Quick Start Guide

Quick Start Overview

The evaluation board is designed to ease customer evaluation of the PE25200 DC-DC converter. This section
guides you through configuring the hardware and the startup procedures.

Evaluation Board Overview

The evaluation board is designed to ease customer evaluation of Murata's products. The board contains:
Input/output terminals
■
Test point hoops for voltage sense points and connection of voltmeters, oscilloscopes, etc.
■
Jumper links for changing the mode of operation
■
On‐board load
Not equipped
Jumper
link array
http://www.murata.com/products/power
Copyright ©2021 Murata Manufacturing Co., Ltd. and pSemi Corporation, a Murata Company. All rights reserved.
DOC-105510-1 (07/2021)
High Efficiency DC-DC Converter
‐Vout
(load) Vout sense
connector points
‐Vin Vin sense
connector points
Figure 1. PE25200 Evaluation Board Assembly
PE25200 EVK User's Manual
+Vout
(load)
connector
INPUT
TERMINALS
+Vin
connector
Page 3 of 25
