7
1. Insert "Backlight Wire" to LED
Driver BD
2. Insert "Power BD to TBT BD
Wire" to Power BD and TBT BD
3. Insert "Calibrator to MCU BD
Wire" to MCU BD and adhere
tapes and mylar to fix it (See
Orange mark)
4. Adhere foils to Main SHD (See
Purple mark)
- 17 -
