- Page 1 ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS s i s t e m a i r . c o m Technical manual PRIME...
- Page 3 INSTRUCTION MANUAL • Type: domestic vacuum cleaner Line • Model: TECNO TECNO • Revision 1.0.0 INDEX TECHNICAL DATA AUTHORIZED USE OF THE VACUUM CLEANER 2.1 Using the service socket (only for Evox) UNAUTHORIZED USE OF THE VACUUM CLEANER SAFETY FEATURES 4.1 Warning 4.2 IP protection degree 4.3 Electrical insulation degree...
-
Page 4: Technical Data
Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 1 - TECHNICAL DATA TECNO Prime TECNO Evox Tecno Tecno Tecno Tecno Tecno Tecno Tecno Tecno Style Style Style Style PRIME 150 PRIME 250 PRIME 350 PRIME 450 Model Article 3110.2TPR 3112.2TPR 3113.3TPR 3115.3TPR... - Page 5 2 - AUTHORIZED USE OF THE VACUUM CLEANER The Tecno lines vacuum cleaner has been designed exclusively to vacuum clean house dust, very small-size solids and dry materials. The use of the central vacuum cleaner is authorized for household and civil uses, connected to a PVC wall-traced piping network and to a standard home electrical wiring. The vacuum cleaner can be installed in domestic dwellings with the following characteristics: •...
- Page 6 4 - SAFETY FEATURES WARNING: TECNOPLUS S.R.L. declines any form of responsibility or guarantee if the purchaser, or anyone in his stead, makes even the slightest modifi cation or adjustment to the purchased product. The unit has been designed to satisfy at best the present needs of the domestic central vacuum clean- ers market, both in terms of quality and operating capacity.
-
Page 7: Ip Protection Degree
4.4 Declaration of absence of dangerous substances TECNOPLUS S.r.l. declares that its products and appliances have been manufactured with materials which comply with the restrictions established by the health and environment protection regulations in force and do not contain SVHC-classifi... -
Page 8: Movable Closure Guards Safety
There are no movable closure guards assembled on the appliance. Every guard assembled is consid- ered a fi xed guard and is fastened with special screws. TECNOPLUS s.r.l. reminds you that it is abso- lutely forbidden to replace the screws used for the design and manufacture the appliances with screws that feature different characteristics. - Page 9 Unscrew the screws and re- move the top cover. Remove the dust collection bin Unscrew the screws and remove the front panel, paying attention to the electrical wiring Unscrew the screws and remove the back panel, paying attention to the electrical wiring Unscrew the screws and remove the wall fi...
- Page 10 Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS Turn the vacuum unit cylinder and assemble all the previously detached parts, paying great at- tention to the electrical wiring 04/06/2019 Rev:1.0.0...
-
Page 11: Preliminary Operations
6 - INSTALLATION - WARNING - THESE PROCEDURES MUST BE CARRIED OUT BY QUALIFIED PERSONNEL 6.1 Preliminary operations The suction system is shipped to the customer completely assembled and packed. Before switching the machine on, the following checks are advisable: •... -
Page 12: Drill The Holes
Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 6.3 Fixing the vacuum cleaner to the wall The vacuum cleaner must be securely and permanently fi xed to a solid wall using the bracket provided and the suitable wall anchors or plugs taking into account that the total weight to be supported can be seven/eight times that of the system itself. - Page 13 6.4 Connection to the piping network 1. Using the sleeve, connect the dust inlet coupling of the cyclonic vacuum cleaner, identifi ed with (A) in the picture, to the suction pipe from the piping network. 2. By using the sleeve, connect the air outlet of the central vacuum unit, marked with (B), to the air outlet of the house.
