  • Page 1 MX808ST/MX825ST/MW809ST/ MW826ST Digital Projector User Manual V 1.00...

  • Page 2: Warranty And Copyright Information

    For other information, please visit www.BenQ.com. Copyright Copyright © 2017 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.

  • Page 3: Table Of Contents

    Table of Contents Warranty and Copyright information ................2 Important safety instructions ....................4 Introduction .......................... 7 Shipping contents ............................7 Projector exterior view ..........................8 Controls and functions..........................9 Positioning your projector ....................12 Choosing a location ..........................12 Obtaining a preferred projected image size..................

  • Page 4: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. 1.
  • Page 5 9. Never replace the lamp assembly or any 13. Always place the projector on a level, electronic components unless the projector is horizontal surface during operation. unplugged. - Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of more than 15 degrees front to back.
  • Page 6 50 cm clearance from walls and free flow of air around the projector. outlet and call BenQ to have the projector - Locations where temperatures may become serviced. excessively high, such as the inside of a car with all windows rolled up.

  • Page 7: Introduction

    Introduction Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories Remote control with Projector User manual CD batteries Quick start guide Warranty card* Power cord •...

  • Page 8: Projector Exterior View

    Projector exterior view 15 17 1. Focus ring 12. USB Type A port (Power for Touch kit) 2. Vent (air exhaust) 13. USB Mini-B port 3. Adjuster feet 14. RGB (PC) signal input jacks 4. Projection lens 15. RGB (PC) signal output jack 5.

  • Page 9: Controls And Functions

    Controls and functions Projector & Remote control • All the key presses described in this document are available on the remote control or projector. • The remote control is without laser pointer in Japan INFO 5. Arrow keys ( , POWER When the On-Screen Display (OSD) menu is Toggles the projector between standby mode...
  • Page 10 6. SOURCE 16. PAGE /PAGE Displays the source selection bar. Operate your display software program (on a connected PC) which responds to page 7. ECO BLANK up/down commands (like Microsoft Used to hide the screen picture. PowerPoint). Do not block the projection lens from 17.
  • Page 11 Controlling your smart device with the remote control When the projector projects the content from your MHL compatible smart device, you can use the remote control to control your smart device. To enter the MHL mode, press and hold AUTO for 3 seconds. The following buttons are available for controlling your smart device: Arrow keys ( , ), MENU, BACK, OK, MHL...

  • Page 12: Positioning Your Projector

    Purchase the BenQ Projector Ceiling Note that a special rear projection screen and the Mount Kit from your dealer to mount your BenQ Projector Ceiling Mount Kit are required projector on the ceiling. for this installation location. After turning on the projector, go to Advanced Menu - Settings > Projector Installation >...

  • Page 13: Obtaining A Preferred Projected Image Size

    All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.

  • Page 14: Mounting The Projector

    If you use a non-BenQ brand projector mounting kit, there is a safety risk that the projector may fall down due to an improper attachment through the use of the wrong gauge or length screws.

  • Page 15: Adjusting The Projected Image

    • Consider the surrounding temperature where the projector is ceiling/wall mounted. If a heater is used, the temperature around the ceiling may be higher than expected. • Read the user manual for the mounting kit about the range of torque. Tightening with torque exceeding the recommended range may cause damage to the projector and subsequently falling off.
  • Page 16 Fine-tuning the image clarity Sharpen the image by rotating the focus ring. Correcting keystone Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection. To correct this, you will need to manually correct it following these steps. 1.

  • Page 17: Connection

    Connection When connecting a signal source to the projector, be sure to: 1. Turn all equipment off before making any connections. 2. Use the correct signal cables for each source. 3. Ensure the cables are firmly inserted. A/V device Touch module VGA cable VGA to DVI-A cable...
  • Page 18 A/V device Touch module VGA cable VGA to DVI-A cable USB cable Component Video to VGA (D-Sub) adapter cable Audio cable USB cable (A to mini B type) connect Speakers to Touch Module Notebook or HDMI cable Monitor desktop computer •...
  • Page 19 You need only connect the projector to a video source device using just one of the connecting methods, however each provides a different level of video quality. Terminal Picture quality Best HDMI/MHL Component Video (through RGB Better input) Good S-Video Normal Video Connecting audio (MW809ST/MX825ST/MW826ST)

  • Page 20: Operation

    Operation Starting up the projector 1. Plug the power cord. Turn on the power outlet switch (where fitted). The power indicator on the projector lights orange after power has been applied. 2. Press on the projector or on the remote control to start the projector.

