DEFINITION OF LIGHT COMMERCIAL:
1. Door Heights less than or equal to 8'0" (< = 8'0") are considered
Residential Applications.
2. Door Heights greater than 8'0" (> 8'0") are considered Light
Commercial Applications.
PLEASE DO NOT RETURN THIS PRODUCT
TO THE STORE
If you need assistance, please call 1-866-
569-3799 (press Option 1) and follow the
prompts to contact a customer service
representative. They will be happy to handle
any questions that you may have.
©Copyright 2021
Wayne Dalton, a division of Overhead Door Corporation
D
O W N
C
OMMERCIAL
T a b l e O f C o n t e n t s
QUICK START GUIDE IMPORTANT NOTICES!
This Quick Start Guide is only meant to be used as an aid and
/ or introduction to garage door installation, and does not replace the
complete Installation Instructions and Owner's manual available on the
web at www.Wayne-Dalton.com. Wayne Dalton highly recommends
that you read and fully understand the Installation Instructions and
Owner's Manual before you attempt this installation.
To avoid possible injury, read and fully understand the enclosed
instructions carefully before installing and operating the garage door. Pay
close attention to all warnings and notes. After installation is complete,
fasten this manual near garage door for easy reference.
The complete Installation Instructions and Owner's Manual are available at no
charge from:
- Your local Wayne Dalton Sales Center, or
- Online at www.Wayne-Dalton.com, or
- By mailing to: Wayne Dalton, a division of Overhead Door Corporation, P.O. Box
67, Mt. Hope, OH., 44660
Part Number
350139
2
2
2
3
4
7
11
11
11
11
11
13
REV10_01/12/2021
Advertisement
Table of Contents
Related Manuals for Overhead door Wayne Dalton 8000
Summary of Contents for Overhead door Wayne Dalton 8000
-
Page 1: Table Of Contents
The complete Installation Instructions and Owner’s Manual are available at no charge from: - Your local Wayne Dalton Sales Center, or - Online at www.Wayne-Dalton.com, or - By mailing to: Wayne Dalton, a division of Overhead Door Corporation, P.O. Box 67, Mt. Hope, OH., 44660 Part Number 350139 REV10_01/12/2021 ©Copyright 2021... -
Page 2: Pre-Installation
Pre-Installation CAUTION Important Safety Instructions IF ANY PART OF THE DOOR IS TO BE INSTALLED ONTO PRESERVATIVE- TREATED WOOD, PTFE-COATED OR STAINLESS STEEL FASTENERS MUST BE DEFINITION OF KEY WORDS USED IN THIS MANUAL: OBTAINED AND USED. REPLACEMENT FASTENERS MUST BE OF AT LEAST EQUAL STRENGTH AND SIZE AS ORIGINAL FASTENERS. -
Page 3: Breakdown Of Parts
BREAKDOWN OF PARTS NOTE: The illustrations shown on this page are general representations of the door parts. Each specific door models may have unique variations. A. FLAG ANGLES (AS REQUIRED): H. TRACKS (AS REQUIRED): A1. Fully Adjustable (F.A.) Flag Angles H1. -
Page 4: Door Installation Instructions
bracket using (1) 1/4” - 20 x 9/16” track bolt and (1) 1/4” - 20 flange hex nut. DOOR INSTALLATION If a top jamb bracket was included, hand tighten it to vertical track using the lower hole of the INSTRUCTIONS hole/ slot pattern in the 3rd hole set and (1) 1/4”... - Page 5 Strutting Schedule Attaching Top Fixtures To Top Section Door Height Configuration Door Width 14’0” - 16’11” 17’0” - 19’11” 20’0” NOTE: Refer to Illustrations shown below or Package Contents to determine which Top 8’3” - 8’9” Solid (2) 2” Struts, (3) 2”...
- Page 6 SHIMMED SIDE MUST BE RAISED THE HEIGHT OF THE SHIM. Horizontal 12” Radius track angle NOTE: Make sure the counterbalance lift cable is located between the track rollers and the track door jamb. Starting on the left hand side of the bottom section, remove the nail. Position the left hand 1/4”-20 x 9/16”...
-
Page 7: Counterbalance Installation Instructions
section of the door with the lower sections. Once aligned, position the top fixture slide, out Once the end bearing bracket is properly positioned as shown in the illustration, tighten the against the horizontal track. Maintaining the slide’s position, tighten the 1/4” - 20 flange hex 3/8”... - Page 8 Slide center bracket bearing into the spring. Align the stationary spring cone(s) with the holes Mounting surface Center bracket Mounting Vertical in the center bracket. Secure the torsion spring(s) to the center bracket with (2) 3/8” - 16 x bushing assembly (3”...
- Page 9 Typicall left hand Torsion shaft / Typicall left hand cable drum Torsion keyed shaft end bearing bracket Securing Door for Spring Winding With the door in the fully closed position, place locking pliers onto both vertical tracks just above the third track roller. This is to prevent the garage door from rising while winding springs.
- Page 10 ©Copyright 2010 Overhead Door Corporation 102081 REV2 06/24/2010 the counterbalance system. Adjustments or repairs must ONLY be made by a trained door systems technician using proper tools and instructions.
-
Page 11: Maintenance
6.) Make sure door is not rubbing on jambs. 3/4” To 7/8” 3/4” To 7/8” IMPORTANT: IF DOOR STILL DOES NOT BALANCE PROPERLY, THEN CONTACT A TRAINED Door edges DOOR SYSTEM TECHNICIAN. Horizontal tracks MAINTENANCE Cleaning Your Garage Door IMPORTANT: DO NOT USE A PRESSURE WASHER ON YOUR GARAGE DOOR! While factory-applied finishes on garage doors are durable, it is desirable to clean them on a routine basis. - Page 12 16 - 1/2 (7’ - 6”) (7’ - 9”) 17 - 1/2 available at no charge from Wayne Dalton, a division of Overhead Door Corporation, P.O. Box (8’ - 0”) (one per spring) Number of Installed Spring Turns Copyright 2010 Wayne Dalton, a...
-
Page 13: Warranty
Models 8000, 8100, 8200 Wayne Dalton, a division of Overhead Door Corporation ("Seller") warrants to the original purchaser of the Models 8000, 8100, 8200 (“Product”), subject to all of the terms and conditions hereof, that the Product and all components thereof will be free from defects in materials and workmanship for the following period(s) of time,... - Page 14 Thank you for your purchase. PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE If you need assistance, please call 1-866-569-3799 (press Option 1) and follow the prompts to contact a customer service representative. They will be happy to handle any questions that you may have.
