Brandt BCG6600W Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN OPERATING GUIDE
Gas cooker

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCG6600W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brandt BCG6600W

Summary of Contents for Brandt BCG6600W

  • Page 1 EN OPERATING GUIDE Gas cooker...

  • Page 2: Table Of Contents

    CONTENTS 1 / SAFETY INSTRUCTIONS • Respect for the environment 2 / INSTALLING YOUR APPLIANCE • Installation regulations • Positioning the cooker • Electrical connection • Gas connection 3 / USING YOUR APPLIANCE • Using the hotplate burners • Using the oven • Accessories 4 / MAINTENANCE AND CLEANING YOUR APPLIANCE 5 / ADJUSTING YOUR APPLIANCE •...
  • Page 3 1/ SAFETY INSTRUCTIONS — This appliance can be used — The insulation of fixed by children aged 8 years and pipes must be protected by over and by individuals with means of an insulating sleeve physical, sensory or reduced example, mental capacity, or lack of appropriate temperature...

  • Page 4: Safety Instructions

    1 / SAFETY INSTRUCTIONS — — Do not use pans that During cleaning function, the surfaces can protrude beyond the edges of become hotter than during the hotplate. — WARNING: Liquids and normal use. recommended to keep young other food must not be children away (depending on heated in a hermetically model).

  • Page 5: Respect For The Environment

    1 / SAFETY INSTRUCTIONS — WARNING: Do not use install mechanical hotplate protective devices ventilation system. unless they have been Intensive and prolonged use designed by the manufacturer of the appliance may require of these cooking appliances additional ventilation, by or if they are recommended opening window...
  • Page 6 2 / INSTALLATING YOUR APPLIANCE INSTALLATION • REGULATIONS — GAS CONNECTION: - This appliance must be installed in accordance with the regulations in force and used only in a well-ventilated area. THE GAS IS CONNECTED AT THE BACK Please read the instructions before OF THE APPLIANCE IN SUCH A WAY installing and using this appliance.
  • Page 7 2 / INSTALLING YOUR APPLIANCE POSITIONING THE COOKER • 3 TYPES OF COOKER POSITIONING You must observe the following cooker po- sitioning dimensions (fig.1 and 2): - 10 mm between the sides of the appliance and the walls or units. - 30 mm between the wall and the back of the appliance, with the cover closed.
  • Page 8 2 / INSTALLATING YOUR APPLIANCE GAS CONNECTION • Advice Caution Hoses with mechanical end-fittings can be Installation is normally only carried out by obtained from the manufacturer’s After- qualified installers and technicians. Sales Service department (details from the The appliance is supplied pre-set for a brand’s Customer Services Department).

  • Page 9: Installing Your Appliance

    2 / INSTALLING YOUR APPLIANCE CHANGE OF GAS TYPE • HANGING FROM A MAINS GAS SUPPLY TO A BUTANE GAS SUPPLY Caution BUTANE GAS MAINS GAS SUPPLY SUPPLY For changing of all gas types, it is essential to carry out the following three operations: ETER Relief valve...
  • Page 10 2 / INSTALLING YOUR APPLIANCE CHANGE OF GAS TYPE • • Changing the injectors Each injector is identified by a number engraved on it (see Operating Guide). Use an angle wrench to change the injectors and proceed as follows: - Remove the pan supports, the caps and fig.1 the heads of all the burners (fig.
  • Page 11 2 / INSTALLING YOUR APPLIANCE CHANGE OF GAS TYPE • • Changing the injector for the fig.1 oven and grill (depending on model) Change the injectors by carrying out Deflector the following steps: - Remove the deflector by unscrewing the 2 screws holding it (fig.1) - Remove the back cover by unscrewing the 11 retaining screws (fig.1)
  • Page 12 2 / INSTALLING YOUR APPLIANCE CHANGE OF GAS TYPE • Mains gas supply (natural gas) to butane gas - Remove the control knobs. - Using a small screwdriver, fully unscrew the brass screw of each gas burner valve (oven and top).
  • Page 13 2 / INSTALLING YOUR APPLIANCE CHANGE OF GAS TYPE • Note: After adjusting, when changing to reduced flow, the burner flame should not extinguish. The oven burner must not extinguish after the oven door is closed. Avoid closing the door too suddenly and check through the ignition hole that the flame is lit. If the flame extinguishes, unscrew the brass screw slightly.
  • Page 14 COOKER INSTALLATION AND ADJUSTMENT...