  • Page 21: Using The Menus

    Using the menus The projector is equipped with 2 types of On-Screen Display (OSD) menus for making various adjustments and settings. • Basic OSD menu: provides primary menu functions. (See Basic menu on page • Advanced OSD menu: provides full menu functions. (See Advanced menu on page To access the OSD menu, press MENU on the projector or remote control.
  • Page 22 Likewise, when you wish to switch from the Advanced OSD menu to the Basic OSD menu, follow the instructions below: 1. Go to Advanced Menu - System > Menu Settings and press OK. 2. Select Menu Type and OK. 3. Press / to select Basic. Next time when you turn on the projector, you may access the Basic OSD menu by pressing MENU.

  • Page 23: Securing The Projector

    Please write down the recall code, and contact 2. Write down the number and turn off your projector. BenQ Customer Center. 3. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of Recall Code: purchase documentation to verify that you are an authorized user of the projector.

  • Page 24: Switching Input Signal

    Be sure the Advanced Menu - Settings > Auto Source Search menu is On if you want the projector to automatically search for the signals. To select the source: MX808ST/MW809ST 1. Press SOURCE. A source selection bar appears. 2. Press until your desired signal is selected and press OK.

  • Page 25: Shutting Down The Projector

    Shutting down the projector 1. Press on the projector or on the remote control and a confirmation message will appear prompting you. If you don't respond in a few seconds, the message will disappear. 2. Press a second time. The power indicator flashes orange, the projection lamp shuts down, and the fans will continue to run for approximately 90 seconds to cool down the projector.

  • Page 26: Menu Operation

    There are several options to set the image's aspect ratio depending on your input signal source. • Auto: Scales an image proportionally to fit (MX808ST/ (MW809ST/ the projector's native resolution in its MX825ST) MW826ST) horizontal or vertical width.
  • Page 27 The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type. • Bright: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms.

  • Page 28: Advanced Menu

    Advanced menu Picture The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type. • Bright: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms.
  • Page 29 This feature utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing truer, more vibrant colors in picture. It enables a greater than 50% brightness increase in mid-tone Brilliant Color images, which are common in video and natural scenes, so the projector reproduces images in realistic and true colors.
  • Page 30 Display There are several options to set the image's aspect ratio depending on your input signal source. • Auto: Scales an image proportionally to fit (MX808ST/ (MW809ST/ MX825ST) MW826ST) the projector's native resolution in its horizontal or vertical width.
  • Page 31 Displays the position adjustment page. To move the projected image, use the Position directional arrow keys. This function is only available when a PC signal (analog RGB) is selected. This projector features a 3D function which enables you to enjoy the 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images.
  • Page 32 Returns all of the adjustments you’ve made for the Display menu to the factory Reset Display preset values. Network (MX825ST/MW826ST) Wired LAN BenQ Network Projector Operation Guide. AMX Device When this function is On, the projector can be detected by AMX controller. Discovery MAC Address Displays the mac address for this projector.
  • Page 33 Quick Cooling: Selecting On enables the function and projector cooling time will be shortened from a normal 90-second duration to approximately 15 seconds. Blank Timer Sets the image blank time when there is no action taken on the blank screen, once elapsed the image will return to the screen.
  • Page 34 Selects a baud rate that is identical with your computer’s so that you can connect Baud Rate the projector using a suitable RS-232 cable and update or download the projector’s firmware. This function is intended for qualified service personnel. Adjusts the equalizer gain settings for an HDMI signal. The higher the setting, the HDMI stronger the gain value.
  • Page 35 • Closed Caption Enable: Activates the function by selecting On when the selected input signal carries closed captions. Closed Caption Captions: An on-screen display of the dialogue, narration, and sound effects of TV programs and (MX825ST/ videos that are closed captioned (usually marked as "CC" in TV listings). MW826ST) •...

