Mirrors - If Equipped

    80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Vehicles and other objects seen in the right side convex mirror will look smaller and farther away than they really are. Relying too much on your right side mirror could cause you to collide with another vehicle or other object.

  • Page 83: Hands-Free Communication (Uconnect ) - If Equipped

    For UConnect customer support, visit the following websites: www.chrysler.com/uconnect www.dodge.com/uconnect www.jeep.com/uconnect or call 1–877–855–8400 UConnect allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone for private conversation.
  • Page 84 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UConnect features Bluetooth technology - the global standard that enables different electronic devices to con- nect to each other without wires or a docking station, so UConnect works no matter where you stow your cellu- lar phone (be it your purse, pocket, or briefcase), as long as your phone is turned on and has been paired to the vehicle’s UConnect...

  • Page 85: Operation

    The radio display will be used for visual prompts from the UConnect system such as CELL or caller ID on certain radios. Operation Voice commands can be used to operate the UConnect system and to navigate through the UConnect menu structure.
  • Page 86 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To activate the UConnect system from idle, simply press the PHONE button and follow the audible prompts for directions. All UConnect system sessions begin with a press of the PHONE button on the radio control head. Cancel Command At any prompt, after the beep, you can say Cancel and you will be returned to the main menu.
  • Page 87 You will then be asked to give your cellular phone a priority level between one and seven, with one being the highest priority. You can pair up to seven cellular phones to your UConnect system. However, at any given time, only one cellular phone can be in use, connected to your UConnect system.
  • Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE or downloaded phonebook. To learn how to store a name in the phonebook, refer to Add Names to Your UConnect Phonebook, in the phonebook. The UConnect system will confirm the name and then dial the corresponding phone number, which may appear in the display of certain radios.
  • Page 89 Phonebook Download – Automatic Phonebook Transfer From Mobile Phone If equipped and specifically supported by your phone, UConnect automatically downloads names (text names) and number entries from the mobile phone’s phonebook. Specific Bluetooth Phones with Phone Book Access Profile may support this feature. See UConnect website for supported phones.
  • Page 90 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phonebook Download — Single Entry If equipped and supported by your phone, UConnect allows the user to download entries from their phone via Bluetooth . To use this feature, press the PHONE button and say “Phonebook Download.”...
  • Page 91 You will then be asked for the name of the phonebook entry that you wish to edit. Next, choose the number designation (home, work, mobile, or pager) that you wish to edit. When prompted, recite the new phone number for the phonebook entry that you are editing.
  • Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you enter the name, the UConnect system will ask you which designation you wish to delete: home, work, mobile, pager, or all. Say the designation you wish to delete. Note that only the phonebook entry in the current language is deleted.

  • Page 93: Phone Call Features

    The UConnect system will then prompt you as to the number designation you wish to call. The selected number will be dialed. Phone Call Features The following features can be accessed through the UConnect system if the feature(s) are available on your cellular service plan.
  • Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Making a Second Call While Current Call is in Progress To make a second call while you are currently on a call, press the VOICE RECOGNITION button and say Dial or Call followed by the phone number or phonebook entry you wish to call.
  • Page 95 Call Termination To end a call in progress, momentarily press the PHONE button. Only the active call(s) will be terminated and if there is a call on hold, it will become the new active call. If the active call is terminated by the far end, a call on hold may not become active automatically.

  • Page 96: Uconnect System Features

    94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UConnect System Features Language Selection To change the language that the UConnect system is using: Press the PHONE button to begin. After the Ready prompt and the following beep, say the name of the language you wish to switch to English, Espanol, or Francais.
  • Page 97 NOTE: The emergency number dialed is based on the country where the vehicle is purchased (911 for the U.S. and Canada and 060 for Mexico). The number dialed may not be applicable with the available cellular service and area. If supported, this number may be programmable on some systems.
  • Page 98 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The towing assistance number dialed is based on the country where the vehicle is purchased (1-800-528- 2069 for the U.S., 1-877-213-4525 for Canada, 55-14- 3454 for Mexico City and 1-800-712-3040 for outside Mexico City in Mexico).
  • Page 99 or sequence of numbers, followed by Send, is also to be used for navigating through an automated customer service center menu structure, and to leave a number on a pager. You can also send stored UConnect phonebook entries as tones for fast and easy access to voice mail and pager entries.
  • Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After the Ready prompt and the following beep, say Setup Confirmations. The UConnect system will play the current confirmation prompt status and you will be given the choice to change it. Phone and Network Status Indicators If available on the radio and/or on a premium display such as the instrument panel cluster, and supported by your cellular phone, the UConnect system will provide...

  • Page 101: Advanced Phone Connectivity

    In order to un-mute the UConnect system: Press the VOICE RECOGNITION button. Following the beep, say Mute off. Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect system allows ongoing calls to be trans- ferred from your cellular phone to the UConnect system without terminating the call.

  • Page 102: Things You Should Know About Your Uconnect System

    100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Select Another Cellular Phone This feature allows you to select and start using another phone paired with the UConnect system. Press the PHONE button to begin. After the Ready prompt and the following beep, say Setup Select Phone and follow the prompts.
  • Page 103 Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the UConnect system Voice Training feature may be used. To enter this training mode, follow one of the two following proce- dures: From outside the UConnect mode (e.g., from radio mode): Press and hold the VOICE RECOGNITION button for...
  • Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Performance is maximized under: low-to-medium blower setting, low-to-medium vehicle speed, low road noise, smooth road surface, fully closed windows, dry weather condition. Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some.
  • Page 105 low road noise, smooth road surface, fully closed windows, dry weather conditions, and operation from the driver’s seat. Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the UConnect system. Echo at the far end can sometimes be reduced by lowering the in-vehicle audio volume.
  • Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105...
  • Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 109 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
  • Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...

  • Page 111: General Information

    General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When you press the VR hard-key, you will hear a beep. The beep is your signal to give a command. NOTE: If you do not say a command within a few seconds, the system will present you with a list of options.

  • Page 113: Commands

    Commands The Voice Recognition system understands two types of commands. Universal commands are available at all times. Local commands are available if the supported radio mode is active. Changing the Volume 1. Start a dialogue by pressing the VR hard-key. 2.
  • Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio FM To switch to the FM band say “FM” or “Radio FM”. In this mode, you may say the following commands: “Frequency” (to change the frequency) “Next Station” (to select the next station) “Previous Station”...
  • Page 115 Memo To switch to the voice recorder mode say “Memo”. In this mode, you may say the following commands: “New Memo” (to record a new memo) — During the recording you may press the VR hard-key to stop recording. You proceed by saying one of the following commands: −...

  • Page 116: Voice Training

    114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the UConnect system Voice Training feature may be used. 1. Press the VR hard-key, say “System Setup” and once you are in that menu then say “Voice Training.”...

  • Page 117: Manual Seat Height Adjustment - If Equipped

    Using body pressure, move forward and rearward on the seat to be sure the seat adjusters have latched. WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured.

  • Page 118: Manual Lumbar - If Equipped

    116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Lumbar — If Equipped The lumbar adjustment handle is located on the outboard side of the driver’s seat. To increase or decrease support, rotate the handle up or down. Lumbar Adjustment Driver’s Seatback Recline To recline: 1.

  • Page 119: Adjustable Head Restraints

    Adjustable Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear. Pull up or push down on the head restraints so that the upper edge is as high as practical. To raise the head restraint, pull up on the head restraint.
  • Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After turning the ignition ON, you can choose from High, Low, or Off heat settings. Amber indicator lights in each switch indicate the level of heat in use. Two indicator lights will illuminate for High, one for Low, and none for Off.

  • Page 121: Fold-Flat Front Passenger Seat

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Fold-Flat Front Passenger Seat To fold the front passenger seat, lift the recliner handle to the full upward position and push the seatback forward until it rests on the seat cushion. Front Passenger Seat Folded Flat Fold-Flat Front Passenger Seat Handle...

  • Page 122: Folding Rear Seat

    120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Rear Seat To provide additional storage area, each rear seatback can be folded forward. Pull the strap forward to move the seat forward and flat. Folding Rear Seat Rear Seats Folded Flat Reclining Rear Seat —...

  • Page 123: To Open And Close The Hood

    WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seri- ously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts.
  • Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Move the safety catch located under the front edge of the hood, near the center and raise the hood. Safety Catch Lift the hood prop rod, clipped to the right side (left side facing hood) of the engine compartment, to secure the hood in the open position.

  • Page 125: Lights

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 LIGHTS Multifunction Lever The multifunction lever controls the operation of the headlights, parking lights, turn signals, headlight beam selection, instrument panel light dimming, interior lights, the passing lights, and the fog lights. The multifunction lever is located on the left side of the steering column.

  • Page 126: Lights-On Reminder

    124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To change the brightness of the instrument panel lights, rotate the center portion of the multifunction lever up or down. Dimmer Control Lights-On Reminder If the headlights or parking lights are left on after the ignition is turned OFF, a chime will sound to alert the driver when the driver’s door is opened.

  • Page 127: Daytime Running Lights (Drl) - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 NOTE: The fog lights will only operate with the head- lights on Low beam. Selecting High beam headlights will turn off the fog lights. Daytime Running Lights (DRL) — If Equipped The High beam lights will come on as Daytime Running Lights (DRL) at DRL intensity (lower), whenever the ignition is ON, the engine is running, the headlight switch is off, the parking brake is off, the turn signal is...

  • Page 128: Turn Signals

    126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signals Move the multifunction lever up or down and the arrows on each side of the instrument cluster flash to show proper operation of the front and rear turn signal lights. You can signal a lane change by moving the lever partially up or down without moving beyond the detent.

  • Page 129: Flash-To-Pass

    High Beam/Low Beam Control Flash-to-Pass You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward you. This will cause the headlights to turn on at High beam and remain on until the lever is released. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 NOTE: If the multifunction lever is held in the flash-to- pass position for more than 30 seconds, the High beams...
  • Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The auxiliary Off-Road lights can be turned on when off-road conditions require additional lighting. To turn the auxiliary Off-Road light on, turn on the High beam headlights and press the top of the switch. To turn off the auxiliary Off-Road lights press the bottom of the switch.

  • Page 131: Map/Reading Lights

    Map/Reading Lights These lights are mounted between the sun visors above the rear view mirror. Each light is turned on by pressing the button. Press the button a second time to turn the light off. The lights also come on when a door is opened or the dimmer control is turned fully upward, past the second detent.

  • Page 132: Windshield Wipers And Washers

    130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS The wipers and washers are operated by a switch on the control lever. The lever is located on the right side of the steering column. Windshield Wiper Operation Turn the end of the handle to select the desired wiper speed.