-
Page 14: Electrical Connection
Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 6.5 Electrical connection WARNING: the electrical connection must be carried out ONLY by qualifi ed personnel. Before connecting the system to the electrical power supply check that the supply voltage corresponds to that required by the vacuum cleaner (see the identifi... -
Page 15: Programmed Routine Maintenance
7 - MAINTENANCE BEFORE CARRYING OUT ANY MAINTENANCE OPERATION, IT IS MANDATORY TO UNPLUG THE POWER SUPPLY CABLE FROM THE POWER SUPPLY INLET. PROTECTIVE MASK AND GLOVES MUST ABSOLUTELY BE WORN 7.1 Programmed routine maintenance Maintenance should be carried out according to the effective running time of the system so to ensure effi... - Page 16 Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 7.3 Extraordinary maintenance (only for TECNO PRIME) The unit features a special display which signals the need for extraordinary maintenance, to be carried out by qualifi ed and/or authorized staff. The extraordinary maintenance have been programmed: •...
- Page 17 Put the conveyor cone back in position Reassemble the dust bin inside its housing under the suction system and lock the closing handles. Switch the suction system on by pressing the ON/OFF switch. After re-starting the system push the “RESET” button to reset the dust bin alarm. Remember to take care when emptying the bin: if there is a huge quantity of dust, make sure you do not throw away the conveyor cone.
-
Page 18: Repairs And Spare Parts
Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 8 - REPAIRS AND SPARE PARTS 8.1 Intervention criteria Any intervention on the vacuum cleaner for repairs and/or maintenance which are not expressly authorized in this manual is absolutely forbidden. Any repair for breakage or malfunctioning must be carried out by qualifi ed Technical Assistance personnel. Any intervention of non-authorized personnel will result in the invalidation of any guarantee of the product and the manufacturer will not be held responsible for any eventual damage to persons and/or objects due to such interventions. -
Page 19: Troubleshooting
9 - TROUBLE SHOOTING 9.1 Thermal switch The thermal switch prevents damages to the electric and electronic parts from power overloads and from short-circuits. The switch button is located inside its lodging during the regular functioning of the machine, while in case of activated protection it will be out of its lodging. - Page 20 Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS PROBLEM CAUSE SOLUTION PRIME Only for TECNO units Alarm signalled on the display Eseguire RESET dell’allarme The power cable is unplugged Connect the power cable The start button is on OFF Press the Start button There is no suction from any of the position...
- Page 21 PROBLEM CAUSE SOLUTION Check for a possible clogging in the piping network Check for a possible clogging in the air discharge pipe The suction works intermittently with the Intervention of the motor hose inserted in the inlet. thermal protection Remove the hose from the suction inlet and wait a couple of minutes to let the motor cool down...
-
Page 22: Exploded View Drawings
Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 10 - EXPLODED VIEW DRAWINGS TECNO EVOX Soundproofi ng Motor thermal protection Motor compartment Motor Main switch Electronic board Thermal switch Service inlet Air exhaust switch Dust inlet Fixing plate Service inlet Cilynder motor body Closing handle... - Page 23 TECNO PRIME Soundproofi ng Motor thermal protection Motor compartment Motor Main switch Thermal switch Electronic board with control panel Ethernet connection Air exhaust Dust inlet Fixing plate BiVac predisposition Cilynder motor body Closing handle Filter cartridge and hook Dust bin Conveyor cone 04/06/2019 Rev:1.0.0...
- Page 24 Instruction manual TECNO line ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 11 TECNO Prime BiVac accessories Dust vacuum cleaning Kit with bag Gasket Bag suction dust inlet Aesthetic frame for (elbow coupling) elbow connector Dust bag Cyclone dust vacuum cleaning Kit with service outlet Gasket Service suction socket...
- Page 25 SUPPLEMENTARY MANUAL • Type: domestic vacuum cleaner TECNO PRIME • Model: Tecno PRIME Line • Revision 1.0.0 INDEX OPERATING CONIFIGURATION CONNECTION TO THE PIPING NETWORK (bag suction) REPLACING THE DUST BAG (bag suction) AUXILIARY CONNECTION SIGNAL ON-BOARD COMPUTER PROGRAMMING 5.1 Main view 5.2 First installation menu 5.2.1 Product model selection 5.2.2 Date and time setting...