  • Page 15: Using Your Appliance

    3 / USING YOUR APPLIANCE USING THE HOTPLATE • BURNERS The reduced flow setting is between the Caution “big flame” symbol and the “small flame” - If there is a power failure, it is still symbol. The dot ● corresponds to the possible to ignite the flame by using a closure of the gas burner valve.
  • Page 16 3/ USING YOUR APPLIANCE USING THE HOTPLATE • BURNERS • Ignition with gas safety device (continued) Press the knob and turn it anti-clockwise until the flame lights. fig.1 Turn while pressing firmly When the flame lights, continue to keep the knob pressed firmly for several seconds (Fig.2).
  • Page 17 3/ USING YOUR APPLIANCE USING THE HOTPLATE • BURNERS • Advice for using the hotplate burners - When the contents of a pan come to a boil, there is no need to continue boiling hard as SIMMERING EBULLIT BOILING the food does not cook any quicker. It will cook better over a smaller flame kept to a light boil.
  • Page 18 3 / USING YOUR APPLIANCE USING THE HOTPLATE • BURNERS • Advice for using the hotplate burners To ensure that the burners ignite correctly, we advise the following: - inspect regularly to check that the igniter electrodes are thoroughly clean and that the burner components are operating correctly, - before igniting, check that the burner heads and caps are fitted correctly,...

  • Page 19: Using The Oven

    3 / USING YOUR APPLIANCE 3 / USING YOUR APPLIANCE USING THE OVEN • Igniting the gas grill • (depending on model) (oven upper burner) - Press and turn the oven control knob to Caution the right until it is in the grill position. Your oven has either electronic ignition or - Continue to press and hold the manual ignition.
  • Page 20 3 3 / USING YOUR APPLIANCE / USI 3 / USING YOUR APPLIANCE NG YOUR APPLI 3 / USING YOUR APPLIANCE USING THE OVEN • • Advice for using the oven Caution - First use: Before using your oven for the - Check that the oven door is closed first time, allow it to warm up while empty properly, so that the seal can perform...

  • Page 21: Accessories

    3 / USING YOUR APPLIANCE • ACCESSORIES (depending on model) • Anti-tipping safety rack fig.1 BACK The rack can be used to support all dishes and moulds containing food for cooking or browning. It can be used for grilling (place the food to be grilled directly on the rack).
  • Page 22 3 / USING YOUR APPLIANCE • ACCESSORIES (depending on model) Rotating grill spit • Spit (depending on model) fig.4 Frame Cooking with a rotating spit is very practical Fork and can produce particularly tasty and Handle evenly cooked meat. To use it: (depending on model) - Fit the frame of the spit in the 3rd shelf...

  • Page 23: Maintenance And Cleaning Your Appliance

    4 / MAINTENANCE AND CLEANING YOUR APPLIANCE CLEANING YOUR COOKER - Use a damp sponge and soapy water, to clean the top. If necessary, after spills, use a cream cleaner that is not abrasive to enamel. Polish off with a dry cloth or better still, with a chamois leather. Do not leave acidic liquid on the enamel (lemon juice, vinegar, etc.).
  • Page 24 4 / MAINTENANCE AND CLEANING YOUR APPLIANCE STANDARD ENAMEL OVEN • Advice - Do not scrape these walls with a metal brush with sharp pointed - Clean the oven walls with a very hot instruments. damp cloth and soapy water to remove grease marks. It is recommended to carry - Do not try to clean them with scouring out this cleaning on a frequent basis.

  • Page 25: Adjusting Your Appliance

    5 / ADJUSTING YOUR APPLIANCE REPLACEMENT OF THE OVEN • CATALYTIC LINERS (depending on model) Before disassembly, allow the appliance to cool and check that the cooker selector knob is in the OFF position. - Side walls with shelf position pressings: Turn the screw one quarter of a turn to fig.1...

  • Page 26: Adjustable Feet

    5 / ADJUSTING YOUR APPLIANCE ADJUSTABLE FEET • (depending on model) fig.1 Some appliances have adjustable feet at the front to obtain correct positioning whatever the type of floor, by screwing and unscrewing. fig.1 REPLACEMENT OF THE OVEN • LAMP (DEPENDING ON MODEL).

  • Page 27: Troubleshooting

    6 / TROUBLESHOOTING Worried that your cooker is not operating properly; there may not be a fault. Check the following points: POSSIBLE YOU NOTICE THAT… WHAT TO DO? CAUSES ➡ Check the gas and electrical - The gas bottle is empty. connection.
  • Page 28 6 / TROUBLESHOOTING If you think your cooker is not operating properly; it may not necessarily be a fault. Check the following points: POSSIBLE YOU NOTICE THAT… WHAT TO DO? CAUSES The length of the burner flames in - This is due to the oven the floor of the thermostat temperature ➡...

  • Page 29: After-Sales Service

    7 /AFTER-SALES SERVICE • OPERATIONS Any work on your appliance must be carried out by a qualified professional representative of the brand. In order to handle your request as efficiently as possible, please provide the full references of your appliance at the time of calling (commercial reference, service reference and serial number).