  • Page 133: Intermittent Wiper System

    Intermittent Wiper System Use the intermittent wiper when weather conditions make a single wiping cycle, with a variable pause be- tween cycles, desirable. Select the delay interval by turning the end of the lever. Rotate the knob upward (clockwise) to decrease the delay time and downward (counterclockwise) to increase the delay time.

  • Page 134: Mist Feature

    132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mist Feature Push down on the wiper control lever to activate a single wipe to clear the windshield of road mist or spray from a passing vehicle. As long as the lever is held down, the wipers will continue to operate.

  • Page 135: Tilt Steering Column

    TILT STEERING COLUMN To tilt the steering column, push down on the lever below the turn signal control lever. With one hand firmly on the wheel, move the steering column up or down as desired. Push the lever back up to lock the column firmly in place. Tilting Steering Column Control UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 WARNING!

  • Page 136: Electronic Speed Control - If Equipped

    134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRONIC SPEED CONTROL — IF EQUIPPED When engaged, Electronic Speed Control takes over accelerator operation at speeds greater than 25 mph (40 km/h). The Electronic Speed Control lever is located on the right side of the steering wheel. Electronic Speed Control Lever To Activate Push the ON/OFF button.

  • Page 137: To Deactivate

    NOTE: The vehicle should be traveling at a steady speed and on level ground before pressing the SET lever. To Deactivate A soft tap on the brake pedal, pulling the speed control lever toward you “CANCEL”, normal braking, or clutch pressure while slowing the vehicle, will deactivate speed control without erasing the set speed memory.

  • Page 138: Manual Transaxle

    136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Transaxle Depressing the clutch pedal will disengage the speed control. A slight increase in engine RPM before the speed control disengages is normal. Vehicles equipped with manual transaxles may need to be shifted into a lower gear to climb hills without speed loss.
  • Page 139 The HomeLink buttons that are located in the headliner or sun visor designate the three different HomeLink channels. HomeLink Buttons NOTE: HomeLink is disabled when the Vehicle Secu- rity Alarm is active. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver.

  • Page 140: Programming Homelink

    138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming HomeLink Before You Begin If you have not trained any of the HomeLink buttons, erase all channels before you begin training. To do this, press and hold the two outside buttons for 20 seconds until the red indicator flashes.
  • Page 141 After training a HomeLink channel, if the garage door does not operate with HomeLink and the ga- rage door opener was manufactured after 1995, the garage door opener may have a rolling code. If so, proceed to the heading “Programming A Rolling Code System.”...

  • Page 142: Gate Operator/Canadian Programming

    140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Firmly press and release the “Learn” or “Training” button. The name and color of the button may vary by manufacturer. NOTE: There are 30 seconds in which to initiate the next step after the “Learn” button has been pressed. 7.

  • Page 143: Using Homelink

    has successfully accepted the frequency signal. The indicator light will flash slowly and then rapidly when fully trained. If you unplugged the device for training, plug it back in at this time. Then proceed with Step 4 under “Programming HomeLink ” earlier in this section. Using HomeLink To operate, simply press and release the programmed HomeLink button.

  • Page 144: Troubleshooting Tips

    142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Troubleshooting Tips If you are having trouble programming HomeLink , here are some of the most common solutions: Replace the battery in the original transmitter. Press the “Learn” button on the Garage Door Opener to complete the training for a Rolling Code.

  • Page 145: Power Sunroof - If Equipped

    POWER SUNROOF — IF EQUIPPED The power sunroof switch is located in the reading light. Power Sunroof Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 WARNING! Never leave children in a vehicle, with the key in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch.

  • Page 146: Opening The Sunroof

    144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening the Sunroof Manual Mode To open the sunroof, press and hold the switch rearward to full open. Any release of the switch will stop the movement and the sunroof will remain in a partial open condition until the switch is pushed and held rearward again.

  • Page 147: Pinch Protect Override

    Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing, press the switch forward and hold for two seconds after the reversal occurs. This allows the sunroof to move towards the close position. NOTE: Pinch protection is disabled while the switch is pressed.

  • Page 148: Sunroof Maintenance

    146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunroof Maintenance Use only a non-abrasive cleaner and a soft cloth to clean the glass panel. Ignition Off Operation The sunroof will also operate up to 45 seconds after the ignition has been turned OFF. The sunroof operation will be canceled if either of the front doors are opened during the 45 second time period.
  • Page 149 WARNING! To avoid serious injury or death: Do not use a three-prong adapter. Do not insert any objects into the receptacles. Do not touch with wet hands. Close the lid when not in use and while driving the vehicle. If this outlet is mishandled, it may cause an electric shock and failure.

  • Page 150: Power Inverter - If Equipped

    148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED A 115-Volt (150-Watt) AC power inverter is located on the rear of the center console for added convenience. The power inverter can be used to power cell phones, elec- tronics and other low power devices.
  • Page 151 WARNING! To avoid serious injury or death: Do not use a three-prong adaptor. Do not insert any objects into the receptacles. Do not touch with wet hands. Close the lid when not in use. If this outlet is mishandled, it may cause an electric shock and failure.

  • Page 152: Cupholders

    150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Your vehicle is equipped with four cupholders. There are two cupholders located in the front. Front Cupholders There are also two cupholders located in the back for the rear passengers. Rear Cupholders...

  • Page 153: Storage

    STORAGE Glove Compartment And Storage Bin Located on the passenger side of the instrument panel are an upper storage bin and a lower glove compartment. 1 — Upper Storage Bin 2 — Lower Glove Compartment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 To open the lower glove compartment, pull outward on the release handle.

  • Page 154: Door Storage - If Equipped

    152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Door Storage — If Equipped The interior door panels are equipped with upper and lower storage areas. Rear Door Storage Front Door Storage...

  • Page 155: Console Features

    CONSOLE FEATURES The floor console contains both an upper and lower storage compartment. To open the upper storage compartment, push inward on the upper handle to unlatch the upper lid and lift the upper lid. Upper Storage Compartment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 To open the lower storage compartment, lift upward on the lower handle to unlatch the lower storage compart- ment and lift the lid open.

  • Page 156: Cargo Area Features

    154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not operate this vehicle with a console compart- ment lid in the open position. Cell phones, music players, and other handheld electronic devices should be stowed while driving. Use of these devices while driving can cause an accident due to distrac- tion, resulting in death or injury.

  • Page 157: Cargo Cover - If Equipped

    To operate the flashlight, press the switch once for high, twice for low, and a third time to return to off. Three-Press Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 Cargo Cover — If Equipped The cargo area trim panels include two notches for mounting the available tonneau cover that accommo- dates the reclining rear seat.

  • Page 158: Removable Load Floor

    156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Removable Load Floor The cargo area load floor is removable and can be washed with mild soap and water. Cargo Load Floor Cargo Tie-Down Loops There are four D-rings installed in the cargo area for securing cargo.

  • Page 159: Fold Down Speakers - If Equipped

    WARNING! (Continued) Place as much cargo as possible in front of the rear axle. Too much weight or improperly placed weight over or behind the rear axle can cause the rear of the vehicle to sway. Do not pile luggage or cargo higher than the top of the seatback.

  • Page 160: Rear Window Defroster

    158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE activate the wiper. The rear wiper operates in an inter- mittent mode only. Rotating the center of the switch all the way forward will turn on the wash function. The wash pump will continue to operate as long as the button is pressed.

  • Page 161: Roof Luggage Rack - If Equipped

    operation, press the button a second time. To prevent excessive battery drain, use the defroster only when the engine is operating. CAUTION! Use care when washing the inside of the rear window to prevent damage to heating elements. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
  • Page 162 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! To prevent damage to the roof of your vehicle, DO NOT carry any loads on the roof rack without cross rails installed. The load should be secured and placed on top of the cross rails, not directly on the roof.

  • Page 163: Understanding Your Instrument Panel

    UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....165 Instrument Cluster – Premium ... . 166 Instrument Cluster Descriptions .
  • Page 164 162 UNDERSTANDING YOUR INSTRUMENT PANEL Sales Code REQ — AM/FM Stereo Radio And 6–Disc CD/DVD Changer (MP3/WMA AUX Jack) ....190 Operating Instructions - Radio Mode ..190 Operation Instructions - (Disc Mode For CD And MP3/WMA Audio Play, DVD-Video) .
  • Page 165 Operation Instructions — CD Mode For CD And MP3 Audio Play ....223 Notes On Playing MP3 Files ... . . 225 List Button (CD Mode For MP3 Play) .
  • Page 166 164 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Sound System Controls — If Equipped......240 Radio Operation ..... 240 CD Player .

  • Page 167: Instrument Panel Features

    INSTRUMENT PANEL FEATURES 1 - Air Outlet 2 - Demisters 3 - Instrument Cluster 4 - Radio UNDERSTANDING YOUR INSTRUMENT PANEL 165 5 - Storage Bin 6 - Glove Compartment 7 - Climate Controls 8 - Power Outlet 9 - Heated Seat Switch – If Equipped 10 - Hazard Warning Flasher 11 - ESP OFF Switch –...

  • Page 168: Instrument Cluster - Premium

    166 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER – PREMIUM...