-
Page 26: Operating Configurations
Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 1 - OPERATING CONFIGURATIONS Confi guration 1 cyclonic (bagless) suction with service suction socket: the customer can choose to assemble the service suction socket directly on one side of the appliance which allows connecting a fl... - Page 27 2 - CONNECTION TO THE PIPING NETWORK (bag suction) 1. If the service suction inlet is already assembled on the body of the appliance remove it being careful not to damage the inserted gasket. 2. In case of fi rst installation, the body of the vacuum cleaner body is completely disconnected; for this reason, install the elbow coupling, provided with the kit, in the lower hole, being careful to position the sealing gasket in the internal side between the coupling and the body.
- Page 28 Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS Slide the dust-collecting bag from the ver- tical end of the inlet opening Introduce a new dust bag Reassemble the dust container in its housing under the vacuum cleaner and close it again. Switch the vacuum cleaner on by pressing the ON/OFF switch.
-
Page 29: Main Screen
ON-BOARD COMPUTER PROGRAMMING With the display touch, it is possible to send controls to the unit management computer, make working choices, program the ordinary maintenance and introduce the installer personal data. 5.1 Main screen 12:40 DATE 05.02.2019 WATCH WARNING SUCTION ON INDICATION SUCTION POWER mbar... -
Page 30: Date And Time Setting
Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.2 First installation menu When the central vacuum unit is switched on for the fi rst time, a welcome message will appear, after which the fi rst installation menu will be automatically activated to allow the user to customize some of the central vacuum unit settings. -
Page 31: Information Menu
5.2.2 Dust collection container selection DUST BACKET (cyclonic suction) DUST BAG 5.3 INFORMATION menu Through the INFORMATION menu it is possible to view information about the effi ciency of fi ltration of dust, the level of dust inside the bucket / bag, the central vacuum unit, the request for main- tenance Service and the repairs carried out on the product. - Page 32 Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.3.1 FILTER / DUST / SERVICE information menu DUST FILTER Press the button to access the Press the button to access the information about the dust information about the fi lter SERVICE MAINTENANCE Press the button to access the information about the scheduled...
- Page 33 HISTORY List of ordinary maintenance requests with reference to the date and time of the alarm 17:32 06.06.2019 08:05 01.05.2019 15:05 20.03.2019 05/06/2019 Rev:1.0.0...
- Page 34 Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.3.2 Product ID CARD Through this menu it is possible to view information about the product such as model, part number, serial number, fi rmware of the electronic board, date of production and installation. CENTRAL VACUUM UNIT Product ID card Product model...
- Page 35 5.3.3 List of SERVICE Through this menu it is possible to view all the information relating to repairs carried out by the author- ized service center. LIST OF SERVICE HISTORY List of repairs carried out by an authorized CAT service center Motor 06.06.2019 Brushes 01.05.2019 Electronic 20.03.2019...
-
Page 36: Settings Menu
Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.4 SETTINGS menu Using this function it is possible to modify the basic settings of the control system and perform the functional tests of the suction system. TEST MAINTENANCE SETTINGS Test function for checking and Setting modifi... -
Page 37: Maintenance Programming
5.4.1 Maintenance Programming ALARM Through the computer it is possible to modify the intervention times and set the suction shutdown fol- lowing the request for cleaning the fi lter, emptying the dust container and the SERVICE maintenance MAINTENANCE SETTINGS Setting modifi cation and vacuum stop FILTER EFFICIENCY DUST LEVEL SCHEDULED MAINTENANCE... - Page 38 Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.4.1.2 FILTER maintenance scheduling ALARM ALARM SET POINT SETTING FILTER MAINTENANCE ALARM Press the two buttons to change the default value of the alarm switch mbar STOP SUCTION SHUTDOWN SETTING Press inside the cell to activate the suction shutdown in the presence of the alarm 5.4.1.3...
- Page 39 5.4.1.4 DUST COLLECTION BUCKET Maintenance scheduling ALARM ALARM TIMER SETTING DUST BUCKET EMPTYING ALARM Press the two buttons to change the alarm default intervention value STOP SUCTION SHUTDOWN SETTING Press inside the cell to activate the suction shutdown in the presence of the alarm 5.4.1.5 Scheduled maintenance planning...
