Device Overview

Speaker

Power

Button

Action

Button

Elbow Joint

Mic B2

Micro USB

Removable Head Pad

Micro SD

Card Slot

Camera

Removable Head Strap

Shoulder Joint

Flashlight

Display Pod

Mic A1

(A2 on opposite side)

Boom Arm

Display Window

Mic B1

Audio Jack

Table of Contents

Do you have a question about the HMT-1 and is the answer not in the manual?

Page 1 Device Overview Removable Head Pad Removable Head Strap Speaker Mic B1 Power Button Shoulder Joint Flashlight Action Button Micro SD Display Pod Card Slot Elbow Joint Camera Mic A1 (A2 on opposite side) Boom Arm Display Window Audio Jack Mic B2 Micro USB...
Page 2 Charging the HMT-1 1. Connect the USB C charging cable as shown. 2. Connect the cable to the wall charger as shown and plug in. The power button will blink RED when charging and turn GREEN when fully charged. Regional Wall Charger...
Page 3 4. Put on the hard hat and if applicable, tighten until secure and comfortable. 5. To remove the HMT-1 from the hard hat, pinch the clip fingers and push the clip out of the hard hat slots.
Page 4 Do not extend the display too far from your eye. Keep the display as close to the eye as possible for the best viewing experience. Adjust the overhead strap such that the HMT-1 rests horizontally, slightly above the tops of your ears. Position the shoulder and elbow joints into a “Z” shape, below the line of sight, left or...
Page 5 Point the camera at the QR code you generated in Step 1. The HMT-1 will detect the QR code and configure the device. Note: Once the device connects to WiFi an update of RealWear Device Agent may occur. Say What You See The HMT-1 is controlled by voice and head motion.
