PE25200 BOM Listing
PART REFERENCE
C1 C2 C4 C5 C21 C23
C3 C6
C7 C8 C34 C35
C9 C11 C12 C31
C13-C16
C17-C20
C1A C1B C2A C2B CLK
CYABOK CYABOKEN
CYACLK CYACLKEN EN_TP
FF FTUNE MODE P1A P1B
P2A P2B PGOOD SS TESTIO
VPP
C22 C24 C27 C30
C25 C26 C28 C29
JP2 JP6 JP7 JP15-JP18
L1-L5
P1
PCB1
R1
http://www.murata.com/products/power
Copyright ©2021 Murata Manufacturing Co., Ltd. and pSemi Corporation, a Murata Company. All rights reserved.
DOC-105510-1 (07/2021)
High Efficiency DC-DC Converter
VALUE
CAP, SMD, CER, 10 µF, 16V, +/-
10 µF
10%, X7S, 0805 (2012 Metric)
CAP, SMD, CER, 22 µF, 6.3V, +/-
22 µF
20%, X7T, 0805 (2012 Metric)
CAP, SMD, CER, 22 µF, 25V, +/-
22 µF
20%, X6S, 1206 (3216 Metric)
CAP, SMD, CER, 2.2 µF, 10V, +/-
2.2 µF
10%, X7R, 0402 (1005 Metric)
CAP, SMD, CER, 47 µF, 6.3V, +/-
47 µF
10%, X7R, 1210 (3225 Metric)
CAP, SMD, CER, 0.1 µF, 25V, +/-
0.1 µF
20%, X7R, 0402 (1005 Metric)
CONN, Test Points, PC Test Point,
5002 Miniature, Test Point TH, Male,
THM, 5002 - White
DNI DNI
DNI DNI
CONN, Rectangular Connectors -
TSW-103-07-G-
Headers, Male Pins, Header, TH,
S
Male, TSW, (3-POS)
IND, SMD, Multilayer - Power -
Automotive, LQM2MPZ_JH, 0.1uH,
0.1 µH
4000mA(85 C), 3000mA(125 C),
0.019 Ohms, 0806 (2016 metric)
CONN, Rectangular Connectors -
PREC010SAAN-
Headers, Male Pins, Header, TH,
RC
Male, 0.100" (2.54mm), 10 POS
MISC, DOC, PCB, PE25200
PCB
DEVICE EVK
RES, SMD, Thick Film, 10K, +/-1%,
10K
1/8W, 0805 (2012 metric)
PE25200 EVK User's Manual
DESCRIPTION MANUFACTURER PN
GRM21BC71C106KE11L
GRM21BD70J226ME44L
GRM31CC81E226ME11L
GRM155C71A225KE11D
GCM32ER70J476KE19L
GRM155R71E104ME14D
5002
DNI
DNI
TSW-103-07-G-S
LQM2MPZR10MJH
PREC010SAAN-RC
PRT-72806-01
CRCW080510K0FKEA