  • Page 169: Instrument Cluster Descriptions

    INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge/Fuel Door Reminder When the ignition switch is in the ON position, the pointer will show the level of fuel remain- ing in the fuel tank. The fuel pump symbol points to the side of the vehicle where the fuel door is located.
  • Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Oil Pressure Warning Light This light indicates low engine oil pressure. The light should turn on momentarily when the engine is started. If the light turns on while driving, stop the vehicle and shut off the engine as soon as possible. A chime will sound for four minutes when this light turns Do not operate the vehicle until the cause is corrected.
  • Page 171 10. Anti-Lock Brake (ABS) Light — If Equipped This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the ignition switch is turned to the ON position and may stay on for as long as four seconds. If the ABS light remains on or turns on while driving, it indicates that the Anti-Lock portion of the brake system is not functioning and that service is required.
  • Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL 13. Engine Temperature Warning Light This light warns of an overheated engine condi- tion. As temperatures rise and the gauge ap- proaches H , this indicator will illuminate and a single chime will sound after reaching a set threshold. Further overheating will cause the temperature gauge to pass H , the indicator will continuously flash and a continuous chime will occur until the engine is allowed...
  • Page 173 The dual brake system provides a reserve braking capac- ity in the event of a failure to a portion of the hydraulic system. A leak in either half of the dual brake system is indicated by the Brake Warning Light, which will turn on when the brake fluid level in the master cylinder has dropped below a specified level.
  • Page 174 172 UNDERSTANDING YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is applied with the ignition switch in the ON position. NOTE: This light shows only that the parking brake is applied. It does not show the degree of brake application. 15.
  • Page 175 WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call an authorized dealer- ship for service if your vehicle overheats. If you decide to look under the hood yourself, see Section 7 of this manual.
  • Page 176 174 UNDERSTANDING YOUR INSTRUMENT PANEL has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.) As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under-inflated.
  • Page 177 tires or wheels on your vehicle, to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly. CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle.
  • Page 178 176 UNDERSTANDING YOUR INSTRUMENT PANEL replacement, be sure to keep a record of the reading before and after the service so that the correct mileage can be determined. CHAngE OIL Message Your vehicle is equipped with an engine oil change indicator system.
  • Page 179 the key is in the ON/RUN position before engine start. If the light does not come on when turning the key from OFF to ON/RUN, have the condition checked promptly. Certain conditions such as a loose or missing gas cap, poor fuel quality, etc., may illuminate the light after engine start.
  • Page 180 178 UNDERSTANDING YOUR INSTRUMENT PANEL Lamp” comes on continuously with the engine running, a malfunction has been detected in either the ESP or the BAS system. If this light remains on after several ignition cycles, and the vehicle has been driven several miles at speeds greater than 30 mph (48 km/h), see an authorized dealer as soon as possible.

  • Page 181: Electronic Vehicle Information Center (Evic) - If Equipped

    ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) — IF EQUIPPED The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the instrument cluster. Electronic Vehicle Information Center (EVIC) UNDERSTANDING YOUR INSTRUMENT PANEL 179 The EVIC consists of the following: System status Vehicle information warning message displays Personal settings (customer-programmable features)

  • Page 182: Engine Oil Change Indicator System

    180 UNDERSTANDING YOUR INSTRUMENT PANEL When the appropriate conditions exist, the EVIC displays the following messages: Turn Signal On (with a continuous warning chime after one mile traveled) Left Front Turn Signal Light Out (with a single chime) Left Rear Turn Signal Light Out (with a single chime) Right Front Turn Signal Light Out (with a single chime) Right Rear Turn Signal Light Out (with a single chime) RKE Battery Low (with a single chime)

  • Page 183: Evic Functions

    Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the Trip Odometer button on the instrument cluster. To reset the oil change indicator system (after performing the scheduled maintenance) refer to the fol- lowing procedure.

  • Page 184: Compass/Temperature/Audio

    182 UNDERSTANDING YOUR INSTRUMENT PANEL Distance To Empty (DTE) Elapsed Time Tire Pressure Monitor (TPM) Personal Settings To Reset The Display Pressing and holding the EVIC button once will clear the function currently being displayed. Reset will only occur if a resettable function is currently being displayed. To reset all resettable functions, press and release the EVIC button a second time within three seconds of resetting the currently displayed function.

  • Page 185: Distance To Empty (Dte)

    Distance To Empty (DTE) Shows the estimated distance that can be traveled with the fuel remaining in the tank. This estimated distance is determined by a weighted average of the instantaneous and average fuel economy, according to the current fuel tank level.
  • Page 186 184 UNDERSTANDING YOUR INSTRUMENT PANEL Use the EVIC button to display one of the following choices: Language When in this display you may select different languages for all display nomenclature, including the trip functions. Pressing the EVIC button while in this display selects English, Espanol, Deutsch, Italiano, or Francais depend- ing on availability.
  • Page 187 Sound Horn with Remote Key Lock When ON is selected, a short horn sound will occur when the RKE transmitter LOCK button is pressed. This feature may be selected with or without the flash lights on lock/unlock feature. Press and hold the EVIC button when in this display until “ON”...
  • Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL Delay Power Off to Accessories Until Exit When this feature is selected the power window switches, radio, hands–free system, power sunroof, and power outlets will remain active for up to 60 minutes after the ignition switch has been turned OFF. Opening a vehicle door will cancel this feature.
  • Page 189 NOTE: Magnetic and battery powered devices, (such as cell phones, iPod’s, radar detectors, PDA’s and laptops) should be kept away from the top of the instrument panel. This is where the compass module is located and such devices may interfere and cause false compass readings.
  • Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL Compass Calibration If the compass appears erratic or inaccurate, and the variance has been properly set, you may wish to manu- ally recalibrate the compass. To manually calibrate the compass: 1. Start the engine and leave the transmission in the PARK position.

  • Page 191: Electronic Digital Clock

    ELECTRONIC DIGITAL CLOCK The clock and radio each use the display panel built into the radio. A digital readout shows the frequency and/or time in hours and minutes (depending on your radio model), whenever the ignition switch is in the ON or ACC position.

  • Page 192: Sales Code Req - Am/Fm Stereo Radio And 6-Disc Cd/Dvd Changer (Mp3/Wma Aux Jack)

    190 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE REQ — AM/FM STEREO RADIO AND 6–DISC CD/DVD CHANGER (MP3/WMA AUX JACK) NOTE: The radio sales code is located on the lower right side of the radio faceplate. REQ Radio Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
  • Page 193 SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
  • Page 194 192 UNDERSTANDING YOUR INSTRUMENT PANEL Clock Setting Procedure 1. Press and hold the TIME button until the hours blink. 2. Adjust the hours by turning the right side TUNE/ SCROLL control knob. 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes.
  • Page 195 Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the treble tones.
  • Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Religious Music Religious Talk Rock 16-Digit Character Display Cls Rock College Country Soft Rhythm and Blues Language Inform Jazz News...
  • Page 197 SETUP Button Pressing the SETUP button allows you to select between the following items: NOTE: Turn the TUNE/SCROLL control knob to scroll through the entries. Push the AUDIO/SELECT button to select an entry and make changes. DVD Enter - When the disc is in DVD Menu mode, selecting DVD Enter will allow you to play the current highlighted selection.
  • Page 198 196 UNDERSTANDING YOUR INSTRUMENT PANEL VES™ Power - Allows you to turn VES™ ON and OFF (if equipped). VES™ Lock - Locks out rear VES™ remote controls (if equipped). VES™ CH1/CH2 - Allows the user to change the mode of either the IR1 or IR2 wireless headphones by pressing the AUDIO/SELECT button (if equipped).
  • Page 199 Subtitle Language — If Equipped Selecting this item allows you to choose a default subtitle language (effective only if the language is supported by the disc). You can select a language not listed by scrolling down and selecting other. Enter the country code using the TUNE/SCROLL control knob to scroll up and down to select the number and then push to select.

  • Page 200: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)

    198 UNDERSTANDING YOUR INSTRUMENT PANEL and press and release that button. If a button is not selected within five seconds after pressing the SET but- ton, the station will continue to play but will not be stored into pushbutton memory. You may add a second station to each pushbutton by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display...
  • Page 201 CAUTION! The radio may shut down during extremely hot conditions. When this occurs, the radio will indicate “Disc Hot” and shut off until a safe temperature is reached. This shutdown is necessary to protect the optics of the DVD player and other radio internal components.

  • Page 202: Notes On Playing Mp3/Wma Files

    200 UNDERSTANDING YOUR INSTRUMENT PANEL Press and hold the EJECT button for five seconds and all CDs will be ejected from the radio. The disc can be ejected with the radio and ignition OFF. SEEK Button (CD MODE) Press the right SEEK button for the next selection on the CD.
  • Page 203 Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
  • Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL When using the MP3/WMA encoder to compress audio data to an MP3/WMA file, the bit rate and sampling frequencies in the following table are supported. In addition, variable bit rates (VBR) are also supported. The majority of MP3/WMA files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates.

  • Page 205: List Button (Disc Mode For Mp3/Wma Play)

    Number of files and folders - Loading times will increase with more files and folders To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option before writing to the disc.
  • Page 206 204 UNDERSTANDING YOUR INSTRUMENT PANEL Pressing the AUX button will change the mode to auxil- iary device if the AUX jack is connected. NOTE: The AUX device must be turned on and the device’s volume set to the proper level. If the AUX audio is not loud enough, turn the device’s volume up.

  • Page 207: Am/Fm/Cd/Dvd Multimedia System Radio (Rer/Ren) - If Equipped

    Operating Instructions - Hands-Free Phone (UConnect ) (If Equipped) Refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions - Satellite Radio Mode (If Equipped) Refer to “Satellite Radio” in this section. Operating Instructions - Video Entertainment System (VES)™ (If Equipped) Refer to separate “Video Entertainment System (VES)™...

  • Page 208: Operating Instructions - Voice Recognition System (Vr) - If Equipped

    206 UNDERSTANDING YOUR INSTRUMENT PANEL The REN and RER Multimedia systems contain a radio, CD/DVD player, USB port, and a 30-gigabyte hard drive (HDD). Sirius Satellite Radio is optional. The 6.5 in (16.5 cm) touch screen allows for easy menu selection. The RER radio also contains a Global Positioning System (GPS)-based Navigation system.
  • Page 209 4. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed. 5.

  • Page 210: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)

    208 UNDERSTANDING YOUR INSTRUMENT PANEL Touch the screen where the words “Show Time if Radio is Off” are displayed to change the current setting. Changing the Time Zone 1. Turn on the multimedia system. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen.

  • Page 211: Operating Instructions - Radio Mode

    Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio.
  • Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Adjust the minutes using the right side TUNE/ SCROLL control knob. Press the TUNE/SCROLL control knob to save time change. 5. To exit, press any button/knob, or wait five seconds. RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows.
  • Page 213 AM/FM Button Press the buttons to select either AM or FM mode. SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button. The symbol SET 1 will now show in the display window.

  • Page 214: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    212 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions — CD MODE For CD And MP3 Audio Play NOTE: The ignition switch must be in the ON or ACC position to operate the radio. This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks.
  • Page 215 EJECT Button - Ejecting a CD Press the EJECT button to eject the CD. If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF.

  • Page 216: Notes On Playing Mp3 Files

    214 UNDERSTANDING YOUR INSTRUMENT PANEL SET/RND Button (Random Play Button) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace. Press the right SEEK button to move to the next ran- domly selected track.
  • Page 217 Maximum number of characters in file/folder names: Level 1: 12 (including a separator . and a three- character extension) Level 2: 31 (including a separator . and a three- character extension) Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal CD audio tracks and computer files (including MP3 files).

  • Page 218: Operation Instructions - Auxiliary Mode

    216 UNDERSTANDING YOUR INSTRUMENT PANEL ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios. Playlist files are not supported. MP3 Pro files are not supported.

