- Page 1 PL61W3 E-mail: ANUAL Please read these user manual carefully before use www.lightsky.com.cn Add:No.51 Yunfeng Rd,Xinhua Industrial Zone,Xinhua Street, FLY DRAGON LIGHTING EQUIPMENT CO., LTD Huadu District,Guangzhou,China.
-
Page 2: Table Of Contents
INDEX 1.Safety information....................2 2.Skill specifications and Performance trait .............3 3.Control panel.......................4 4.Attachment and Body size...................5 5.Distance,spot diameter and Illumination diagram............6 6.Mounting and Installation..................7 7.Power supply and Signal connection..............8 8.Menu setting.......................10 9.Channel function....................12 Circuit connecting diagram .................13 11.Troubeshooting....................14 12.Cleaning and Maintenances................15 Duty exonerative and Copyright protection ............15 Congratulations on choosing our company product! We thank you for your custom. -
Page 3: Safety Information
SAFETY INSTRUCTIONS Notice: To guarantee proper and consistent operation, it is important to follow the guidelines in this manual. Our company will not accept responsibility for damages resulting from the misuse of this fixture due to the disregard of the information printed in this manual. -
Page 4: Skill Specifications And Performance Trait
Skill specifications and Perfor mance trait ◎ Voltage：AC100~240V 50/60Hz. ◎ Maximum power consumption :190W ◎ LED chip：CREEN 3W White ◎ LED QTY：61PCS ◎ Chip drive current：950mA ◎ LED life：≥50000H ◎ Beam angle:Zoom function min.10°，max.50° ◎ Color：RGB Color system,soft and no flicker,Single ring can be controlled separateiy, fast marco color system ◎... -
Page 5: Control Panel
Control panel Display screen Keypad DMX IN DMX OUT POWER IN POWER OUT... -
Page 6: Attachment And Body Size
Attachment and Body size power cord ◆Each of the six stage lights delivers a power cord and a signal line. Body Size---Fig 2... -
Page 7: Distance,Spot Diameter And Illumination Diagram
Distance,spot diameter and illumination diagram Distance,spot diameter and illumination diagram 1320 1420 50° (Lux) W1+W2 2240 8500 3540 2020 1040 10° （Lux） 10200 3700 2160 1110 W1+W2 16500 6050 3360 1760 10° 50° (m) 0 Distance 10°Diameter(m) 0.55 0. 9 1. -
Page 8: Mounting And Installation
Mounting and installation Cautions: For added protection mount the fixtures in areas outside walking paths, seatingareas, and away from areas were unauthorized personnel might reach the fixture. Before mounting the fixture to any surface, make sure that the installation area can hold a minimum point load of 10 times the device's weight. -
Page 9: Power Supply And Signal Connection
Power supply and signal connection 1. Power supply Use the professional plug to connect the projector and main power supply. Please pay attention to the voltage, frequency the same as the mentioned on the projector. Suggest each light has separately switched of the power supply so that could turn on or turn off each projector desultorily. - Page 10 2.Signal connection Please use the round 3/5-pin XLR plugs &sockets offered by menu facture to connect the first projector's output to the second projector' input and connect the second projector's output to the third device's input. And in the same way for the rest, eventually connect the last device's output, all the devices are together as the following figure.
-
Page 11: Menu Setting
Menu setting 1.Button operation ● ESC： Exit Button ； ● UP：Page up or increase； ● DOWN：Page down or reduce； ● ENTER：OK button DOWN ENTER 2.Menu operation Level 1 menu Level 2 menu Level 3 menu Level 4 menu note A. * * * Address code Settings Dimmer speed off DIM.1... - Page 12 Note Level 2 menu Level 3 menu Level 4 menu Level 1 menu D.000 Fixed editing of scenes Fixed editing of scenes C.000 F.SCE S.000 Fixed editing of scenes Fixed editing of scenes Z.000 F.000 Fixed editing of scenes LED temperature TEM1 D.000 The DMX512 value of the console...
-
Page 13: Channel Function
CHANNEL FUNCTION FUNCTION CHANNEL DMX VALUE Dimmer 0- 255 0- 100 0- 255 0- 100 Shutter 0- 9 0- 3 No Function Slow closing,Fast opening,Slow→Fast 10- 49 4- 19 20- 34 Fast closing, Slow opening,Slow→Fast 50- 89 Slow closing,Slow opening,Slow→Fast 90- 119 35- 46 47- 70... -
Page 14: Circuit Connecting Diagram
Circuit connecting diagram Power in Switching power supply GF5241AS GF5241AS in put Display board Dreiver board LED board LED OUTPUT DC48V INPUT... -
Page 15: Troubeshooting
TROUBLE DISPOSE It is recommended some solution for some normal trouble shooting. Any inextricability problems should always be handling by the professional person. Disconnect the power supply before maintenance the light. ●LED off： 1.Please check if install the suitable voltage 2.Please check whether the led will reach the end of their life can explode;... -
Page 16: Cleaning And Maintenances
CLEANING AND MAINTENANCE ■ 1.In order to ensure the projector could work normally. It should be kept clean always .The lens should also be regularly cleaned to maintain an optimum light output. Do not use any type of solvent on lens. It will damage the projector.
