(GPS Pin Assist, APL, Active Green, Real Green Undulation, Course Preview)
▣ How to Use
1. Color may transfer from dark colored clothes or leather accessories.
2. Wipe off any dirt immediately.
3. Keep out from contact of water.
4. When battery level is low, residual battery level (
only the laser functions are available.
5. When the residual battery level indicator changes to
able.
6. Please use only the dedicated USB charging cable with a C-type USB port.
7. Please activate GPS in a space without obstacles such as roofs and trees (e.g. starting plaza).
8. Reset: To reset, please long-press the Power and Mode buttons for more than 6 seconds.
▣ Components
- Device, Pouch, USB Cable, User Manual
▶ Device
1. Laser Receiving Lens / Objective Lens
2. Laser Transmitting Lens
3. Mode Button
4. Power Button / Measurement Button
VOICECADDIE SL2 USER MANUAL
5. Eyepiece and Focusing Unit
6. USB Charging Terminal
7. LCD Touchscreen Display
8. GPS Receiver
) blinks on the laser LCD display. In this case,
, the device may be turned off and inoper
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Voice Caddie SL2
Summary of Contents for Voice Caddie SL2
- Page 1 VOICECADDIE SL2 USER MANUAL (GPS Pin Assist, APL, Active Green, Real Green Undulation, Course Preview) ▣ How to Use 1. Color may transfer from dark colored clothes or leather accessories. 2. Wipe off any dirt immediately. 3. Keep out from contact of water.
- Page 2 9. Laser Measurement Indicator ▣ Laser LCD Display ▶ LCD Brightness Short-press together to adjust brightness in 1 to 6 steps. You can check brightness level on the numerical laser LCD display. ▶ Change Unit of Measurement Long-press to change unit of measurement between M (meter) and Y (yard). ▶...
- Page 3 ▣ Mode Guidelines ▶ SLOPE - NORMAL - This mode provides distance compensated to the target position, linear distance, slope guidance and continuous measurement (scanning). - SCAN: You can continuously measure the target while pressing the button. ▶ SLOPE – PIN(GPS Pin Assist) - This mode measures the slope compensated distance, linear distance and slope to the pin.
- Page 4 ▶ TOURNAMENT - This mode measures only the linear distance for the pin measurement and scanning functions. - Long-pressing the button converts to scanning function. ▣ How to Use GPS Golf Mode - Pressing the button activates the laser and GPS function. ▶...
- Page 5 - About APL APL recognizes the pin location and automatically changes the pin location. It guides you through golf courses with APL. Clicking the APL button in ‘My Voice Caddie’ applicatio n activates the APL function. The pin changes to when APL is activated.
- Page 6 ▶ Real Green Undulation - Green contour lines are divided in 11 steps with 15cm intervals to provide more precise green undul ation. ▶ Active Green - User location is recognized to automatically convert the green direction.
- Page 7 Change user position ▶ Green Attack Info - Green Attack info shows back green safe distance, green horizontal and vertical distance. ▶ Course Preview - Course preview shows the course layout from teeing ground to green. Course View: Touching enters the course preview. Course Preview: Guides you through the overall course layout from teeing ground to green.
- Page 8 2. Green View Zoom ※ Zoom-in display does not support active green function. ▣ Cautions 1. This device may be affected by the weather and surrounding climate such as rain and cloud. 2. Battery consumption may vary depending on user environment and frequency of use. 3.
- Page 9 12. Gradual aging and performance degradation from normal use are not grounds for warranty. ▣ Specifications MODEL VOICE CADDIE SL2 GPS Pin Assist, APL, Active Green, Real Green Undulation, Key Functions Normal / Pin / Tournament Mode, Vibration & Notification,...
- Page 10 4. For after-sales service or compensation to damage, please produce this warranty card and receipt (bill) of purchase. Warranty Period Model VOICE CADDIE SL2 1 year from purchase (Or 6 months for other com Serial No. ponents)
-
Page 11: Fcc Warning Statement
FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s a uthority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