  • Page 219: Sales Code Res/Rsc - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio

    UNDERSTANDING YOUR INSTRUMENT PANEL 217 NOTE: The AUX device must be turned on and the device’s volume set to proper level. If the AUX audio is not loud enough, turn the device’s volume up. If the AUX audio sounds distorted, turn the device’s volume down. TIME Button (Auxiliary Mode) Press this button to change the display to time of day.

  • Page 220: Operating Instructions - Radio Mode

    218 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio.
  • Page 221 Phone Button (UConnect Hands-Free Phone) — If Equipped Press this button to operate the Hands-Free Phone (UConnect ) feature (if equipped). Refer to “Hands-Free Communication (UConnect )” in Section 3. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With UConnect”...
  • Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button Press the INFO button for an RDS station (one with call letters displayed). The radio will return a Radio Text message broadcast from an FM station (FM mode only). RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows.
  • Page 223 MUSIC TYPE Button Pressing this button once will turn on the Music Type mode for five seconds. Pressing the MUSIC TYPE button or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected.
  • Page 224 222 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type Sports Talk Top 40 Weather By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode.

  • Page 225: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    You may add a second station to each pushbutton by repeating the above procedure with this exception: Press the SET/RND button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
  • Page 226 224 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will show the disc number, the track number, and index time in minutes and seconds.

  • Page 227: Notes On Playing Mp3 Files

    TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press the RW button to stop the CD at the beginning of the current CD track/title. Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed.
  • Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
  • Page 229 Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.

  • Page 230: List Button (Cd Mode For Mp3 Play)

    228 UNDERSTANDING YOUR INSTRUMENT PANEL Loading times for playback of MP3 files may be affected by the following: Media - CD-RW media may take longer to load than CD-R media Medium formats - Multisession discs may take longer to load than non-multisession discs Number of files and folders - Loading times will increase with more files and folders To increase the speed of disc loading, it is recommended...

  • Page 231: Universal Consumer Interface (Uci) - If Equipped

    Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack which allows the user to plug in a portable device such as an MP3 player or cassette player and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.

  • Page 232: Connecting The Ipod

    230 UNDERSTANDING YOUR INSTRUMENT PANEL UCI supports Mini, 4G, Photo, Nano, 5G iPod iPhone devices. Some iPod software versions may not fully support the UCI features. Please visit Apple’s website for software updates. NOTE: If the radio has a USB port, connecting an iPod to this port does not play the media.

  • Page 233: Controlling The Ipod Using Radio Buttons

    The iPod can be controlled using the radio buttons to Play, Browse, and List the iPod contents. The iPod battery charges when plugged into the UCI connector. Controlling The iPod Using Radio Buttons To get into the UCI (iPod ) mode and access a connected iPod , press the ‘AUX’...

  • Page 234: List Or Browse Mode

    232 UNDERSTANDING YOUR INSTRUMENT PANEL Use the << SEEK and SEEK >> buttons to jump to the previous or next track. If the << SEEK button is pressed during the first two seconds of the track, it will jump to the previous track in the list, if you press this button at any other time in the track it will jump to the beginning of the track.
  • Page 235 Turning it clockwise (forward) and counterclock- wise (backward) scrolls through the lists, displaying the track detail on the radio display. Once you have the track to be played highlighted on the radio display, press the TUNE control knob to select and start playing the track.

  • Page 236: Satellite Radio - If Equipped (Ren/Req/Rer/Res/Reu Radios Only)

    234 UNDERSTANDING YOUR INSTRUMENT PANEL the same steps to go to the desired track in that list. Not all iPod sub-menu levels are available on this system. MUSIC TYPE button: The MUSIC TYPE button is another shortcut button to the genre listing on your iPod .

  • Page 237: System Activation

    System Activation Sirius Satellite Radio service is pre-activated and you may begin listening immediately to the one year of audio service that is included with the factory-installed satellite radio system in your vehicle. Sirius will supply a wel- come kit that contains general information, including how to setup your on-line listening account at no addi- tional charge.

  • Page 238: Selecting Satellite Mode

    236 UNDERSTANDING YOUR INSTRUMENT PANEL Next, turn the knob surrounding the joystick in the center of the radio to scroll to Subscription, and then press and release the joystick. All of the ESNs that apply to your vehicle will display. Selecting Satellite Mode Press the SAT button until SAT appears in the display.
  • Page 239 SEEK Buttons Press and release the SEEK buttons to search for the next channel in Satellite mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new channel until you make another selection.
  • Page 240 238 UNDERSTANDING YOUR INSTRUMENT PANEL MUSIC TYPE Button — Except REU Radio Pressing this button once will turn on the Music Type mode for five seconds. Pressing the MUSIC TYPE button or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected.

  • Page 241: Operating Instructions - Hands-Free Phone (If Equipped)

    SET Button – To Set the Pushbutton Memory When you are receiving a channel that you wish to commit to pushbutton memory, press the SET button. The symbol SET 1 will now show in the display window. Select the button (1-6) you wish to lock onto this channel and press and release that button.

  • Page 242: Remote Sound System Controls - If Equipped

    240 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. Remote Sound System Controls The right-hand control is a rocker type switch with a pushbutton in the center.

  • Page 243: Cd Player

    The button located in the center of the left-hand control will tune to the next preset station that you have pro- grammed in the radio preset pushbuttons. CD Player Press the top of the switch once to go to the next track on the CD.

  • Page 244: Radio Operation And Cellular Phones

    242 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If you experience difficulty in playing a particu- lar disc, it may be damaged (i.e. scratched, reflective coating removed, a hair, moisture or dew on the disc) oversized, or have theft protection encoding. Try a known good disc before considering disc player service.
  • Page 245 Climate Controls The air conditioning system of your vehicle contains R-134a, a refrigerant that does not deplete the ozone layer in the upper atmosphere. UNDERSTANDING YOUR INSTRUMENT PANEL 243 The controls are as follows: Mode Control (Air Direction) The mode control allows you to choose from several patterns of air distribution as identified by the symbols.
  • Page 246 244 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: There is a difference in temperature between the upper and lower outlets for added comfort. The warmer air goes to the floor outlets. This feature gives improved comfort during sunny but cool conditions. Floor Air is directed through the floor outlets and side window demister outlets with a small amount through the defrost outlet.
  • Page 247 NOTE: For maximum airflow to the rear seat passen- gers, the center instrument panel outlets can be aimed, so that the left center outlet is directed toward the right rear passenger and the right center outlet is directed toward the left rear passenger. Fan Control Use this control to regulate the amount of air forced through the...

  • Page 248: Air Conditioning (A/C)

    246 UNDERSTANDING YOUR INSTRUMENT PANEL Circulation Control Use this button to choose between outside air intake or recirculation of the air inside the vehicle. A lamp will illuminate when you are in recirculate mode. Only use the recirculate mode to tempo- rarily block out any outside odors, smoke, or dust and to cool the interior rapidly upon initial start...

  • Page 249: Air Filtration System - If Equipped

    MAX A/C For maximum cooling select the air direction to either the Panel or Bi-Level position using the mode control. Press the A/C button and the recirculation button so that both lamps are illuminated and set the temperature control to its coolest setting.

  • Page 250: Operating Tips

    248 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips...
  • Page 251 Window Fogging Vehicle side windows tend to fog on the inside in mild rainy or humid weather. To clear the windows, set mode to the mix or defrost position. Direct the panel outlets toward the side windows. Do not use recirculate without A/C for long periods as fogging may occur.
  • Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL Side Window Demisters A side window demister outlet is at each end of the instrument panel. These nonadjustable outlets direct air toward the side windows when the system is in either the FLOOR, MIX, or DEFROST mode. The air is directed at the area of the windows through which you view the outside mirrors.
  • Page 253 STARTING AND OPERATING CONTENTS Starting Procedures ....256 Manual Transmission — If Equipped ..256 Automatic Transmission —...
  • Page 254 252 STARTING AND OPERATING AutoStick — If Equipped ....264 Operation ......264 General Information .
  • Page 255 Parking Brake ......287 Brake System ......289 Anti-Lock Brake System (ABS) —...
  • Page 256 254 STARTING AND OPERATING Tire Chains ......318 Snow Tires ......318 Tire Rotation Recommendations .
  • Page 257 Trailer And Tongue Weight ....341 Towing Requirements ....342 Towing Tips ......347 STARTING AND OPERATING 255 Recreational Towing (Behind Motorhome, Etc.).

  • Page 258: Starting Procedures

    256 STARTING AND OPERATING STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.

  • Page 259: Extremely Cold Weather (Below 20°F Or 29°C)

    WARNING! Do not attempt to push or tow your vehicle to get it started. Vehicles equipped with an automatic trans- axle cannot be started this way. Unburned fuel could enter the catalytic converter and once the engine has started, ignite and damage the converter and vehicle. If the vehicle has a discharged battery, booster cables may be used to obtain a start from another vehicle.

  • Page 260: After Starting

    258 STARTING AND OPERATING CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again. After Starting The idle speed will automatically decrease as the engine warms up.
  • Page 261 Fully depress the clutch pedal before you shift gears. As you release the clutch pedal, lightly depress the accelera- tor pedal. Shift Pattern STARTING AND OPERATING 259 Use each gear in numerical order, do not skip a gear. Be sure the transaxle is in 1st gear, (not 3rd), when starting from a standing position.

  • Page 262: Recommended Shift Speeds

    260 STARTING AND OPERATING Recommended Shift Speeds To use your manual transaxle for optimal fuel economy, it should be upshifted as listed in the following table. Manual Transaxle Recommended Shift Speeds Units in mph (km/h) Accel- Engine eration 1 to 2 2 to 3 Size Rate...

  • Page 263: Brake/Transmission Interlock System

    CAUTION! Damage to the transaxle may occur if the following precautions are not observed: Shift into PARK only after the vehicle has come to a complete stop. Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.

  • Page 264: Automatic Transaxle Ignition Interlock System

    262 STARTING AND OPERATING NOTE: If a malfunction occurs, the transaxle will not shift out of PARK. Battery power is required to release the brake/transmission interlock system. There is a remov- able plug in the right side of the shift lever housing that allows you to insert your finger to override the system.
  • Page 265 PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range. Always apply the parking brake first, and then place the shift lever in the PARK position. WARNING! Unintended movement of a vehicle could injure those in and near the vehicle.

  • Page 266: Autostick - If Equipped

    264 STARTING AND OPERATING REVERSE Shift into this range only after the vehicle has come to a complete stop. NEUTRAL The engine may be started in this range. DRIVE This should be used for most driving and provides the best ratio for optimum drivability, fuel economy, and performance.

