Murata PE25200 User Manual page 5

SYNCSEL
MODE
FF
FTUNE
SS
EVK Connection
Connect the EVK and the measuring equipment as shown in Figure 4.
‐Ve
Adjustable
‐Ve sense
bench power
+Ve sense
supply
15V max 5A
+Ve
http://www.murata.com/products/power
Copyright ©2021 Murata Manufacturing Co., Ltd. and pSemi Corporation, a Murata Company. All rights reserved.
DOC-105510-1 (07/2021)
High Efficiency DC-DC Converter
No function
Divide by 2
Fixed frequency
Nominal
600mA
Figure 3. Typical Jumper Settings and Options
DMM
Figure 4. EVK Connectors
PE25200 EVK User's Manual
No function
No function
Divide by 3
No function
Asynchronous
Cycle skip
15%
‐15%
2.1A
1.1A
DMM
‐Ve
‐Ve sense
Adjustable
+Ve sense
electronic load
+Ve
Page 5 of 25
