- Page 1 Product Information Force 5i Winches Models FA2.5i-MR, FA2.5i-MR-CE, FA5i-MR, and FA5i-MR-CE (Dwg. MHP2669) Save These Instructions Form MHD56435 Edition 6 January 2014 45899770 2014 Ingersoll Rand ©...
-
Page 2: Product Description
Only allow trained technicians to perform maintenance on this product. For additional information contact factory or nearest Ingersoll Rand Ingersoll Rand Distributor. For additional supporting documentation refer to Table 1 ‘Product Information Manuals’ on page 2. Manuals can be downloaded from http://www.ingersollrandproducts.com. The use of other than genuine Ingersoll Rand replacement parts may result in safety hazards, decreased performance and increased maintenance and will invalidate all warranties. -
Page 3: Specifications
SPECIFICATIONS Model Code Explanation Example: FA5i-MR24MK1G FA5i-MR Series (Capacity): FA2.5i 3,810 lbs (1,445 kg) Personnel Rating; 5,000 lbs (2,268 kg) Utility Rating FA5i 6,875 lbs (3,118 kg) Personnel Rating; 11,000 lbs (4,990 kg) Utility Rating Man Rider™ Drum Flange Height Standard flange Drum Length (Distance between drum flanges): Standard (Refer to Table 4 ‘Available Drum Lengths’... - Page 4 Table 2: Specifications Air System Rated Performance (at rated pressure/volume) Air Consumption Net Weight ** Full Drum Full Drum Max Stall Pull, 1st Maximum Operating (at rated pressure Rated Force Models Line Pull Line Speed Layer Freeboard Mode and load) Operating Limit Pressure...
-
Page 5: Installation
INSTALLATION Prior to installing the product, carefully inspect it for possible shipping damage. Wire Rope Selection Products are supplied fully lubricated from the factory. Check oil levels and adjust as necessary before operating product. Refer to “LUBRICATION” section Consult a reputable wire rope manufacturer or distributor for assistance in selecting on page 9 for recommended oils and lubrication intervals. - Page 6 Mufflers n Drum Guard Ensure mufflers are installed in winch exhaust manifold and control valve exhaust A drum guard is standard on all MR and MR-CE winches. port. Check mufflers periodically to ensure they are functioning correctly. Refer to the Product Parts Information Manual. Shut Off Valve Drum guard panels must be adjusted to suit wire rope departure angle.
-
Page 7: Operation
Table 8: Winch Bolt Hole Mounting Dimensions - Refer to Dwg. MHP0133 on page 11; A. Drum. Drum Length (inches) Models Dimension inch “A” inch “B” * FA2.5i-MR and FA2.5i- inch Note 3 “B” ** MR-CE (Note 1) inch 0.6875 “C”... -
Page 8: Winch Brakes
Man Rider Mode: The winch shall not be able to lift a load greater than 150% of the rated Man Rider n Emergency Stop and Overload System (Personnel) load. If this is possible, adjustment is required. Emergency Stop and Overload System are standard on all MR-CE winches. 1. - Page 9 3. Operate winch slowly to open brakes for lowering the person the shortest way 2. Equipment which has been idle for a period of over six months shall be given a to safety. complete inspection conforming with the requirements of ‘Periodic Inspection’ before being placed in service.
-
Page 10: General Lubrication
The motor should be level-checked daily or at the start of each shift after any Table 9: Lubrication Intervals accumulated water has been drained off. When motors are operated in temperatures Component Interval below freezing, wait long enough at the end of shift for water to separate from oil but not long enough for it to freeze. - Page 11 PRODUCT INFORMATION GRAPHICS Lift Slider Handle UP to Unlock DRUM Haul-In Payout Air Inlet Port 1-1/4 NPT (Dwg. MHP0133) Brake Release Port 1/4 NPT Exhaust Port 1-1/2 NPT (Dwg. MHP1809) (Dwg. MHP2686) Air Out Regulator Air In Lubricator Filter (Dwg. MHP2619) (Dwg.
- Page 12 PRODUCT INFORMATION GRAPHICS (CONTINUED) To Brake Fill Cap Vent Cap Threaded Ports Level Plug (Dwg. MHP2043) Drain Plug (Dwg. MHP2126) Fill Plug Drum Position Reduction Gear Assembly Level Plug Position Inboard Upright (Dwg. MHP0140) (Dwg. MHP2398) (Dwg. MHP1348) Form MHD56435 Edition 6...
- Page 13 PRODUCT INFORMATION GRAPHICS (CONTINUED) “Emergency Stop” Button (Dwg. MHP2688) “ON” Button Function Main Air Levers Supply Pendant Handle Rotate handle to use in normal condition (Dwg. MHP1892) Emergency Lowering Inlet (Dwg. MHP3143) (Dwg. 45899051) Form MHD56435 Edition 6...
- Page 14 DECLARATION OF CONFORMITY (CS) PROHLÁŠENÍ O SHODĚ (DA) OVERENSSTEMMELSESERKLÆRING (DE) KONFORMITÄTSERKLÄRUNG (EL) ∆ΗΛΩΣΗ ΑΝΑΓΝΩΡΙΣΗΣ (ES) DECLARACIÓN DE CONFORMIDAD (FI) VAKUUTUS NORMIEN TÄYTTÄMISESTÄ (FR) CERTIFICAT DE CONFORMITÉ (HU) MEGFELELŐSÉGI NYILATKOZAT (IT) DICHIARAZIONE DI CONFORMITÀ (NL) SCHRIFTELIJKE VERKLARING VAN (LT) ATBILSTĪBAS DEKLARĀCIJA (LV) ATITIKTIES DEKLARACIJA CONFORMITEIT (NO) KONFORMITETSERKLÆRING (PT) DECLARAÇÃO DE CONFORMIDADE (PL) DEKLARACJA ZGODNOŚCI (SK) PREHLÁSENIE O ZHODE (SL) IZJAVA O SKLADNOSTI...
- Page 15 DECLARATION OF CONFORMITY (CS) PROHLÁŠENÍ O SHODĚ (DA) OVERENSSTEMMELSESERKLÆRING (DE) KONFORMITÄTSERKLÄRUNG (EL) ∆ΗΛΩΣΗ ΑΝΑΓΝΩΡΙΣΗΣ (ES) DECLARACIÓN DE CONFORMIDAD (FI) VAKUUTUS NORMIEN TÄYTTÄMISESTÄ (FR) CERTIFICAT DE CONFORMITÉ (HU) MEGFELELŐSÉGI NYILATKOZAT (IT) DICHIARAZIONE DI CONFORMITÀ (NL) SCHRIFTELIJKE VERKLARING VAN (LT) ATBILSTĪBAS DEKLARĀCIJA (LV) ATITIKTIES DEKLARACIJA CONFORMITEIT (NO) KONFORMITETSERKLÆRING (PT) DECLARAÇÃO DE CONFORMIDADE (PL) DEKLARACJA ZGODNOŚCI (SK) PREHLÁSENIE O ZHODE (SL) IZJAVA O SKLADNOSTI...
- Page 16 www.ingersollrandproducts.com...