  • Page 267: General Information

    Autostick is deactivated: By holding the shift lever to (+) momentarily When the shift lever is shifted out of DRIVE When in 6th position, touching the shift lever to the right When heavy Anti-Lock Brake System (ABS) applica- tion is detected General Information If a ratio other than 1st is selected and the vehicle is brought to a stop, the transaxle control logic will...

  • Page 268: Four-Wheel Drive Operation - If Equipped

    266 STARTING AND OPERATING FOUR-WHEEL DRIVE OPERATION — IF EQUIPPED This feature provides full time, on-demand, four–wheel drive (4WD). Four-Wheel Drive Switch Where one or more wheels have wheel spin or if addi- tional traction is needed in sand, deep snow, or loose traction surfaces, activate the 4WD LOCK switch by pulling up once and releasing.

  • Page 269: Traction

    WARNING! Rapid acceleration on slippery surfaces is dangerous. Unequal traction can cause sudden pulling of the front wheels. You could lose control of the vehicle and possibly have an accident. Accelerate slowly and carefully whenever there is likely to be poor traction (ice, snow, wet, mud, loose sand, etc.).

  • Page 270: Flowing/Rising Water

    268 STARTING AND OPERATING Flowing/Rising Water WARNING! Do not drive on or cross a road or a path where water is flowing and/or rising (as in storm run-off). Flow- ing water can wear away the road or path’s surface and cause your vehicle to sink into deeper water. Furthermore, flowing and/or rising water can carry your vehicle away swiftly.
  • Page 271 CAUTION! (Continued) Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission/transaxle, axle, etc.) for signs of con- tamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.

  • Page 272: On-Road Driving Tips

    270 STARTING AND OPERATING ON-ROAD DRIVING TIPS Utility vehicles have higher ground clearance and a narrower track to make them capable of performing in a wide variety of off-road applications. Specific design characteristics give them a higher center of gravity than ordinary cars.

  • Page 273: When To Use Low (L Off-Road) With The 4Wd Lock Lever Engaged

    CAUTION! Never park your vehicle over dry grass or other combustible materials. The heat from your vehicle exhaust system could cause a fire. WARNING! Always wear your seat belt and firmly tie down cargo. Unsecured cargo can become projectiles in an off-road situation.
  • Page 274 272 STARTING AND OPERATING and avoid abrupt vehicle maneuvers. You want to keep a slow constant steady pace. The key is to maintain the vehicle’s momentum. Snow In heavy snow or for additional control and traction at slower speeds, activate the 4WD LOCK and shift the transaxle to low (L Off-Road) if necessary.

  • Page 275: Crossing Obstacles (Rocks And Other High Points)

    Sand Soft sand is very difficult to travel through with full tire pressure. When crossing soft sandy spots in a trail maintain your vehicle’s momentum and do not stop. The key to driving in soft sand is using the appropriate tire pressure, accelerating slowly, avoiding abrupt maneu- vers and maintaining the vehicle’s momentum.
  • Page 276 274 STARTING AND OPERATING forward until it makes contact with the object. Apply the throttle lightly while holding a light brake pressure and ease the vehicle up and over the object. WARNING! Crossing obstacles can cause abrupt steering system loading which could cause you to loose control of your vehicle.
  • Page 277 vehicle’s mobility. Approach these obstacles at a 45- degree angle and let each tire go through the obstacle independently. You need to use caution when crossing large obstacles with steep sides. Do not attempt to cross any large obstacle with steep sides at an angle great enough to put the vehicle at risk of a roll over.

  • Page 278: Hill Climbing

    276 STARTING AND OPERATING and place a few rocks under the tires so the weight is off of the high point when you let the vehicle down. You can also try rocking the vehicle or winching the vehicle off the object. CAUTION! Winching or rocking the vehicle off hard objects increases the risk of underbody damage.
  • Page 279 slightly to bring all four tires back on the ground. As you approach the crest of the hill ease off the throttle and slowly proceed over the top. If the wheels start to slip as you approach the crest of a hill, ease off the accelerator and maintain headway by turning the steering wheel no more than a 1/4 turn quickly back and forth.

  • Page 280: Driving Through Water

    278 STARTING AND OPERATING Driving Across An Incline If at all possible avoid driving across an incline. If it is necessary, know your vehicle’s abilities. Driving across an incline places more weight on the down-hill wheels, which increases the possibilities of a down-hill slide or rollover.
  • Page 281 designated and approved. You should tread lightly and avoid damage to the environment. You should know your vehicles abilities and be able to recover it if some- thing goes wrong. You should never stop or shut a vehicle off when crossing deep water unless you ingested water into the engine air intake.
  • Page 282 280 STARTING AND OPERATING soft bottoms the vehicle will sink in, effectively increas- ing the water level on the vehicle. Be sure to consider this when determining the depth and the ability to safely cross. Crossing Puddles, Pools, Flooded Areas Or Other Standing Water Puddles, pools, flooded or other standing water areas normally contain murky or muddy waters.

  • Page 283: Airing Down For Off-Road Driving

    the slowest current can push the heaviest vehicle down- stream out of control if the water is deep enough to push on the large surface area of the vehicle’s body. Before you proceed determine the speed of the current, the water’s depth, approach angle, bottom condition and if there are any obstacles, then cross at an angle heading slightly upstream using the low and slow technique.

  • Page 284: Vehicle Recovery

    282 STARTING AND OPERATING Vehicle Recovery If you drive off-road, you may encounter a situation where you will need to recover your vehicle. Vehicle recovery should always be given consideration before attempting a questionable obstacle. You should never go off-road driving without the ability to recover your vehicle from a situation.
  • Page 285 Rock Cycling Your Vehicle Rock cycling your vehicle is one of the easiest, fastest and most commonly used methods. This simply involves shifting your vehicle from DRIVE to REVERSE, while applying throttle after each shift. During this process, for additional traction, try turning your steering wheel quickly back and forth no more than a 1/4 turn.

  • Page 286: After Driving Off-Road

    284 STARTING AND OPERATING for a safe recovery. If necessary join two tow straps together using a 1 1/2 in (4 cm) hard wood dowel. This will keep the straps from becoming knotted and is safer than using a clevis pin if the strap breaks. Next have the tow vehicle backup, leaving 2 to 3 ft (61 to 91 cm) worth of slack in the strap.
  • Page 287 Check threaded fasteners for looseness, particularly on the chassis, drivetrain components, steering, and sus- pension. Retighten them, if required, and torque to the values specified in the Service Manual. Check for accumulations of plants or brush. These things could be a fire hazard, or they might hide damage to fuel lines, brake hoses, axle pinion seals, and propeller shafts.

  • Page 288: Power Steering

    286 STARTING AND OPERATING POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason the power assist is interrupted, it will still be possible to steer your vehicle.

  • Page 289: Parking Brake

    apparent, and/or the system is not functioning as antici- pated. Coordinate inspection efforts through an autho- rized dealer. No chemical flushes should be used in any power steering system; only the approved lubricant may be used. WARNING! Fluid level should be checked on a level surface and with the engine off to prevent injury from moving parts and to ensure accurate fluid level reading.
  • Page 290 288 STARTING AND OPERATING NOTE: The parking brake lever will not release unless the lever is pulled up slightly past its applied position. Parking Brake When parking on a hill, it is important to set the parking brake before placing the shift lever in PARK, otherwise, the load on the automatic transaxle locking mechanism may make it difficult to move the shift lever out of PARK.

  • Page 291: Brake System

    BRAKE SYSTEM Your vehicle is equipped with power assisted brakes as standard equipment. In the event power assist is lost for any reason (for example, repeated brake applications with the engine off), the brakes will still function. How- ever, the effort required to brake the vehicle will be much greater than that required with the power system oper- ating.

  • Page 292: Anti-Lock Brake System (Abs) - If Equipped

    290 STARTING AND OPERATING Anti-Lock Brake System (ABS) — If Equipped The ABS provides increased vehicle stability and brake performance under most braking conditions. The system automatically “pumps” the brakes during severe braking conditions to prevent wheel lock-up. WARNING! Pumping of the Anti-Lock Brakes will diminish their effectiveness and may lead to an accident.
  • Page 293 the conventional brake system will continue to operate normally if the BRAKE warning light is not on. If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefits of Anti-Lock brakes. If the ABS light does not come on when the ignition switch is turned to the ON position, have the bulb repaired as soon as possible.

  • Page 294: Electronic Brake Control System

    292 STARTING AND OPERATING WARNING! The Anti-Lock Brake System (ABS) contains sophis- ticated electronic equipment that may be susceptible to interference caused by improperly installed or high output radio transmitting equipment. This in- terference can cause possible loss of Anti-Lock brak- ing capability.

  • Page 295: Brake Assist System (Bas)

    Brake Assist System (BAS) The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The system detects an emergency braking situation by sens- ing the rate and amount of brake application and then applies optimum pressure to the brakes. This can help reduce braking distances.

  • Page 296: Traction Control System (Tcs)

    294 STARTING AND OPERATING Traction Control System (TCS) This system monitors the amount of wheel spin of each of the driven wheels. If wheel spin is detected, brake pressure is applied to the slipping wheel(s) and engine power is reduced to provide enhanced acceleration and stability.

  • Page 297: Hill Descent Control (Hdc) - If Equipped

    WARNING! Many factors, such as vehicle loading, road condi- tions and driving conditions, influence the chance that wheel lift or rollover may occur. ERM cannot prevent all wheel lift or rollovers, especially those that involve leaving the roadway or striking objects or other vehicles.

  • Page 298: Electronic Stability Program (Esp)

    296 STARTING AND OPERATING normal. When either the brake or the accelerator is released, HDC will control the vehicle back to the origi- nal set speed. HDC is only intended for low speed off-road driving. At vehicle speeds above 31 mph (50 km/h) HDC will no longer function.
  • Page 299 ESP Indicator Light The “ESP Indicator Light” located in the instrument cluster, starts to flash as soon as the tires lose traction and the ESP system becomes active. If the “ESP Indicator Light” begins to flash during acceleration, ease up on the accelerator and apply as little throttle as possible.
  • Page 300 298 STARTING AND OPERATING Full On (4WD Models) or On (2WD Models) This is the normal operating mode for ESP. Whenever the vehicle is started the ESP system will be in this “On” mode. This mode should be used for most driving situations.
  • Page 301 In this mode, ESP is turned off until the vehicle reaches a speed of 35 mph (56 km/h). At 35 mph (56 km/h) the system returns to “Partial Off” mode, as described above. When the vehicle speed drops below 30 mph (48 km/h) the ESP system shuts off.