- Page 40 Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.4.2 Test TEST Through the computer it is possible to carry out tests to make a fi rst level diagnosis regarding the correct connection of the electric line of the suction inlets (MICRO line) TEST Press the button to access the TEST function...
-
Page 41: Change Date And Time
5.4.3 Change date and time ALARM TEST DATE AND TIME Change date and time SETTING TIME Press the two buttons to modify the time DATE SETTING Press the two buttons to change day, month and year settings 05/06/2019 Rev:1.0.0... - Page 42 Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.4.4 Dust container selection ALARM TEST DUST COLLECTION CONTAINER Function to change the dust collection container DUST COLLECTION BUCKET Select this function if you decide to collect the dust in the bucket of the central unit DUST COLLECTION BAG Select this function if you decide to...
- Page 43 5.4.5 Telephone contact SERVICE ALARM TEST TELEPHONE Change telephone contact for technical assistance Use the keypad to set the telephone contact of the SERVICE which will appear in case of scheduled mainte- nance request 05/06/2019 Rev:1.0.0...
- Page 44 Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.4.6 Product model selection ALARM TEST PRODUCT SELECTION MODEL Function to modify the product model Select the model of the product shown in the fi eld “Model” on the technical data label ........
- Page 45 5.4.7 AIR CLOUD ethernet connection ALARM TEST ETHERNET Check LAN connection ACTIVE COMMUNICATION MAC ADDRESS IP ADDRESS MAC ADDRESS MAC ADDRESS STATUS Identifi cation address TEST of the ethernet network card IP ADDRESS IP ADDRESS Automatically assigned host address from the Ethernet network COMMUNICATION ERROR STATUS AIR CLOUD TEST...
-
Page 46: Service Menu
Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.5 SERVICE menu Menu, password protected, for the input of repairs carried out by the manufacturer authorized assis- tance center. This way the end user will be able to always identify the list of repairs made through the “repair list” menu, see chapter 5.3.3. - Page 47 6 MAINTENANCE NOTIFICATIONS 6.1 Maintenance REPORTING ALARM FILTER CLEANING REQUEST This screen indicates the requests for cleaning the fi ltering cartridge after reaching the alarm set point STOP PLAY Pressing this button starts a demonstration animation for fi lter cleaning. 6.2 BUCKET DUST emptying notifi cation ALARM DUST EMPTYING REQUEST...
- Page 48 Supplementary manual TECNO Prime ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 6.3 DUST BAG replacement notifi cation (BiVac) ALARM DUST EMPTYING REQUEST This screen indicates the request to replace the dust bag following the reaching of the alarm setpoint STOP PLAY Pressing this button starts a demonstration animation for dust bag replacement 6.4 Scheduled maintenance notifi cation...
- Page 49 7 AIR CLOUD CONNECTION By connecting a LAN cable to the central vacuum unit, using the ETHERNET connector, it will be pos- sible to establish a connection with our server This will allow the user to remotely control the central vacuum unit. In order to activate this function, the user must connect to our website www.sistemair.com and proceed with registration in the appropriate section MODEM...
- Page 50 Instruction manual TECNO line Instruction manual TECNO line ByTecnoplus ByTecnoplus s.r.l. s.r.l. CENTRAL VACUUM SYSTEMS CENTRAL VACUUM SYSTEMS EXPRESS PERSONAL DELIVERY SHOPPER cleanoop.com THE SHOP OF THE CLEAN Cleanoop.com, the o cial Sistem Air store, is online for the purchase of spare parts and accessories. 04/06/2019 Rev:1.0.0...
- Page 52 F0920584 Sistem Air 27020 Gravellona Lomellina (PV) ITALIA - Via Cilavegna, 53 - GPS: N: 45° 19’ 28” ; E: 8° 45’ 32” Group Tel. + 39 0381 650082 - Fax +39 0381 650120 - info@sistemair.com since 1993...
