MicroPMU GPS Time Synchronization Issue
Recovery Procedure
Background
After April 6th, 2019, when the microPMU is powered off and back on, reconfigured, or rebooted, the
micro-synchrophasor measurements will be time-stamped with the wrong date and time and report the
year as 1999, instead of the present UTC date and time. The problem will not show if the microPMU is
left powered on and not restarted.
All microPMU devices will need to have firmware 3.7.319.04.25 or above installed regardless of whether
they exhibit this symptom. The minimum required firmware can be retrieved from the download center
of the PSL website (
.
https://www.powerstandards.com/download/psl_firmware_3-7-3-19-04-25/)
How to Install the Fix
Step 1:
First check the time reported by the microPMU. This can be done through the display screen of the
device.
From the home screen of the display, tap on System, then Date/Time (examples below).
If the time reported reflects today's date, apply the firmware update via USB (see the microPMU
Instruction Manual for details on applying the firmware file). Otherwise, continue to the next steps.
Once the firmware update is complete and the device has rebooted, verify the firmware version number
reported by the device matches version number in the name of the update file. Also make sure the
reported date/time is reflecting today's date.
Revision 2.0
Power Standards Lab 980 Atlantic Ave, Alameda CA 94501, USA
Tel ++1-510-522-4400 Fax ++1-510-522-4455 www.powerstandards.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PSL MicroPMU GPS
Summary of Contents for PSL MicroPMU GPS
- Page 1 MicroPMU GPS Time Synchronization Issue Recovery Procedure Background After April 6th, 2019, when the microPMU is powered off and back on, reconfigured, or rebooted, the micro-synchrophasor measurements will be time-stamped with the wrong date and time and report the year as 1999, instead of the present UTC date and time. The problem will not show if the microPMU is left powered on and not restarted.
- Page 2 NOTE: Physical access to the microPMU will be required for these next steps. If physical access is not possible, please use the contact information at the end of this document to reach out to PSL support before continuing.
- Page 3 Step 4: After the device is shut down the MS1/GPS1 modules must be disconnected completely from the microPMU hardware as seen in the example image below. If the hardware is DIN rail mounted, slide the MS1 module toward the left so that it is no longer physically connected to the microPMU. Step 5: Reconnect input power to the microPMU device and download a copy of its current Setup.ini file via USB (see the microPMU Instruction Manual for details on downloading the setup file).
- Page 4 MS1/GPS1 modules. After the device is shut down, physically reconnect the MS1 and GPS1 modules and restore input power to the microPMU. Finally, check the date reported by the microPMU reflects today’s date. For any further questions or concerns please contact PSL at support@powerstandards.com or by phone at +1-510-522-4400. Revision 2.0 Power Standards Lab 980 Atlantic Ave, Alameda CA 94501, USA Tel ++1-510-522-4400 Fax ++1-510-522-4455 www.powerstandards.com...