  • Page 302: Tire Safety Information

    300 STARTING AND OPERATING and the vehicle has been driven several miles/kilometers at speeds greater than 30 mph (48 km/h), see your authorized dealer as soon as possible to have the problem diagnosed and corrected. NOTE: The “ESP Indicator Light” and the “ESP/BAS Warning Light”...
  • Page 303 NOTE: P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. European-Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width.
  • Page 304 302 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
  • Page 305 Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...

  • Page 306: Tire Identification Number (Tin)

    304 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.

  • Page 307: Tire Loading And Tire Pressure

    Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire and Loading Information Placard STARTING AND OPERATING 305 This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry...
  • Page 308 306 STARTING AND OPERATING NOTE: Under a maximum loaded vehicle condition, gross axle weight ratings (GAWRs) for the front and rear axles must not be exceeded. For further information on GAWRs, vehicle loading, and trailer towing, refer to “Vehicle Loading” in this section. To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of occupants and cargo should never exceed XXX lbs or...
  • Page 309 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. NOTE: The following table shows examples on how to calcu- late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations STARTING AND OPERATING 307...
  • Page 310 308 STARTING AND OPERATING...

  • Page 311: Tires - General Information

    WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.

  • Page 312: Tire Inflation Pressures

    310 STARTING AND OPERATING WARNING! (Continued) Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear patterns to develop across the tire tread.
  • Page 313 CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...

  • Page 314: Tire Pressures For High Speed Operation

    312 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.

  • Page 315: Limited-Use Spare - If Equipped

    WARNING! Temporary use spare tires are for emergency use only. With these tires, do not drive more than 50 mph (80 km/h). Temporary-use spare tires have limited tread life. When the tread is worn to the tread wear indica- tors, the temporary use spare tire needs to be replaced.

  • Page 316: Tire Spinning

    314 STARTING AND OPERATING WARNING! The limited-use spare tires are for emergency use only. Installation of this limited-use spare tire affects vehicle handling. With this tire, do not drive more than 50 mph (80 km/h). Keep it inflated to the cold tire inflation pressure listed on either your tire plac- ard or limited-use spare tire and wheel assembly.

  • Page 317: Tread Wear Indicators

    Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. 1 — Worn Tire 2 — New Tire STARTING AND OPERATING 315 These indicators are molded into the bottom of the tread grooves.

  • Page 318: Replacement Tires

    316 STARTING AND OPERATING WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident resulting in serious injury or death.
  • Page 319 WARNING! Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.

  • Page 320: Tire Chains

    318 STARTING AND OPERATING TIRE CHAINS Due to limited clearance, tire chains are not recom- mended. CAUTION! Damage to the vehicle may result if tire chains are used. SNOW TIRES Some areas of the country require the use of snow tires during Winter.

  • Page 321: Tire Pressure Monitoring System (Tpms)

    Follow the recommended tire rotation frequency for your type of driving found in the “Maintenance Schedules” section of this manual. More frequent rotation is permis- sible if desired. The reasons for any rapid or unusual wear should be corrected prior to rotation being per- formed.
  • Page 322 320 STARTING AND OPERATING tires. The tire pressure will also increase as the vehicle is driven - this is normal and there should be no adjustment for this increased pressure. The TPMS will warn the driver of a low tire pressure if the tire pressure falls below the low-pressure warn- ing limit for any reason, including low temperature effects, or natural pressure loss through the tire.
  • Page 323 CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warnings have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when us- ing replacement equipment that is not of the same size, type, and/or style.

  • Page 324: Base System

    322 STARTING AND OPERATING Seasonal temperature changes will affect tire pressure, and the TPMS will monitor the actual tire pressure in the tire. Base System This is the TPMS warning indicator located in the instrument cluster. The TPMS uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure lev- els.
  • Page 325 Check TPMS Warnings The Tire Pressure Monitoring Telltale Light will flash on and off for 75 seconds and remain on solid when a system fault is detected. The system fault will also sound a chime. If the ignition key is cycled, this sequence will repeat providing the system fault still exists.

  • Page 326: Premium System - If Equipped

    324 STARTING AND OPERATING 4. For each subsequent ignition key cycle, a chime will sound and the Tire Pressure Monitoring Telltale Light will flash on and off for 75 seconds and then remain on solid. 5. Once you repair or replace the original road tire and reinstall it on the vehicle in place of the compact spare tire, the TPMS will update automatically and the Tire Pressure Monitoring Telltale Light will turn OFF, as long...
  • Page 327 Various Tire Pressure Monitoring System Messages, which display in the Electronic Vehicle Information Center (EVIC) Yellow Tire Pressure Monitoring Telltale Light Tire Pressure Monitoring Low Pressure Warnings The Tire Pressure Monitoring Telltale Light will illumi- nate in the instrument cluster and an audible chime will be activated when one or more of the four active road tire pressures are low.
  • Page 328 326 STARTING AND OPERATING graphic display of the pressure value(s) will stop flash- ing, and the Tire Pressure Monitoring Light will extin- guish once the updated tire pressure(s) have been re- ceived. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) to receive this information.
  • Page 329 will be displayed instead of dashes. A system fault can occur with any of the following scenarios: 1. Jamming due to electronic devices or driving next to facilities emitting the same radio frequencies as the TPM sensors. 2. Installing some form of aftermarket window tinting that affects radio wave signals.

  • Page 330: General Information

    328 STARTING AND OPERATING limit in any of the four active road tires. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada.

  • Page 331: Reformulated Gasoline

    Reformulated Gasoline Many areas of the country require the use of cleaner burning gasoline referred to as “reformulated gasoline”. “Reformulated gasolines” contain oxygenates and are specifically blended to reduce vehicle emissions and improve air quality. The manufacturer supports the use of “reformulated gasolines”.

  • Page 332: Mmt In Gasoline

    330 STARTING AND OPERATING If a Non-FFV vehicle is inadvertently fueled with E-85 fuel, the engine will have some or all of these symptoms: operate in a lean mode OBD II “Malfunction Indicator Light” on poor engine performance poor cold start and cold drivability increased risk for fuel system component corrosion To fix a Non-FFV vehicle inadvertently fueled once with E-85 perform the following:...

  • Page 333: Materials Added To Fuel

    MMT is prohibited in Federal and California reformu- lated gasolines. Materials Added To Fuel All gasoline sold in the United States is required to contain effective detergent additives. Use of additional detergents or other additives is not needed under normal conditions and would result in additional cost.

  • Page 334: Carbon Monoxide Warnings

    332 STARTING AND OPERATING Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period of time.
  • Page 335 After removing the gas cap, place the gas cap tether cable over a hook on the inside of the fuel door. This keeps the gas cap suspended away from and protects the vehicle’s surface. Fuel Filler Door STARTING AND OPERATING 333 CAUTION! A poorly fitting gas cap may cause the Malfunc- tion Indicator Light (MIL) to turn on.

  • Page 336: Loose Fuel Filler Cap Message

    334 STARTING AND OPERATING NOTE: Tighten the gas cap about 1/4 turn until you hear one click. This is an indication that cap is properly tightened. If the gas cap is not tighten properly, the MIL will come on. Be sure the gas cap is tightened every time the vehicle is refueled.

  • Page 337: Vehicle Loading

    VEHICLE LOADING As required by National Highway Traffic Safety Admin- istration regulations, your vehicle has a certification label affixed to the driver’s side door or B-Pillar. Vehicle Certification Label Your vehicle has a Vehicle Certification Label attached to the driver’s door B-Pillar. The label contains the following information: Name of manufacturer Month and year of manufacture...
  • Page 338 336 STARTING AND OPERATING Curb Weight The curb weight of a vehicle is defined as the total weight of the vehicle with all fluids, including vehicle fuel, at full capacity conditions, and with no occupants or cargo loaded into the vehicle. The front and rear curb weight values are determined by weighing your vehicle on a commercial scale before any occupants or cargo are added.

  • Page 339: Trailer Towing

    TRAILER TOWING In this section you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer, carefully review this information to tow your load as efficiently and safely as possible.
  • Page 340 338 STARTING AND OPERATING WARNING! It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. Tongue Weight (TW) The tongue weight is the downward force exerted on the hitch ball by the trailer.

  • Page 341: Trailer Hitch Classification

    safety. The addition of a friction/hydraulic sway control also dampens sway caused by traffic and crosswinds and contributes positively to tow vehicle and trailer stability. Trailer sway control and a weight distributing (load equalizing) hitch are recommended for heavier Tongue Weights (TW) and may be required depending on Vehicle and Trailer configuration/loading to comply with Gross Axle Weight Rating (GAWR) requirements.

  • Page 342: Trailer Towing Weights (Maximum Trailer Weight Ratings)

    340 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Transmission Frontal Area 2.0L Auto/Man 22 sq ft (2.04 sq m) 2.4L Auto/Man 22 sq ft (2.04 sq m) 2.4L Auto/Man with 32 sq ft (3.0 sq m) Trailer Tow Prep Pack-...

  • Page 343: Trailer And Tongue Weight

    Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle. Loads balanced over the wheels or heavier in the rear can cause the trailer to sway severely from side-to- side which will cause loss of control of the vehicle and trailer.

  • Page 344: Towing Requirements

    342 STARTING AND OPERATING NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or authorized dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the Tire and Loading Information placard in the Tire Safety Information section of this manual for the maximum combined weight of occupants and cargo for your vehicle.
  • Page 345 Safety chains must always be used between your vehicle and trailer. Always connect the chains to the frame or hook retainers of the vehicle hitch. Cross the chains under the trailer tongue and allow enough slack for turning corners. Vehicles with trailers should not be parked on a grade. When parking, apply the parking brake on the tow vehicle.
  • Page 346 344 STARTING AND OPERATING − When replacing tires, refer to “Tires–General Informa- tion” in this section for proper tire replacement proce- dures. Replacing tires with a higher load carrying capacity will not increase the vehicle’s GVWR and GAWR limits. Towing Requirements — Trailer Brakes −...
  • Page 347 WARNING! Do not connect trailer brakes to your vehicle’s hy- draulic brake lines. It can overload your brake sys- tem and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping dis- tance.
  • Page 348 346 STARTING AND OPERATING The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustrations. 4-Pin Connector 1 — Female Pins 4 — Park 2 — Male Pin 5 —...

