FrSky Scout VS600 Series Instruction Manual

Instruction Manual for FrSky Scout VS600 Series (MIC certificated Version)

Introduction

Thank you for purchasing the FrSky video transmission device. A simple and clean design, equipped with a
switchable power output and operating band and channel. Paired with a FrSky radio transmitter, the parameters can
be adjusted conveniently through the gTrans.lua script. In addition Scout VS600 BLACK/VS600 RED has a built-in
microphone which transmits audio. To fully enjoy all the features of this device please thoroughly read the
instructions below to set up the device.
Overview
23.55 mm
Scout VS600 RED
17 mm
BLUE
RED
GREEN
Scout VS600 Mini
FrSky Electronic Co., Ltd. www.frsky-rc.com
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: sales4tech@gmail.com
24 mm
13 mm
GREEN
RED
BLUE
Scout VS600 BLACK
Button
S.Port
- S.Port
VDD5.0
VEDIO IN
GND
Contact us: frsky@frsky-rc.com
01140183
Version
1.0

Specifications

Model Name
Scout VS600 RED
Scout VS600 Black
Scout VS600 Mini
• Transmission Frequency: 5.7 GHz
• Transmission Power: ＜0.01mW (pit mode) / 25mW / 100mW / 200mW / 300mW / 600mW
* Only Scout VS600 BLACK and Scout VS600 RED support 600 MW power output.

Features

• Support S.Port
• Support inverted S.Port
• Built-in microphone (Scout VS600 Red & Black)
• Adjustable RF power
• Support set parameters by gTrans.lua / Button

Transmission Frequency

CH
CH1
Band
5655
A
5705
B

LED State

LED
Indication
Flash 1 time
Flash 2 times
Flash 3 times
Flash 4 times
Flash 5 times
Flash 6 times
The Scout VS600 Series has a green LED/red LED/blue LED which indicates the RF power/frequency band/chan-
nel. As you press the button key, the LED will flash, indicating the corresponding RF power level/frequency
band/channel.
Note: Only Scout VS600 BLACK and Scout VS600 RED support 600 mW power output.

Configuration method

1. Manual configuration（by the Button）
Press the button for (3s) to enter the power/channel/frequency selection mode, press the button for (3s) again
to switch between power/channel/frequency.
FrSky Electronic Co., Ltd.
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: sales4tech@gmail.com
Instruction Manual for FrSky Scout VS600 Series (MIC certificated Version)
L*W*H (mm) Weight (g) Available Channel
31.5*23.6*4.5 4.2 10CH
31*24*4.9 4 10CH
17*15.3*4 1.2 10CH
CH2 CH3
5665 5675
5715 5725
Green Red
Power Band
Pit Mode A
25mW B
100mW /
200mW /
300mW /
* 600mW /
www.frsky-rc.com Contact us: frsky@frsky-rc.com
01140183
Version
1.0
Operating Voltage
2-6S
2-6S
5V
CH4 CH5
5685 5695
5740 5750
Blue
Channel
CH1
CH2
CH3
CH4
CH5