  • Page 36: Maintenance

    Maintenance Care of the projector Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface. Please be sure to turn off the projector and let it cool down completely before cleaning the lens. • Use a canister of compressed air to remove dust. •...
  • Page 37 The following Lamp warning displays will remind you to change the lamp. Notice Order a replacement lamp Install a new lamp for optimal performance. Press Equivalent lamp hour >XXXX hours dismiss the message. Order a new lamp at www.BenQ.com Maintenance...
  • Page 38 Replace lamp soon diminishes with use. This is normal lamp behavior. You can Equivalent lamp hour >XXXX hours replace the lamp whenever you notice that the brightness level Order a new lamp at www.BenQ.com has significantly diminished. Press to dismiss the message.
  • Page 39 3. Remove the lamp cover from the projector. • Do not turn the power on with the lamp cover open. • Do not insert your fingers between the lamp and the projector. The sharp edges inside the projector may cause injuries 4.
  • Page 40 13. Tighten the screw that secures the lamp cover. • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screw. 14. .Connect the power and restart the projector. Resetting the lamp timer 15.
  • Page 41 Indicators Light Status & Description Power events Stand-by mode Powering up Normal operation Normal power-down cooling Download CW start fail Lamp events Lamp error in normal operation Lamp is not lit up Lamp life exhausted Thermal events Fan 1 error (the actual fan speed is outside the desired speed) Fan 2 error (the actual fan speed is outside the desired speed) Temperature 1 error (over limited temperature) Thermal sensor 1 open error...

  • Page 42: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC power jack on the projector, and plug the power cord into the power outlet. If There is no power from the power cord. the power outlet has a switch, make sure that it is switched Attempting to turn the projector on again during Wait until the cooling down process has completed.

  • Page 43: Specifications

    Projector specifications All specifications are subject to change without notice. Optical Input terminals Resolution Computer input 1024 x 768 XGA (MX808ST/MX825ST) RGB input 1280 x 800 WXGA (MW809ST/MW826ST) D-Sub 15-pin (female) x 2 Display system Video signal input 1-CHIP DMD...

  • Page 44: Dimensions

    Dimensions 296 mm (W) x 116 mm (H) x 237 mm (D) Unit: mm Specifications...

  • Page 45: Timing Chart

    1024 x 768 XGA_85 84.997 68.667 94.500 XGA_120 (Reduce 119.989 97.551 115.5 Blanking) 1152 x 864 1152 x 864_75 67.5 BenQ 1024 x 576 60.0 35.820 46.966 Notebook_timing BenQ 1024 x 600 64.995 41.467 51.419 Notebook_timing 1280 x 720 1280 x 720_60 45.000...
  • Page 46 119.989 97.551 115.5 Blanking) 1152 x 864 1152 x 864_75 67.5 1280 x 768 1280 x 768_60 59.87 47.776 79.5 BenQ Notebook 1024 x 576@60Hz 60.00 35.820 46.996 Timing BenQ Notebook 1024 x 600@65Hz 64.995 41.467 51.419 Timing 1280 x 720 1280 x 720_60 45.000...
  • Page 47 • Video timings Supported 3D format Vertical Horizontal Pixel Timing Resolution Frequency Frequency Frequency Frame Frame Side by (Hz) (kHz) (MHz) Sequential Packing Bottom Side 480i 720 x 480 59.94 15.73 480p 720 x 480 59.94 31.47 576i 720 x 576 15.63 576p 720 x 576...
  • Page 48 Supported timing for Video and S-Video inputs Supported 3D Horizontal Frequency Vertical Frequency Color sub-carrier Video mode format (kHz) (Hz) Frequency (MHz) Frame Sequential NTSC 15.73 3.58 15.63 4.43 SECAM 15.63 4.25 or 4.41 PAL-M 15.73 3.58 PAL-N 15.63 3.58 PAL-60 15.73 4.43...