  • Page 349: Towing Tips

    Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic. Towing Tips — Automatic Transmission The automatic transmission fluid and filter should be changed if you REGULARLY tow a trailer for more than 45 minutes of continuous operation.

  • Page 350: Recreational Towing (Behind Motorhome, Etc.)

    348 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Ground) Recreational Manual Towing Transaxle Condition Vehicles Four Wheel Flat Tow (All Wheels on Ground) Two Wheel Never Dolly Tow (Front or Rear Wheels...

  • Page 351: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....350 If Your Engine Overheats ....350 Automatic Transaxle Overheating .

  • Page 352: Hazard Warning Flasher

    350 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is located on the instrument panel, below the radio. Press the switch to turn on the Hazard Warning flashers. When the Hazard Warning flasher switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
  • Page 353 NOTE: There are steps that you can take to slow down an impending overheat condition. If your air conditioner is on, turn it off. The air conditioning system adds heat to the engine cooling system and turning off the A/C removes this heat.

  • Page 354: Automatic Transaxle Overheating

    352 WHAT TO DO IN EMERGENCIES WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, refer to “Maintenance”, Section 7 of this manual.

  • Page 355: Jack Location

    Jack Location The jack and jack-handle are stowed under the load floor in the cargo area. Spare Tire and Jack Stowage Spare Tire Stowage The spare tire is stowed under the rear load floor in the cargo area. WHAT TO DO IN EMERGENCIES 353 Spare Tire Removal Lift up the load floor cover and remove the hold down.

  • Page 356: Jacking Instructions

    354 WHAT TO DO IN EMERGENCIES 5. Turn on the Hazard Warning flasher. 6. Block both the front and rear of the wheel diagonally opposite the jacking position. For example, if changing the right front tire, block the left rear wheel.
  • Page 357 WARNING! (Continued) If working on or near a roadway, be extremely careful of motor traffic. To assure that spare tires, flat or inflated are securely stowed, spares must be stowed with the valve stem facing the ground. Turn on the Hazard Warning flasher. Jack Warning Label 1.
  • Page 358 356 WHAT TO DO IN EMERGENCIES CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in Step 3. 3. There are two front jacking locations and two rear jacking locations on each side of the body. The front locations are outlined by two triangular cutouts, the rear ones by two rectangular cutouts.
  • Page 359 6. Remove the wheel nuts and pull the wheel (and bolt-on center cap if equipped) off the hub. Install the spare wheel and wheel nuts with the cone shaped end of the nuts toward the wheel. Lightly tighten the nuts. To avoid the risk of forcing the vehicle off the jack, do not tighten the nuts fully until the vehicle has been lowered.

  • Page 360: Jump-Starting Procedures

    358 WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURES WARNING! Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is on. You can be hurt by the fan. Do not attempt to push or tow your vehicle to get it started.
  • Page 361 2. Turn off the heater, radio and all unnecessary electrical loads. 3. Using the two finger screws on the cover, remove the air intake duct covering the battery. 4. Connect one end of a jumper cable to the positive terminal of the booster battery. Connect the other end of the jumper cable to the positive terminal of the dis- charged battery.

  • Page 362: Freeing A Stuck Vehicle

    360 WHAT TO DO IN EMERGENCIES 8. When removing the jumper cables, reverse the se- quence exactly. Be careful of the moving belts and fan. FREEING A STUCK VEHICLE NOTE: If your vehicle is equipped with Traction Con- trol or ESP, turn the system OFF before attempting to “rock”...

  • Page 363: Towing A Disabled Vehicle

    TOWING A DISABLED VEHICLE With Ignition Key Automatic Transaxle Front Wheel Drive (FWD) vehicles can be towed with the front wheels elevated or on a flatbed truck (all four wheels off the ground). All Wheel Drive (AWD) vehicles must be towed on a flatbed truck (all four wheels off the ground).

  • Page 364: Without The Ignition Key

    362 WHAT TO DO IN EMERGENCIES CAUTION! If the vehicle being towed requires steering, the ignition switch must be in the ACC position, not in the LOCK position. Do not attempt to use sling type equipment when towing. When securing the vehicle to a flat bed truck, do not attach to front or rear suspension components.

  • Page 365: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 2.0L/2.4L ..365 Onboard Diagnostic System — OBD II ..366 Loose Fuel Filler Cap Message ... 366 Emissions Inspection And Maintenance Programs .
  • Page 366 364 MAINTAINING YOUR VEHICLE Brake System ..... . . 384 Automatic Transaxle (CVT) ....386 Manual Transaxle .

  • Page 367: Engine Compartment - 2.0L/2.4L

    ENGINE COMPARTMENT — 2.0L/2.4L 1 — Washer Fluid Reservoir 2 — Power Steering Fluid Reservoir 3 — Engine Oil Fill 4 — Brake Fluid Reservoir 5 — Integrated Power Module MAINTAINING YOUR VEHICLE 365 6 — Battery 7 — Air Cleaner Filter 8 —...

  • Page 368: Onboard Diagnostic System - Obd Ii

    366 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated Onboard Diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transaxle control systems. When these systems are oper- ating properly, your vehicle will provide excellent per- formance and fuel economy, as well as engine emissions well within current government regulations.

  • Page 369: Emissions Inspection And Maintenance Programs

    persists, the message will appear the next time the vehicle is started. This might indicate a damaged cap. If the problem is detected twice in a row, the system will turn on the MIL. Resolving the problem will turn the MIL light off.

  • Page 370: Replacement Parts

    368 MAINTAINING YOUR VEHICLE 5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.

  • Page 371: Dealer Service

    DEALER SERVICE Your authorized dealer has the qualified service person- nel, special tools, and equipment to perform all service operations in an expert manner. Service Manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
  • Page 372 370 MAINTAINING YOUR VEHICLE The best time to check the engine oil level is about five minutes after a fully warmed engine is shut off. Do not check oil level before starting the engine after it has sat overnight. Checking engine oil level when the engine is cold will give you an incorrect reading.
  • Page 373 American Petroleum Institute (API) Engine Oil Identification Symbol This symbol means that the oil has been certified by the American Petroleum Institute (API). The manufacturer only recommends API Certified engine oils. Engine Oil Viscosity (SAE Grade) SAE 5W-20 engine oil is recommended for all operating temperatures.

  • Page 374: Engine Oil Filter

    372 MAINTAINING YOUR VEHICLE environment. Contact your authorized dealer, service station, or governmental agency for advice on how and where used oil and oil filters can be safely discarded in your area. Engine Oil Filter The engine oil filter should be replaced at every engine oil change.

  • Page 375: Maintenance-Free Battery

    Maintenance-Free Battery The top of the maintenance-free battery is permanently sealed. You will never have to add water, nor is periodic maintenance required. WARNING! Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin, or clothing.

  • Page 376: Air Conditioner Maintenance

    374 MAINTAINING YOUR VEHICLE CAUTION! (Continued) If a “fast charger” is used while the battery is in the vehicle, disconnect both vehicle battery cables before connecting the charger to the battery. Do not use a “fast charger” to provide starting voltage. Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer...

  • Page 377: Body Lubrication

    Refrigerant Recovery And Recycling R-134a air conditioning refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.

  • Page 378: Adding Washer Fluid

    376 MAINTAINING YOUR VEHICLE Operation of the wipers on dry glass for long periods may cause deterioration of the wiper blades. Always use washer fluid when using the wipers to remove salt or dirt from a dry windshield. Avoid using the wiper blades to remove frost or ice from the windshield.
  • Page 379 exhaust system each time the vehicle is raised for an oil change or lubrication. Replace as required. WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you.

  • Page 380: Cooling System

    378 MAINTAINING YOUR VEHICLE WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.
  • Page 381 WARNING! (Continued) You or others can be badly burned by hot coolant or steam from your radiator. If you see or hear steam coming from under the hood, do not open the hood until the radiator has had time to cool. Never try to open a cooling system pressure cap when the radiator is hot.
  • Page 382 380 MAINTAINING YOUR VEHICLE CAUTION! Mixing of engine coolant (antifreeze) other than specified Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion pro- tection. If a non-HOAT engine coolant (antifreeze) is introduced into the cooling system in an emer- gency, it should be replaced with the specified engine coolant (antifreeze) as soon as possible.
  • Page 383 When adding engine coolant (antifreeze), a minimum solution of 50% recommended MOPAR Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology), or equivalent, in water should be used. Use higher concentrations (not to exceed 70%) if temperatures below 34°F ( 37°C) are antici- pated.
  • Page 384 382 MAINTAINING YOUR VEHICLE WARNING! (Continued) Do not use a pressure cap other than the one specified for your vehicle. Personal injury or en- gine damage may result. Disposal Of Used Engine Coolant Used ethylene glycol-based engine coolant (antifreeze) is a regulated substance requiring proper disposal.
  • Page 385 Points to Remember NOTE: When the vehicle is stopped after a few miles/ kilometers of operation, you may observe vapor coming from the front of the engine compartment. This is nor- mally a result of moisture from rain, snow, or high humidity accumulating on the radiator and being vapor- ized when the thermostat opens, allowing hot engine coolant (antifreeze) to enter the radiator.

  • Page 386: Brake System

    384 MAINTAINING YOUR VEHICLE Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Refer to the “Maintenance Schedule” in Section 8 for proper maintenance intervals. WARNING! Riding the brakes can lead to brake failure and possibly an accident.
  • Page 387 Use only manufacturer’s recommended brake fluid. Re- fer to “Fluids, Lubricants, and Genuine Parts” in this section for the correct fluid type. WARNING! Use of a brake fluid that may have a lower initial boiling point or is unidentified as to specification, may result in sudden brake failure during hard prolonged braking.

  • Page 388: Automatic Transaxle (Cvt)

    386 MAINTAINING YOUR VEHICLE Automatic Transaxle (CVT) Selection Of Lubricant It is important that the proper lubricant is used in the transaxle to assure optimum transaxle performance. Use only the manufacturer’s recommended transmission fluid which has been formulated with special metal to metal friction coefficient additives to provide the proper steel belt traction on the drive and driven pulleys.

  • Page 389: Rear Drive Assembly (Rda) - Awd/4Wd Models Only

    Fluid Level Check Check the fluid level by removing the fill plug. The fluid level should be between the bottom of the fill hole and a point not more that 3/16 in (4.7 mm) below the bottom of the hole. Add fluid, if necessary, to maintain the proper level.

