Parts list

Item Part number
OMP40-2 A-4071-2001
OMP40-2 A-4071-2002
OMP40-2LS A-4071-3001
Stylus A-5000-3709
Batteries P-BT03-0007
Battery cassette A-4071-1166
Battery cassette A-5625-1166
Seal A-4038-0301
Tool kit A-4071-0060
Styli tool M-5000-3707
Shank adaptor A-4071-0031
assembly
OMI-2 A-5191-0049
OMI-2 A-5191-0050
OMI-2T A-5439-0049
OMI-2T A-5439-0050
OMM-2 A-5492-0049
OSI interface A-5492-2000
OSI interface A-5492-2010
Weak link kit A-2085-0068
Mounting bracket A-2033-0830
Description
OMP40-2 probe with batteries, tool kit and quick-start guide
(set to optical on / optical off) – modulated transmission,
PROBE 1 start.
OMP40-2 probe with batteries, tool kit and quick-start
guide (set to optical on / time off 134 sec) – modulated
transmission, PROBE 1 start.
OMP40-2LS probe with batteries, tool kit and quick-
start guide (set to optical on / optical off) – modulated
transmission, PROBE 1 start.
PS3-1C ceramic stylus 50 mm long with Ø6 mm ball.
½AA lithium-thionyl chloride (LTC) batteries (pack of two).
OMP40-2 battery cassette assembly.
OLP40 metal battery cassette assembly.
Seal for OMP40-2 battery cassette.
Probe tool kit comprising: Ø1.98 mm stylus tool, 2.0 mm A/F
hexagon key and shank grubscrews (x 6).
Tool for tightening/releasing styli.
Shank adaptor assembly for mounting to OMP60, RMP60,
MP700 type shanks.
OMI-2 complete with cable 8 m (26.25 ft) long.
OMI-2 complete with cable 15 m (49.21 ft) long.
OMI-2T complete with cable 8 m (26.25 ft) long.
OMI-2T complete with cable 15 m (49.21 ft) long.
OMM-2 with 8 m (26.25 ft) cable, tool kit and quick-start
guide.
OSI (multiple probe mode) with DIN rail mounting, terminal
block and quick-start guide.
OSI (single probe mode) with DIN rail mounting, terminal
block and quick-start guide.
Weak link (part no. M-2085-0009 × 2) and 5.0 mm A/F
spanner.
Mounting bracket with fixing screws, washers and nuts.
9.1