  • Page 390: Power Transfer Unit (Ptu) - Awd/4Wd Models Only

    388 MAINTAINING YOUR VEHICLE Power Transfer Unit (PTU) – AWD/4WD Models Only Lubricant Selection Use only the manufacturer’s recommended fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in this section for the correct fluid type. Fluid Level Check Visually inspected the unit at each oil change for leakage. If leakage is detected, Check the fluid level by removing the fill plug.
  • Page 391 What Causes Corrosion? Corrosion is the result of deterioration or removal of paint and protective coatings from your vehicle. The most common causes of corrosion are: Road salt, dirt and moisture accumulation. Stone and gravel impact. Insects, tree sap and tar. Salt in the air near sea coast localities.
  • Page 392 390 MAINTAINING YOUR VEHICLE Special Care If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month. It is important that the drain holes in the lower edges of the doors, rocker panels and trunk be kept clear and open.
  • Page 393 YES Essentials Fabric Cleaning Procedure – If Equipped YES Essentials seats may be cleaned in the following manner: Remove as much of the stain as possible by blotting with a clean, dry towel. Blot any remaining stain with a clean, damp towel. For tough stains, apply MOPAR Total Clean or a mild soap solution to a clean, damp cloth and remove stain.
  • Page 394 392 MAINTAINING YOUR VEHICLE WARNING! Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in closed areas, they may cause respiratory harm. Cleaning Headlights Your vehicle has plastic headlights that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and, therefore, different lens cleaning procedures must be followed.
  • Page 395 Instrument Panel Bezels CAUTION! When installing hanging air fresheners in your ve- hicle, read the installation instructions carefully. Some air fresheners will damage the finish of painted or decorated parts if allowed to directly contact any surface. Cleaning Plastic Instrument Cluster Lenses The lenses in front of the instruments in this vehicle are molded in clear plastic.

  • Page 396: Fuses

    394 MAINTAINING YOUR VEHICLE FUSES Integrated Power Module (IPM) The Integrated Power Module (IPM) is located in the engine compartment near the air cleaner assembly. This center contains cartridge fuses and mini-fuses. A label that identifies each component may be printed on the inside of the cover.
  • Page 397 Cavity Cartridge Mini- Fuse Fuse 20 Amp Pwr Run/Acc Outlet Yellow RR/Dome Lamp 10 Amp IOD CCN 40 Amp RAD Fan Relay Bat- Green tery Feed 15 Amp IGN Run/Acc Dome Lt Blue Lamp/Sunroof/Rear Wiper Motor/ACC Inverter 10 Amp IOD Feed Mod-Wcm 40 Amp ASD Relay Contact Green...
  • Page 398 396 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Fuse Fuse 10 Amp IGN RUN ORC/OCM Feed Hot Car (No Fuse Re- quired) 20 Amp Heated Seats Yellow 10 Amp Headlamp Washer Relay Control (If Equipped) 30 Amp ENG ASD Control Pink Feed 1 10 Amp ABS MOD/J1962...

  • Page 399: Vehicle Storage

    CAUTION! (Continued) When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system over- load. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected.

  • Page 400: Bulb Replacement

    398 MAINTAINING YOUR VEHICLE BULB REPLACEMENT Headlamps 1. Raise the hood and locate the connector behind the headlight. 2. Reach into engine compartment and pull red lock out at connector.
  • Page 401 MAINTAINING YOUR VEHICLE 399 3. Remove the green connector from the back of the bulb 4. Twist the bulb to the left. by pulling straight back.

  • Page 402: Fog Lights

    400 MAINTAINING YOUR VEHICLE 5. Pull bulb outward from assembly. NOTE: These are halogen bulbs. Take care not to touch the bulb with your fingers. Body oils from your fingers could cause excessive heat buildup which reduces bulb life. Fog Lights See your authorized dealer for replacement.

  • Page 403: License Lights

    MAINTAINING YOUR VEHICLE 401 License Lights 2. Rotate the socket 1/4 turn counterclockwise. 1. Use a screw driver to gently pry against the side of the snap tab to remove the light from the liftgate.

  • Page 404: Center High-Mounted Stoplight

    402 MAINTAINING YOUR VEHICLE 3. Pull the bulb from the socket. Center High-Mounted Stoplight Light is an LED assembly. See your authorized dealer for replacement. Auxiliary Off-Road Light 1. Remove the three screws attaching the lens to the housing.
  • Page 405 2. Unlatch the wire clasp securing the bulb into the housing and rotate it into the position shown. MAINTAINING YOUR VEHICLE 403 3. Disconnect the bulb from the light harness to replace the bulb.

  • Page 406: Fluids And Capacities

    404 MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Fuel (Approximate) Engine Oil with Filter 2.0L and 2.4L Engine (SAE 5W-20, API Certified) Cooling System * 2.0L and 2.4L Engine (MOPAR Engine Coolant/Antifreeze 5 Year/100,000 Mile Formula) * Includes heater and coolant recovery bottle filled to MAX level. U.S.

  • Page 407: Fluids, Lubricants, And Genuine Parts

    FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.

  • Page 408: Chassis

    406 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transaxle (CVT) Manual Transaxle Rear Drive Assembly (RDA) Power Transfer Unit (PTU) Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR CVTF + 4 Automatic Transmission Fluid MOPAR ATF+4 Automatic Transmission Fluid MOPAR Gear &...

  • Page 409: Maintenance Schedules

    MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..408 Maintenance Schedule ....408 Required Maintenance Intervals ..410...

  • Page 410: Emissions Control System Maintenance

    408 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
  • Page 411 NOTE: The oil change indicator message will not monitor the time since the last oil change. Change your vehicle’s oil if it has been six months since your last oil change and even if the oil change indicator message is NOT illuminated.
  • Page 412 410 MAINTENANCE SCHEDULES Once a Month Check the tire pressure and look for unusual wear or damage. Inspect the battery and clean and tighten the terminals as required. Check the fluid levels of coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
  • Page 413 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule Change the engine oil and engine oil filter.
  • Page 414 412 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 24,000 Miles (40,000 km) or 24 Months Maintenance Service Schedule Change the engine oil and engine oil filter.

  • Page 415: Service Schedule

    30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Replace the spark plugs (except 2.4L PZEV). Adjust the parking brake on vehicles equipped with four-wheel disc brakes. Odometer Reading Date Repair Order #...
  • Page 416 414 MAINTENANCE SCHEDULES 48,000 Miles (80,000 km) or 48 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
  • Page 417 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Inspect the brake linings; replace if necessary. Adjust the parking brake on vehicles equipped with four-wheel disc brakes. Replace the air conditioning filter.
  • Page 418 416 MAINTENANCE SCHEDULES 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
  • Page 419 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
  • Page 420 418 MAINTENANCE SCHEDULES 96,000 Miles (160,000 km) or 96 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
  • Page 421 108,000 Miles (180,000 km) or 108 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
  • Page 422 420 MAINTENANCE SCHEDULES 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Inspect the brake linings; replace if necessary. Adjust the parking brake on vehicles equipped with four-wheel disc brakes. Replace the air conditioning filter.
  • Page 423 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
  • Page 424 422 MAINTENANCE SCHEDULES 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
  • Page 425 † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. MAINTENANCE SCHEDULES 423 WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment.
  • Page 427 IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......427 Prepare For The Appointment .
  • Page 428 426 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....431 Department Of Transportation Uniform Tire Quality Grades ......432 Treadwear .

  • Page 429: Suggestions For Obtaining Service For Your

    SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.

  • Page 430: If You Need Consumer Assistance

    428 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.

  • Page 431: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)

    Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.

  • Page 432: Warranty Information (U.s. Vehicles Only)

    430 IF YOU NEED CONSUMER ASSISTANCE WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain, or emit, chemicals known to the State of California to cause cancer and birth defects, or other reproductive harm. In addi- tion, certain fluids contained in vehicles and certain products of component wear contain, or emit, chemi- cals known to the State of California to cause cancer and birth defects, or other reproductive harm.

  • Page 433: In Canada

    To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Adminis- trator, NHTSA, 400 Seventh Street, SW., Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from http://www.safercar.gov.

  • Page 434: Department Of Transportation Uniform Tire Quality Grades

    432 IF YOU NEED CONSUMER ASSISTANCE Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.

  • Page 435: Treadwear

    Treadwear The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded 100.

  • Page 436: Department Of Transportation Uniform Tire Temperature Grades

    434 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 437 INDEX...
  • Page 438 436 INDEX ABS (Anti-Lock Brake System) ....290 Adding Engine Coolant (Antifreeze) ..380 Adding Fuel ......332 Adding Washer Fluid .
  • Page 439 Autostick ......264 Battery ....... 373 Keyless Transmitter Replacement (RKE) .
  • Page 440 438 INDEX Chains, Tire ......318 Changing A Flat Tire ..... 352 Chart, Tire Sizing .
  • Page 441 Cupholders ......153 Customer Assistance ..... 427 Data Recorder, Event .
  • Page 442 440 INDEX Emergency, In Case of Jacking ......352 Jump Starting ......358 Towing .
  • Page 443 Fluid Level Checks Automatic Transaxle ....386 Power Steering ......286 Fluids .
  • Page 444 442 INDEX Gearshift ......262 General Information ....19,109,328 General Maintenance .
  • Page 445 Integrated Power Module (Fuses) ... . 394 Interior Appearance Care ....391 Intermittent Wipers (Delay Wipers) ... 131 Introduction .
  • Page 446 444 INDEX Electronic Stability Program (ESP) Indicator ......297,299 Engine Temperature Warning ....170 Fog .
  • Page 447 Maintenance Schedule ....408 Malfunction Indicator Light (Check Engine) ..... . . 176,367 Manual, Service .
  • Page 448 446 INDEX Materials Added to ..... 371 Recommendation ....370,404 Synthetic .
  • Page 449 Radial Ply Tires ......312 Radio Operation ......242 Radio, Satellite .
  • Page 450 448 INDEX Satellite Radio Antenna ....236 Schedule, Maintenance ....408 Seat Belt Maintenance .
  • Page 451 Slippery Surfaces, Driving On ....266 Snow Chains (Tire Chains) ....318 Snow Tires .
  • Page 452 450 INDEX Tire Safety Information ....300 Tires ......70,309,432 Aging (Life of Tires) .
  • Page 453 Trailer and Tongue Weight ....341 Wiring ......345 Trailer Towing Guide .
  • Page 454 452 INDEX Voice Recognition System (VR) ....109 Warning Lights (Instrument Cluster Description) ... . . 167 Warning, Roll Over .

  • Page 455: Installation Of Radio Transmitting Equipment

    INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
  • Page 456 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
  • Page 457 Chrysler LLC 81-326-0912 First Edition Printed in U.S.A.

Table of Contents
